Garagentorantriebe Modell LM60XX, LM80XX
Modèle LM60XX, LM80XX de ouvre-porte de garage
Garage Door Operator Model LM60XX, LM80XX
Model LM60XX, LM80XX Garageportsåbner
Abridor de la puerta de garage, Modelo LM60XX, LM80XX
M˯·ÓÈÛÌfi˜ AÓÔ›ÁÌ·ÙÔ˜ °Î·Ú·˙fi ÔÚÙ·˜, MÔÓÙ¤ÏÔ LM60XX, LM80XX
Apriporta per garage Modello LM60XX, LM80XX
Garasjeportåpner, Modell LM60XX, LM80XX
Model LM60XX, LM80XX Garagedeuropener
Operador automático de porta, Modelo LM60XX, LM80XX
Garageportöppnare Modell LM60XX, LM80XX
Autotallin oven avaaja, Malli LM60XX, LM80XX
Устройство за управление на гаражна врата Модел LM60XX, LM80XX
Pohon garáÏov˘ch vrat model LM60XX, LM80XX
A LM60XX, LM80XX, -as modell: garázsajtók hajtós
Ure∂aj za otvaranje garaÏnih vrata Model LM60XX, LM80XX
nap´d drzwi gara˝owych model LM60XX, LM80XX
Dispozitiv de deschis uøa garajului modelul LM60XX, LM80XX
Привод гаражных ворот, модель LM60XX, LM80XX
enota garaÏnih vrat model LM60XX, LM80XX
Otváraã garáÏov˘ch vrát model, LM60XX, LM80XX
Garaj Kapisi Operatörü Model LM60XX, LM80XX
Уређај за руковање вратима гараже Модел LM60XX, LM80XX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LiftMaster PROFESSIONAL LM60 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Chamberlain LiftMaster PROFESSIONAL LM60 Series

  • Page 1 LM60XX, LM80XX Pogonska – Otváraã garáÏov˘ch vrát model, LM60XX, LM80XX Obrázky – Talimatlar Garaj Kapisi Operatörü Model LM60XX, LM80XX – Упутства – Уређај за руковање вратима гараже Модел LM60XX, LM80XX Chamberlain GmbH Alfred-Nobel-Str. 4 D-66793 Saarwellingen www.chamberlain.de info@chamberlain.de...
  • Page 2: Table Of Contents

    WARNING Start by Reading These Important Safety Instructions Failure to comply with the following instructions may result in serious personal injury or property damage. • Read these instructions carefully • The garage door opener is designed and tested to offer reasonable safe service provided it is installed and operated in strict accordance with the instructions in this manual.
  • Page 3: Before You Begin

    Slide outer trolley (1) into back (opener) end of the rail assembly (2), be sure end with trolley release arm (3) is heading in direction of The Chamberlain Arm™ for use on door types B and D. opener. Slide outer trolley down rail until it engages with inner trolley.
  • Page 4 Attach Emergency Release Rope & Handle Position the Header Bracket Thread one end of rope (1) through hole in top of red handle so The header bracket must be rigidly fastened to a structural "NOTICE" reads right side up as shown (3). Secure with an overhand support of the garage.
  • Page 5 Install Door Control Program your Opener & Remote/Wireless Wall Control Locate door control where the garage door is visible, away from door and door hardware and out of the reach of children. Mount Activate the opener only when door is in full view, free of at least 1,5 m (5 feet) above the floor obstruction and properly adjusted.
  • Page 6: Using The Wall-Mounted Door Control

    ADJUSTMENT SECTION Program your Keyless Entry Setting the Limits Activate the opener only when door is in full view, free of obstruction and properly adjusted. No one should enter or leave garage while door is in motion. Do not allow children to operate Travel limits regulate the points at which the door will stop when push button(s) or remote(s).
  • Page 7: Install The Protector System

    (11) Model 770E The Protector System™ • Clear any ice or snow from garage floor area where garage (12) Model 1703E The Chamberlain Arm™ door closes. (13) Model FLA230 Flashing Light Kit • Repeat Setting Limits and Force, see adjustment steps 25 and 26.
  • Page 8: Care Of Your Opener

    HAVING A PROBLEM? (CONT.) CARE OF YOUR OPENER When properly installed, opener will provide high performance with a minimum of maintenance. The opener does not require additional 12. Opener strains: lubrication. Door may be unbalanced or springs are broken. Close door and use Limit and Force Settings: These settings must be checked and manual release rope and handle to disconnect trolley.
  • Page 9: Operation Of Your Opener

    A power door operator, in combination with a Garage Door must be installed and workmanship will be repaired or replaced (at Chamberlain's option) at no cost to the owner for maintained according to all the Manufacturer’s instructions, to meet the provisions of EN12453, EN13241-1 and Machinery Directive, 2006/42//EEC.
  • Page 10 Anleitungen – Garagentorantriebe Modell LM60/ LM80XX/ K700XX Instructions – Modèle LM60/ LM80XX/ K700XXde ouvre-por te de gar age Instructions – Garage Door Oper ator Model LM60/ LM80XX/ K700XX Instruktioner – Model LM60/ LM80XX/ K700XX Gar ageportsåbner Instrucciones – Abridor de la puer ta de gar age, Modelo LM60/ LM80XX/ K700XX O‰ËÁ›Â˜...
  • Page 11 A. 0-100mm B. 150-250mm (2x) 24V/21W Max. A. 0-100mm B. 150-250mm (4x) (10x) (1x) 158A49 41A4166 41A589-1 (4x) 41A5797 12B374 12C810 171A28 83A11 41B4101-1 10A20 41A5908 21(1x) 41A5800 41A5734C (433Mhz) 41A6516-1 (868Mhz) 41B4494-1 (2x) 111A79 (2x) 210C42 210C42 41D577 41C161 (60VA) 41C0162 (80VA) 178B34...
