- Page 1 Instruction Manual for the User Manual Electric Motorcycle Please read the Manual thoroughly before use. Do not ride this motorcycle without fully understanding its features.
- Page 2 User Manual. Hence all specifications are as per the actual product. FELO Technology(Shanghai) Co., Ltd. reserves the right to revise this book at any time without any advance notices, and shall assume no responsibilities for such revision.
-
Page 3: Table Of Contents
Smart key system ............23 Overview ..............3 Burglar alarm system ..........26 Vehicle information ............4 ABS (anti-lock brake system) ........26 FELO MOTO APP ............5 Ramp parking function ..........27 Riding safety ETCS traction control ..........27 Safety guidelines ............6... -
Page 4: Preface
Preface Maintenance Technical parameters Importance of maintenance ........42 Main assemblies ............61 Maintenance schedule ..........43 Lithium battery ............62 Parts and components maintenance ......45 Electric installation ............. 62 Fuse ................62 Troubleshooting Index Motorcycle cannot ride..........54 The power battery cannot be charged. -
Page 5: Important Information
Important Information Overview In this User Manual, particularly important information is distinguished with the following symbols. Danger Failure to follow the instructions may result in serious injury or death. Warning Failure to follow the instructions may result in serious injury or death. Attention Failure to follow the instructions may result in your injury. -
Page 6: Vehicle Information
Important Information Vehicle information The chassis number and product label are unique to your motorcycle, and are used to identify your motorcycle. They are required when registering your motorcycle. They may also be required by your dealer when you order any parts for replacement. -
Page 7: Felo Moto App
● Motorcycle inspection ● Track history You can search “FELO MOTO” in the APP Store to download FELO MOTO APP, or scan the QR code below to access the official website, and download FELO MOTO APP or its instruction manual. -
Page 8: Riding Safety
Riding safety Safety guidelines Boots Select a pair of protective boots that fit your feet without affecting your riding. Clothing Owner's responsibility Select an eye-catching long-sleeved shirt with protective effect, and a As the owner, you shall be responsible for operating your vehicle pair of durable pants (or a protective suit) suitable for riding. - Page 9 Riding safety Handling Accidents Warning Personal safety is your first priority. If you or anyone else is injured, This motorcycle uses the 96 V lithium battery. If you dispose it improp- carefully assess the severity of the injury and determine whether it is erly after an accident, it may cause serious injury or death.
- Page 10 Riding safety Loading guidelines ● For complete braking effect, operate both front and rear brakes simultaneously. ● Overloading may affect the operating, braking and stability of your ● Abnormal noises that do not affect using may occur after a long-time motorcycle.
-
Page 11: Vehicle Introduction
Vehicle Introduction Main components GLOVE BOX MAIN CUSHION PASSENGER CUSHION REAR TAIL LIGHT/BRAKE LIGHT PASSENGER FOOTREST REAR SHOCK ABSORBER REAR TURN SIGNAL LIGHT REAR BRAKE GEAR BOX RIDER FOOTREST SIDE STAND REAR-VIEW MIRROR POWER SWITCH... - Page 12 Vehicle Introduction STORAGE COMPARTMENT FRONT TURN SIGNAL LIGHT HEADLIGHTS FRONT FENDER FRONT BRAKE TIRES REAR FENDER LICENSE PLATE LIGHT GRAB RAIL...
