SAFETY AND INSTALLATION INSTRUCTIONS
Model 4655
Manual Humidifier Control
Product Info &
Digital Manual
THESE INSTALLATION INSTRUCTIONS
ARE FOR THE APRILAIRE® MANUAL
HUMIDIFIER CONTROL ONLY.
For AprilAire® Humidifier installation, follow
AprilAire Humidifier Installation Instructions.
1
B2204275B • 10007235 • 6.22
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4655 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aprilaire 4655

  • Page 1 SAFETY AND INSTALLATION INSTRUCTIONS Model 4655 Manual Humidifier Control Product Info & Digital Manual THESE INSTALLATION INSTRUCTIONS ARE FOR THE APRILAIRE® MANUAL HUMIDIFIER CONTROL ONLY. For AprilAire® Humidifier installation, follow AprilAire Humidifier Installation Instructions. B2204275B • 10007235 • 6.22 English...
  • Page 2 WARNING ATTENTION INSTALLER: This product must be installed by a qualified heating and air conditioning contractor. Failure to do so could result in serious injury from electrical shock. 1. 120 volts may cause serious injury from electrical shock. Disconnect electrical power to the furnace before starting installation.
  • Page 3 INSTALLATION TEMPLATE                                   11 INTRODUCTION The Manual Humidifier Control (Part 4655) is designed for low voltage service to control humidification equipment.
  • Page 4 LOCATION The Control can be mounted on wall in living space or on return duct. WALL MOUNT • Locate on an inside wall of living area approximately 5 feet above the floor. • Do not locate control in the direct path of drafts from open doors and windows.
  • Page 5 INSTALLING AND WIRING WALL INSTALLATION 1. Select location for the Humidifier Control on an inside wall. Mount the Humidifier Control in a location where low voltage wires from the furnace area are already in place, or can be easily run. 2.
  • Page 6 FIGURE 1 – WALL MOUNT ANCHOR F (x2) SCREW E (x2) BASE PLATE D HUMIDISTAT SWITCH C COVER B KNOB A BASE PLATE D 90-1228 English...
  • Page 7 DUCT (SHEET METAL) INSTALLATION 1. Select Humidifier Control location on furnace return air duct. 2. Use the attached template to mark the duct opening. 3. Carefully cut the opening in the duct. 4. (See FIGURE 2) Gently pull knob A from Humidifier Control cover B.
  • Page 8 FIGURE 2 – SHEET METAL DUCT MOUNT GASKET G BASE PLATE D SCREW H (x4) HUMIDISTAT SWITCH C COVER B KNOB A INSIDE OF RETURN DUCT RETURN DUCT 90-1229 English...
  • Page 9 DUCT (FIBER BOARD) INSTALLATION 1. Select Humidifier Control location on furnace return air duct. 2. Cut a rectangular hole in the duct board, no smaller than 5-3/4 inches long by 3-3/4 inches wide. 3. Cut a rectangular piece of sheet metal to fit behind the hole in duct board for mounting the Humidifier Control.
  • Page 10 FIGURE 3 – FIBER BOARD DUCT MOUNT GASKET G HUMIDISTAT SWITCH C SCREW H (x4) COVER B KNOB A INSIDE OF RETURN DUCT BASE PLATE D SHEET METAL PLATE RETURN DUCT RETURN SHEET METAL CUT OPENING IN DUCT PLATE RETURN DUCT 90-1230 English...
  • Page 11 INSTALLATION TEMPLATE English...
  • Page 12 © 2022 AprilAire | aprilairepartners.com | 800.334.6011 AprilAire reserves the right to change specifications without notice.
