- Page 1 Remote Grip MC-N10 Reference Guide • Read this document thoroughly before using the product. • To ensure proper use of the product, be sure to read “For Your Safety” (page 5). • After reading this document, keep it readily accessible for future reference.
-
Page 2: Table Of Contents
What the MC-N10 Can Do for You........ -
Page 3: Introduction
Introduction What the MC-N10 Can Do for You When connected to the camera, the MC-N10 can be used for such tasks as video recording, photography, and adjusting camera settings. It comes equipped with a rosette for attachment to third-party camera equipment. With the MC-N10... - Page 4 Remote High-Angle Video Recording and Photography The MC-N10 can be used for remote video recording or photography while the camera is mounted on a tall tripod or otherwise out of reach. You can even connect the camera to an external monitor via HDMI so that you can see the view through the lens on a conveniently-placed display while recording video or taking pictures remotely.
-
Page 5: For Your Safety
For Your Safety To prevent damage to property or injury to yourself or to others, read “For Your Safety” in its entirety before using this product. After reading these safety instructions, keep them readily accessible for future reference. A DANGER: Failure to observe the precautions marked with this icon carries a high risk of death or severe injury. - Page 6 A WARNING Do not handle with bare hands in locations exposed to extremely high or low temperatures. Failure to observe this precaution could result in burns or frostbite. Do not use batteries not specifically designated for use with this product. Failure to observe this precaution could result in fire or electric shock. A CAUTION Remove the batteries if this product will not be used for an extended period.
- Page 7 A WARNING (Batteries) Do not remove or damage the battery casing. Never use batteries with damaged casing. Failure to observe this precaution could result in the batteries leaking, overheating, rupturing, or catching fire. Keep batteries out of reach of children. Should a child swallow a battery, seek immediate medical attention. Do not immerse batteries in water or expose to rain.
-
Page 8: Parts Of The Mc-N10
Parts of the MC-N10 The parts of the product are identified below. Performs the function to the matching control on the camera. Rosette adapter attachment wheel Exposure compensation button (E) ISO sensitivity button (S) Turns the rosette adapter attachment Video-record button screw. - Page 9 Playback zoom in button (X) DISP button Multi selector i button Pressing the center has the same effect as MENU button pressing the camera J button. Playback button (K) Battery chamber cover ( Battery chamber cover latch release Parts of the MC-N10...
-
Page 10: Using The Mc-N10
Using the MC-N10 Readying the MC-N10 Inserting Batteries in the MC-N10 Insert two third-party AA batteries. Use batteries of the same make and model. Keeping the battery chamber cover latch release pressed (q), slide and open the battery chamber cover as shown (w). - Page 11 (q) and rotate the rosette adapter attachment wheel in the direction shown to fix the MC-N10 in place (w). Do not attempt to insert the MC-N10’s rosette adapter attachment screw into the tripod socket on the camera body. Attempting to force the screw into the tripod socket could damage the camera or MC-N10.
- Page 12 Connect the MC-N10 to the camera using the MC-N10’s supplied USB cable. Readying the MC-N10...
-
Page 13: Shooting With The Mc-N10
Powering Up While Connected While connected to the MC-N10 via USB, the camera will display a message regarding connection of a remote grip each time the camera or MC-N10 is turned on. Press the camera J button or tap the camera monitor. - Page 14 Press the shutter-release or video-record button on the MC-N10. In photo mode, the camera will focus when the shutter-release button on the MC-N10 is pressed halfway and take a picture when the button is pressed the rest of the way down.
- Page 15 Error. The status lamp will turn off after about 40 seconds if no action is taken. Try: turning the MC-N10 and camera off and then on again, disconnecting and reconnecting the USB cable, Red (flashes Connected/not...
-
Page 16: Precautions For Use
Precautions for Use ● Caution: Handling the MC-N10 To avoid dropping or damaging the camera or the camera equipment to which the MC-N10 is attached, support the device when carrying the MC-N10. ● Batteries If the product will not be used for a period of more than about two weeks, remove the batteries to prevent damage caused by leaking battery fluid. -
Page 17: Reattaching The Battery Chamber Cover
Reattaching the Battery Chamber Cover The battery chamber cover may detach to prevent damage if subject to excessive force while open. It can be reattached as shown in the illustration. Before reattaching the cover, orient it so that the hinge is visible. Reattaching the Battery Chamber Cover... -
Page 18: Technical Notes
Nikon reserves the right to change the appearance, specifications, and performance of the product described in this document at any time and without prior notice. Nikon will not be held liable for damages that may result from any mistakes that this document may contain. -
Page 19: Notices
The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Nikon Corporation may void the user’s authority to operate the equipment. Nikon Inc., 1300 Walt Whitman Road, Melville, New York 11747-3064, U.S.A. - Page 20 Notice for Customers in Canada CAN ICES-003 (B) / NMB-003 (B) Notices for Customers in Europe CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. This symbol indicates that electrical and electronic equipment is to be collected separately.
- Page 21 No reproduction in any form of this document, in whole or in part (except for brief quotation in critical articles or reviews), may be made without written authorization from NIKON CORPORATION. SB2K02(11) 6MDR0611-02 © 2022 Nikon Corporation...
