Rogers Sprayers EcoFoil EF1000 Assembly And Operation Manual

Rogers Sprayers Inc.
th
141– 105 Street East, Saskatoon, SK S7N 1Z2 Canada
Phone: (306) 975-0500 Fax: (306) 975-0499
E Mail: info@rogerssprayers.com web: www.rogerssprayers.com
Windfoil Drift Containment Sprayer
EcoFoil
EF1000, EF1500, EF2000
Assembly and Operations Manual
Minimize Chemical Drift
The WINDFOIL sprayer has been designed in wind tunnels to control air flow around and behind the sprayer
to minimize drift, allowing safe spraying in windy conditions. Drift can blow off a field after it has been sprayed,
especially in high winds. Reasonable caution should be taken, in order to spray effectively and safely.
For maximum drift control, keep curtain in contact with the canopy to ensure a seal to it. Drift control
of the WINDFOIL is less effective when the wind blows the curtain off the turf canopy, breaking the
seal between the curtain and the turf.
Safety
Many people die or suffer serious injury in job related accidents every year due to carelessness. Know your
machinery and be aware of potential hazards. Put safety first in all your operations. Review all instructions and
procedures outlined in this manual annually. Every operator must familiarize themselves with the operating
instructions of the sprayer.
Nozzles
The EcoFoil is equipped with conventional 110º spray tips, spaced at 20 ". Tips are mounted with self-aligning
¼ turn caps for easy removal or change. Use the provided application rate tables to determine application rate.
Trouble Shooting
If dripping occurs, it is caused by the diaphragm not seating properly, the diaphragm may be hard, cracked, or
the seating may be damaged.