-
Page 13: Main Electrical Components
Vehicle Introduction MAIN ELECTRICAL COMPONENTS POWER BATTERY CHARGING PORT USB CHARGING PORT POWER OFF SWITCH MOTOR POWER BATTERY BOX HORN DC-DC CONVERTER 12 V BATTERY ABS CONTROLLER Caution If the electrical system fails, please take your motorcycle to a qualified repair store as soon as possible for an overall inspection and repair. -
Page 14: Meter
Vehicle Introduction 5 READY indicator 1 Clock The vehicle is in the standby status. The clock is displayed in the 24-hour system. The VCU is 6 Real-time power scale display automatically calibrated according to the network. It displays the remaining power capacity of the power battery. -
Page 15: Indicators
Vehicle Introduction 1 Left-turn indicator 7 Right-turn indicator This indicator flashes when the This indicator flashes when the left-turn indicator or hazard warning right-turn indicator or hazard light is turned on. warning light is turned on. 2 Fault indicator 8 High beam indicator This indicator lights up when OBD has a fault code. -
Page 16: Switch
Vehicle Introduction Switch Left handlebar switch 1 Dimmer switch High beam Low beam 2 Turn indicator switch Left-turn indicator flashes. Right-turn indicator flashes. Switch off the turn indicator. 3 Sport mode switch (Gear S) Sport mode (Gear S): press and hold this switch (Gear S) to enter the sport mode. - Page 17 Vehicle Introduction Switch (continued) Right handlebar switch 5 Hazard warning switch Turn on the hazard warning indicator (all turn indicators flash at the same time,) Turn off the hazard warning indicator The hazard warning indicator is used in emergency circumstances, or when a vehicle is parked in a place where a traffic accident may occur to draw the attention of other drivers.
- Page 18 Vehicle Introduction Power switch 1 Turns off the power system. 2 Turn on the power system, and prepare to start the motorcycle. 3 LOCKED Lock the steering handlebar. Caution Leaving the power switch in the (ON) position without riding will completely drain the battery capacity. Please do not turn on the power switch while riding.
-
Page 19: Key
Vehicle Introduction Use of the mechanical key Your motorcycle is equipped with one smart key and two mechan- ical keys. To use the mechanical key, you need to insert the mechanical key If you lost your keys, please contact your dealer. into the corresponding keyhole, while turning the knob. -
Page 20: Storage Device
Vehicle Introduction Storage device Storage compartment The storage compartment is located under the main seat cushion. (To open the main seat cushion, see Page 30.) Do not exceed the maximum load carrying capacity for the storage compartment. Maximum load carrying capacity: 10 kg We recommend that you keep the plastic file bag con- taining the manual, motor vehicle registration certificate and insurance policy in the storage compartment for... - Page 21 Vehicle Introduction Glove box The glovebox is located on the left side below the steer- ing handlebar. Maximum load carrying capacity: 1.5 kg Caution Please do not store any valuable or fragile items inside it. When you leave the motorcycle, please take out the items from the glovebox to avoid any loss.
-
Page 22: Charging Port
Vehicle Introduction Charging port Power battery charging port The power battery charging port is located on the right side of the glovebox. Please open the charging port lid, and then use it. (For precautions on how to use the power battery, see Page 37.) (On how to charge the power battery, see Page 38.) charging... - Page 23 Vehicle Introduction USB charging port The USB charging port is located on the upper side of the glovebox. To use it please open the lid. The USB charging port type is Type-A. Maximum output power: 10 W (5 V/2 A) Precautions for use ●...
-
Page 24: Functions
Functions Riding mode Switching method Basic introduction This motorcycle has 3 speed modes: ● Normal mode: This mode can be applied to flat roads, congested roads, heavy rain, and other environments. The maximum speed in this mode is 80 km/h. ●... -
Page 25: Smart Key System
Functions Smart key system VCU technical parameters Frequency range: 700-2690 MHz Usage: Electric motorcycle VCU Technical parameters for the smart key Temperature: -20°C - 60°C Frequency range: 2400 MHz Rated voltage: 12 V Usage: Electric motorcycle VCU Antenna type: Bracket steel antenna for 4G and BT, ceramic antenna for GPS. - Page 26 Functions Basic introduction Operating range The smart key system enables you to operate the power switch The working range may vary when the power switch is locked or without inserting the mechanical key in the keyhole. unlocked. The system performs two-way verification between the motorcycle The smart key system may not work properly under the following and smart key to verify whether the smart key has been registered.
- Page 27 Functions Precautions when using the smart key: ● It is necessary to withstand interference from industrial, scientific and medical (ISM) application equipment that emits RF energy, or ● Do not drop the smart key or place any heavy objects on it. interference by other legal radio stations.
