Summary of Contents for bluBathworks blu-stone BT0102.01
- Page 1 ™ Installation Guide BT0102.01 BT0305.02 BT0104.01 BT0105.01 BT0110L BT0305N15 BT0110R BT0305N17.01 BT0110L BT0110R BT0203.01 BT0402.02 BT0402N16 BT0402N17 BT0406.01 BT0408.02 BT0304.01 BT0304N17 2020-06 1 866 907 0122 blubathworks.com...
- Page 2 Product Support at 1.866.907.0122 (09:00 – 17:00hrs PST) or email technical@blubathworks.com North America Blu Bathworks Inc. 188 Smithe Street,Vancouver, BC, Canada, V6B 6A9 T +1.604.299.0122 F +1.604.299.0125 Please refer to blubathworks.com for warranty, terms & conditions under warranty & procedure for warranty service. 2020-06 1 866 907 0122 blubathworks.com...
- Page 3 • Connect the bathtub drain to the waste. Hook up the water to the faucet. Check that all connections are waterproof. NOTE: The faucet cannot be installed on the bathtub. The tub filler must be mounted either in the wall or a freestanding floor-mounted tubfiller. Read the manufacturer’s instructions for installation details. 2020-06 1 866 907 0122 blubathworks.com...
- Page 4 Attach the drain body nut on the drain body and tighten until the nut and washer have created a seal with the bottom of the bathtub. * DO NOT overtighten - wear protection - two people recommended 2020-06 1 866 907 0122 blubathworks.com...
- Page 5 Apply a bead of tub and tile caulk around the edge of the base. (Fig. 6) • Carefully set tub into position (Fig. 7) and connect the drain hardware (previously installed). Finish the installation of the tail piece. top of the tub bottom of the tub flat 2020-06 1 866 907 0122 blubathworks.com...
- Page 6 5. Apply a clear silicone bead where the tub and wall finish meet at the flange location **Blu Bathworks recommends TF.BTSB Tile Flange (Sold separately) Silicone above & below lip DETAIL I DETAIL I (exploded) 2020-06 1 866 907 0122 blubathworks.com...
- Page 7 ALCOVE INSTALLATION EXAMPLES BT0110L/R, BT0114L/R, BT0102.01, BT0104.01, BT0105.01 + BT0203.01 2020-06 1 866 907 0122 blubathworks.com...
- Page 8 For more extensive repairs, send a photograph of your blu·stone product to Blu Customer Service ™ (technical@blubathworks.com), who will inform you as to the most appropriate methods to use. limited warranty Blu Bathworks’ (“Blu”) warranty on blu·stone products covers all defects in materials and manufacturing for a period of five (5) ™...
