GLOBBER E-MOTION 14 Original Instructions Manual

Foldable electric scooter
Hide thumbs Also See for E-MOTION 14:
Table of Contents

Advertisement

Quick Links

www.globber.com
Original instructions
Instructions d'origine
+
12
70
kg
154lbs
max
From/De
1.45 m
4'8"
to/à
1.75 m
5'7"
E-MOTION 14
E-MOTION 210
200W
FOLDABLE ELECTRIC SCOOTER/
TROTTINETTE ÉLECTRIQUE PLIABLE
Personal Light Electric Vehicle (PLEV)
EN 14619:2019 CLASS A: 70KG MAX
i
Class 2 / Classe 2
EN17128:2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-MOTION 14 and is the answer not in the manual?

Questions and answers

Related Manuals for GLOBBER E-MOTION 14

Summary of Contents for GLOBBER E-MOTION 14

  • Page 1 E-MOTION 14 E-MOTION 210 200W FOLDABLE ELECTRIC SCOOTER/ TROTTINETTE ÉLECTRIQUE PLIABLE Class 2 / Classe 2 EN17128:2020 Original instructions Personal Light Electric Vehicle (PLEV) Instructions d’origine EN 14619:2019 CLASS A: 70KG MAX From/De 1.45 m 4’8” 154lbs to/à 1.75 m...
  • Page 2 2001/95/EC General product safety directive Hereby declare with the sole responsibility that / Déclarons par l présente sous notre seule responsabilité que : Product Name/ Désignation: Globber electric scooter (E-MOTION 14, E-MOTION 210) Model Number/ Modèle nr : 750-101, 750-102, 750-103, 758-120...

  • Page 3: Manuel D'utilisation

    OWNER’S MANUAL ENGLISH MANUEL D’UTILISATION FRANÇAIS BENUTZERHANDBUCH DEUTSCH MANUAL DEL PROPIETARIO ESPAÑOL MANUALE D’USO ITALIANO GEBRUIKSHANDLEIDING NEDERLANDS MANUAL DE INSTRUÇÕES PORTUGUÊS INSTRUKCJA OBSŁUGI POLSKI KULLANIM KILAVUZU TÜRKÇE РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ РУССКИЙ P108 使用說明 繁體中文 P120...

  • Page 4: Technical Specification

    Please keep these instructions for future reference. EN 17128:2020 CLASS 2: 70KG MAX EN 14619:2019 CLASS A: 70KG MAX READ THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER BEFORE USING THE PRODUCT. 1 - SAFE USE OF THE ELECTRIC SCOOTER This appliance can be used by children aged from 12 years old and above and by persons with reduced physical, sensory, or mental capabilities or those with lack of experience and knowledge, if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 5: On/Off Function

    - To turn off the scooter, press and hold the ON/OFF button until the LCD screen and taillights turn off; release the ON/OFF button and the LED side lights will also turn off. - Your E-MOTION 14/E-MOTION 210 will automatically turn off after 10 minutes of inactivity. START-UP Once the scooter is in ON mode, it is now ready to use.
  • Page 6 SPEED MODE SELECTION When you first press the ON/OFF button, the scooter is by default in “speed mode 2”. When the scooter is in “ON” mode, but the motor is not engaged, the scooter is in “standby mode”. In standby mode, you can switch between the 2 speed modes by double-clicking the ON/OFF button. 1. Speed mode 2 (default mode): max speed is 15km/h. The LCD screen and taillight will continuously light up, while the side LED lights will flash slowly.

  • Page 7: Fold The Scooter

    - I n case the red button gets jammed and cannot be pulled, please lift the t-bar tube slightly to find a point where there is no pressure on the folding mechanism, then pull the clamp. WARNING! RISK OF INJURY BY PINCHING! DO NOT INSERT YOUR FINGERS INTO THE SHADED AREA INDICATED. The folding mechanism might become loose after being used over time. In such case, please use the provided hex wrench to tighten the bolt slightly as shown below.
  • Page 8 If in doubt please contact us at contact@globber.com Important: - Prior to attempting any product repairs yourself, please contact your retailer and/or Globber directly at contact@globber.com to get the full technical and safety recommendations. - In case of battery leakage, do not touch it.
  • Page 9 1. If the scooter battery is low or uncharged, the appliance can be used as a standard scooter. To do so, stand on the scooter with your hands on each handlebar and push with one foot to make it moving forward. Proceed with caution to start with. 2.

  • Page 10: Maintenance

    • Caution: The rear wheel has a motorised part. If you wish to check the motorized parts or change it, contact a qualified technician or a Globber representative at contact@globber.com. • Eliminate the sharp edges generated by the use. • Do not modify or transform the vehicle, including the steering tube and sleeve, stem, folding mechanism and rear brake. or the warranty will be invalidated.

  • Page 11: Warranty

    The manufacturer is not liable for incidental or consequential loss or damage due directly or indirectly to the use of this product. Globber does not offer an extended warranty. If you have purchased an extended warranty, it must be honoured by the store at which it was purchased.

  • Page 12: Troubleshooting

    2 - Your scooter is new and has low autonomy? In both cases (1 and 2) the battery needs to be changed, please contact your dealer or a Globber representative at contact@globber.com Excessive overload occurs during a steep incline or when the rider is too Excessive use of heavy;...

  • Page 13: Error Code

    11 – BUILT-IN MALFUNCTION DETECTION SYSTEM This E-MOTION 14/210 scooter has a built-in malfunction detection system. In the event of an electrical problem, the screen will display an ERROR code. Refer to the below table to find the related cause and remedial actions required. IMPORTANT: Prior to repairing, contact your retailer to get disassembly and assembly recommendations.