-
Page 28: Burglar Alarm System
Functions Burglar alarm system ABS (anti-lock brake system) This motorcycle is equipped with ABS (only on front wheel) that can Basic introduction prevent the brake from being locked during the emergency brake. The burglar alarm system reduces the risk of the motorcycle to be ●... -
Page 29: Ramp Parking Function
Functions Ramp parking function ETCS traction control The ramp parking function can prevent the motorcycle from skidding ETCS traction control can effectively prevent the wheels from while parking on a ramp. You can enable this function by following slipping while the motorcycle is in motion. If the VCU detects that the steps below: the difference of the instantaneous speed between the front and rear wheels is too big, the current output will be limited, making the... -
Page 30: Riding Guidelines
Riding Guidelines Preparation before riding Please check the following items when you ride your motorcycle every time to ensure that it is in safe working conditions. Be sure to follow the inspection items, maintenance procedures and maintenance schedule specified in this User Manual. Reference Inspection items Inspection contents... -
Page 31: Start The Motorcycle
Riding Guidelines Start the motorcycle You should always carry your smart key or mechanical key with you when riding your motorcycle. (See Page 17) 1 Make sure the power-off protection switch is turned on (for informa- tion on how to open the cushion, see Page 30). 2 Unlock the steering handlebar lock (See Page 31) 3 Unlock the power switch (See Page 32) Caution... -
Page 32: Cushion
Riding Guidelines Cushion Close the main cushion Close and press down on the tail of the saddle until it is locked. Pull the saddle up slightly to ensure that it is firmly locked. Open the main cushion Caution Mechanical mode: 1 Using a mechanical key, see Page 17. -
Page 33: Steering Handlebar Lock
Riding Guidelines Steering handlebar lock Smart mode: 1 Carry the smart key or run the APP, enable your cell phone's Blue- tooth, and then approach your motorcycle. 2 Press the power switch while turning it from the (OFF) position to (LOCKED) position. - Page 34 Riding Guidelines Caution Caution When you leave your motorcycle, please make sure that the power If you lose your key during riding, you can still continue to use your motorcycle, and turn off the power switch. However, once the power switch is in (OFF) or (LOCKED) position.
-
Page 35: Riding
Riding Guidelines Riding Before starting your motorcycle, please check the traffic condition around you. Adjust the rear-view mirror, and turn on the turn signal light to indicate your riding direction. 1 Start the power supply, and retract the side stand. (For information on how to start the power supply, see Page 29.) 2 Press the Electric start switch on the right handlebar. -
Page 36: Braking
Riding Guidelines Braking Turn off the speed-control handle, and then hold the front and rear brake handles at the same time. The brake light at the rear of the motorcycle will light up when braking. Caution When you are about to make a turn or stop during riding, you need to brake the motorcycle in advance. -
Page 37: Parking
Riding Guidelines Parking Please park your motorcycle on the solid and flat ground with the side stand, and lock the steering handlebar. If you have to park on the slightly tilted or loose ground, make sure to park stably, and keep the motorcycle from moving or tipping over. 1 Turn the power switch to the (OFF) position. -
Page 38: Battery Charging
Riding Guidelines Battery charging Basic introduction The power battery has the following features. ● As the power battery is repeatedly charged and discharged, the This model is equipped with two batteries: one lead-acid battery battery capacity will decrease over time. (small) and one power lithium battery (large). - Page 39 Riding Guidelines Please follow the rules below ● Please use original power batteries of the motorcycle, and do not use power batteries of other brands or other models. ● Please prevent the power battery from contacting water, beverage or corrosive liquid. ●...
- Page 40 Riding Guidelines How to charge Charging environment Please charge the power battery in the following locations. Please always use the power battery charger supplied with the motorcycle ● Park the motorcycle on a firm horizontal ground. to charge your power battery. ●...
- Page 41 Riding Guidelines About charger Charger indicator Please store the power battery Description on the charger indicator status charger far away from direct sunlight and rain. Charger status Indicator During charging, you can judge the charging status according to the meter display. Standby status Red indicator stays still.
