Heavy Duty Farm Yard Sprayer
Assembly, Parts and Operator's Manual
Rogers Sprayers Inc.
Rogers Sprayers Inc.
141 - 105th Street East
Saskatoon, SK S7N 1Z2
Canada
FY325
(3 Nozzle, 25 USG Tank)
Version FY-1405
Toll Free 1-888-975-8294
Phone: (306) 975-0500
Fax: (306) 975-0499
Email: info@rogerssprayers.com
Web: www.rogerssprayers.com
www.rogerssprayers.com
Advertisement
Related Manuals for Rogers Sprayers FY325
Summary of Contents for Rogers Sprayers FY325
- Page 1 Rogers Sprayers Inc. 141 - 105th Street East Phone: (306) 975-0500 Saskatoon, SK S7N 1Z2 Fax: (306) 975-0499 Canada Email: info@rogerssprayers.com Web: www.rogerssprayers.com FY325 Heavy Duty Farm Yard Sprayer (3 Nozzle, 25 USG Tank) Assembly, Parts and Operator’s Manual Version FY-1405 Rogers Sprayers Inc.
- Page 2 Application Rate Tables ....................4 Assembly Instructions ..................... 5 General Assembly Drawing ..................... 8 Plumbing Assembly Drawing ..................9 ORC Assembly Drawing ....................10 Electrical Assembly Drawing ..................11 Visit our website, www.rogerssprayers.com, for additional models. Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com...
- Page 3 Nozzles The FY325 and FY425 are equipped with 80º spray tips respectively, spaced at 16”. Tips are mounted with self-aligning ¼ turn caps for easy removal or change.
- Page 4 Application Rate Tables Table 3: Acceptable Tip Sizes for Standard and High Flow Pumps Table 4: Nozzle Application Rates for 16” (40cm) Spacing Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com...
- Page 5 Long Bolt and Standoff and Standoff Back Front Figure 3: Airfoil assembly Figure 4: Flow monitor and pressure gauge Figure 5: Mounting hitch on boom Figure 6: Mount tank and secure with strap Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com...
- Page 6 Start assembly before hitch is attached. ” - Attach spray wand plumbing assembly - Place insulated clamps on hose ” - Drill holes in shroud Figure 11: Boom feed hose Figure 12: Spray wand plumbing assembly Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com...
- Page 7 Adjust spray wand plumbing assembly if necessary to ensure free movement of valve and wand hose. Note: Both FY 425 and FY 325 models use the outer front stand off bolt to mount the clamp for the spray wand Rogers Sprayers Inc. Toll Free 1-888-975-8294...
-
Page 8: General Assembly
General Assembly Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com... -
Page 9: Plumbing Assembly
Plumbing Assembly Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com... - Page 10 Flow Kit - #14881 Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com...
-
Page 11: Electrical Assembly
Electrical Assembly Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com... - Page 12 Saskatoon, SK S7N 1Z2 Canada Email: info@rogerssprayers.com ROGERS SPRAYERS INC OWNER WARRANTY AGREEMENT Windfoil Drift Containment Spray Systems (DCSS) are warranted to be free of factory defects under normal and intended use for a period of one (1) year from date of purchase to the original purchaser.
- Page 13 Rogers Sprayers Inc. 141 - 105th Street East Saskatoon, SK S7N 1Z2 Canada Phone: (306) 975-0500 Fax: (306) 975-0499 Email: info@rogerssprayers.com Web: www.rogerssprayers.com Rogers Sprayers Inc. Toll Free 1-888-975-8294 www.rogerssprayers.com...
