- Page 1 D4150 Fu l l Hei g h t Tu r n s t i l e 120 Rotor Made in 100 % Duty cycle...
-
Page 2: Introduction And Warnings
D4150 Introduction and Warnings This equipment is part of a large range of traffic flow products. They are designed to be easy to install, as all settings and internal wiring have been completed in our factory. Any of the instructions in this manual should only be carried out by a qualified service engineer or a competent person. - Page 3 D4150 Delivery,Movement & Transportation This article describes how your equipment will be delivered to you, specifications on the transportation used and advice including health & safety on movement of the equipment. The manufacturer will use a qualified transport company to deliver the product conforming to the...
- Page 4 D4150 Guide to Physical Installation Component Identification and Notes: You should check that you have received the following in your order as they are referred to throughout this manual (note this can change per barrier spec i.e. manual components are different from automatic):...
-
Page 5: Notes Area
D4150 Guide to Physical Installation (Cont) Tak ing into con s ide r ati on th at t h e plinth has been Once you have the Turnstile in position and Prepared correctly and is absolutely level and true, Have checked that it is all level, Bolt down side Lower the turnstile onto the plinth and visually align. -
Page 6: Commissioning Certificate
D4150 Commissioning Certificate We certify that the system covered by this certificate has been commissioned satisfactorily. Site Name Completion Site Reference Engineers Installing Installation Commenced Commissioning Equipment Fitted Handover Date Part 2. Existing Installation Items not covered under warranty/ This certificate: Part 3. - Page 7 D4150 Electrical Troubleshooting Guide Manual Release Please use the following instructions to operate the barrier manually, the following is assuming you have powered down the unit and opened the cabinet door: To Manually release the Turnstile, Turn the entry or exit key switch clockwise to release the rotor into free wheel.
- Page 8 D4150 Connection Terminals/Layo ut 24VDC Power supply...
- Page 9 D4150 Electrical Troubleshooting Guide The table (bottom) relates to the diagram directly below to help you trouble shoot electrical component errors Example 2 Example 1 Inputs 1 and 4 are highlighted There are Several Faults Which indicates that the stop...
-
Page 10: Troubleshooting Guide
D4150 T roubleshooting Guide MECHANICAL ERRORS CAUSE CORRECTION Turnstile is free wheeling Paddles are not latched in check manual release keyswitches Rotor is not spining Check bearings top/bottom Oil or grease bearings Rotor has a lot of play when locked... -
Page 11: Service Log
D4150 Service Log This Manual must be completed in accordance with the guidelines below, at any point service/repair work is carried out on the product. This is to achieve two things; 1. To keep a history of the product for yourself and your supplier/manufacturer. -
Page 12: T Echnica Data
D4150 T echnica Data Specification Dimensions: Specification Power Requirement: Frame: 1520 mm x 1360 mm x 220 v, Single Phase, 50 Hz, 5 Amps Arms and body: 2230 mm Primed/Powder Coated finish Duty Cycle: Rotor: 120 mm Ø tube with...