- Page 42 Riding Guidelines Charger 2: Charger indicator Description on the charger indicator status Plug Charger status Indicator Remarks Power Con- Standby Green indicator battery nector is always on. Charger Charging Green indicator flashes. Fully charged Green indicator is always on. No load (short circuit, Red and green Check output undervoltage and...
- Page 43 Riding Guidelines Instructions for the Charger surroundings well ventilated during charging. ● Do not charge the battery in places where there is a risk of thunder- Please follow the rules below when using the charger: storms. ● When the battery is charged using the charger, insert the charger into ●...
-
Page 44: Maintenance
Maintenance Importance of maintenance Always keep your motorcycle well maintained.This is very important to keep your body safe, protect your properties, achieve the optimal performance of your motorcycle, and prevent your motorcycle from any faults. Warning Failure to carry out normal maintenance or correct any malfunctions before riding may result in serious or fatal accidents. -
Page 45: Maintenance Schedule
Maintenance Maintenance schedule Every two years Every year Every 10,000 km Every 5000 km After 1,000 km Items Inspection before riding ▲ Check brake discs ○ ● ● ● ● ▲ Check front wheel brake pads ○ ● ● ● ●... - Page 46 Maintenance Every two years Every year Every 10,000 km Every 5000 km After 1,000 km Items Inspection before riding Check the motorcycle frame ● ● Check the rocker arm ● ● Check if nuts, bolts and fasteners are loose ○ ●...
-
Page 47: Parts And Components Maintenance
Maintenance Parts and components maintenance Parts replacement Power-off switch To ensure reliability and safety, please use genuine parts or equivalent Power-off switch is located in the storage compartment. products. When you need to replace any parts, please consult your authorized dealer. - Page 48 Maintenance Motor and controller Check tire pressure The controller of a motorcycle, one of the most important parts and Visually check the tires and measure the tire pressure with the components, is a core control device that is used to control the start barometer at least once a month or whenever you feel that the tire and operation of the motorcycle’s motor.
- Page 49 Maintenance Check tire damage Check tread depth Position mark/Wear indication mark Check the tire for cuts, cracks, exposed fabric or tire threads, or Check the indication marks of the tread wear. If any wear indication nails or other foreign objects embedded in the tire side or tread. marks are visible, please replace the worn tire immediately.
- Page 50 Maintenance Please follow the rules below ● Use recommended tires or an equivalent products with the same size, structure, speed rating and load capacity. ● Do not install any inner tube in the tubeless tire of this motorcycle. Excessive heat may cause the inner tube to burst. ●...
- Page 51 Maintenance Check brake fluid Turn the steering handlebar, and check whether the brake fluid level Front brake fluid is above the mark of the lower limit to the fluid level, when the brake reservoir fluid level is aligned with the mark line. Rear brake If the brake fluid level in the reservoir is below the mark of the fluid reservoir...
- Page 52 Maintenance Check brake pads and brake discs Check the condition of the wear-and-tear marks on the front and rear brake pads. If the wear-and-tear of the brake pads has reached the bottom of indication mark, the pads need to be replaced. Check the state of wear-and-tear on the front and rear brake discs.
- Page 53 Maintenance Side stand Inspection Check whether the side stand works smoothly. If the side stand is ● stiff or rattling, clean the pivot area and lubricate the pivot bolt with clean grease. ● Check the springs for damage or loss of elasticity. ●...
- Page 54 Maintenance Speed-control handle Inspection When the power switch is in the (OFF) position, check whether the speed-control handle can be turned from the fully-closed to the fully-opened position smoothly. If the speed-control handle does not operate smoothly or return automatically, please refer the motorcycle to your authorized dealer for service.
- Page 55 Maintenance Replace gear oil ● Support the motorcycle with a stand so that the front and rear wheels are lifted from the ground. Dipstick cap ● Place the oil tray under the gearbox to collect the oil, remove the dipstick cap and oil plug until the gearbox oil is completely drained. ●...
-
Page 56: Troubleshooting
Troubleshooting Motorcycle cannot ride. The power battery cannot be charged. If you place the power switch in the (ON) position, but the Please check the following items: display still show nothing. ● Have you charged your motorcycle in a very hot place (e.g. a place exposed to direct sunlight)? Please check the following items: ●... -
Page 57: When The Smart Key System Cannot Work Properly
Troubleshooting When the smart key system Tire puncture cannot work properly When the smart key system cannot work properly, please execute the Repairing a tire puncture or removing a wheel needs special tools following operations. and professional skills. ● First confirm whether your smart key is within the normal operating We recommend you leaving such work to your authorized dealer. -
Page 58: Bulb Fault
Troubleshooting Bulb fault Turn signal light fault If the turn signal light is faulty, the front or rear turn signal light on the same side of the faulty light will flash rapidly after the turn signal All bulbs on the motorcycle are LEDs. If any of the LEDs fails to light light is turned on, the turn signal light icon in the corresponding up, please contact your authorized dealer for service. -
Page 59: Other Information
Other information Maintenance of the motorcycle 5 Apply a layer of wax on plastic exterior parts to avoid corrosion. ● Avoid using products that contain strong degreasers or chemical solvents. These substances can damage the metal parts, paint layer and plastic parts of your motorcycle. Regular cleaning and polishing can ensure that your motorcycle ●... - Page 60 Other information – Do not directly rinse the parts near the headlight with water: ● Panel The inner lampshade of the headlight may temporarily fog up Follow the rules below to prevent scratches and damage: after cleaning or when riding in the rain, which makes no impact –...
-
Page 61: Storage Of Motorcycle
Other information Storage of motorcycle – Clean your motorcycle and wax all paint finishes (except for matt paint finishes). Apply anti-rust oil to all chromium-plated parts. – Support your motorcycle with the repair bracket, and then insert stop blocks to lift two tires above the ground. If you place your motorcycle outdoors, you should consider to cover –... -
Page 62: Transportation Of The Motorcycle
Other information Transportation of the motorcycle Environment Protection If you want to transport your motorcycle, you need a motorcycle Owning and riding the motorcycle is enjoyable, but you must do trailer, or a flatbed truck or trailer equipped with the loading platform, your duty to protect the environment. -
Page 63: Technical Parameters
The values on this parameter page are for your reference only. * The promotional pictures, functions, performance and other parameters in this User Manual are for your reference only. Please refer to the actual item. * The final interpretation right is owned by FELO Technology(Shanghai) Co., Ltd. -
Page 64: Lithium Battery
* The promotional pictures, functions, performance and other parameters in this User Manual are for your reference only. Please refer to the actual item. * The final interpretation right is owned by FELO Technology(Shanghai) Co., Ltd. * The operating voltage of battery is 96 V. - Page 65 Index ABS (anti-lock brake system) .... 26 Cannot ride ........54 Accessories and modifications .... 8 Cannot work properly ......55 Accidents ..........7 Charger..........39 Chassis number........4 Check ..........47 Battery charging ........ 36 Cushion ..........30 Brake ........... 7 Brake fluid..........
- Page 66 Electric start switch ......15 Environment ........60 Indicators ........... 13 ETCS ..........27 key ............. 55 FELO MOTO APP ....... 5 Loading guidelines....... 8 Glovebox ........... 19 Low speed mode ....... 22 Hazard warning switch ...... 15 Main assemblies ........ 61 Horn button ........
- Page 67 Index mechanical key ........17 Power switch ........16 Meter ..........12 Precautions for safe riding ....6 Motor and controller......46 Preparation before riding ....28 Product label........4 Normal mode ........22 Ramp parking ........27 Replace gear oil......... 53 Parking ..........
- Page 68 Index Smart key .......... 17 Transportation ........60 Speed-control handle ......52 Tread depth ........47 Sport mode ........22 Turn indicator switch ......14 Sport mode switch (Gear S) ....14 Steering handlebar lock ..... 31 USB charging port ......21 Storage ..........
- Page 72 FELO Technology(Shanghai) Co., Ltd. Room D2-101, No.6000, Shenzhuan Highway, info@front-design.cn Songjiang District, Shanghai +86-21-6785-9325...
