- Page 1 AlertMaxx2 Ground Water Installation & Operating Manual Pump Station High Level Alarm...
-
Page 2: Table Of Contents
Connecting mains power to the AlertMaxx2 10.0 Connecting pumps to the AlertMaxx2 11.0 Installing a finger float into a ground or surface water chamber 12.0 Connecting a finger float to the AlertMaxx2 unit 13.0 Activating & testing the AlertMaxx2 unit 13.1 Connecting the ribbon cable 13.2... -
Page 3: Alertmaxx2 Overview
The unit must be positioned where there is sufficient air circulation to the front and base vents. The AlertMaxx2 must not be located further than 10m from the pump/s it is being used in conjunction with. If cable extensions are required, these must be selected in accordance with BS Technical information 7671:2018 ‘Requirements for Electrical Installations’. -
Page 4: Wiring Schematic
Wiring schematic Connecting mains power to the AlertMaxx2 The AlertMaxx2 is different from a standard high level alarm, as the pump/s must be fed through the Insert 4 large cable glands into the far right hand side of the AlertMaxx2 unit. -
Page 5: Connecting Pumps To The Alertmaxx2
The finger float must raise with the rising water level! Figure 3. Connecting pumps Figure 4. Ground Water Float Switch Figure 5. Ground Water Sump (XXX) PLEASE NOTE If you are only connecting one pump to the AlertMaxx2, the PUMP PRIMARY must be used. -
Page 6: 12.0 Connecting A Finger Float To The Alertmaxx2 Unit
Once the AlertMaxx2 has been installed and fully tested, please apply one of the chamber location stickers, provided in the box, to the main label of the AlertMaxx2 fascia and one to its relevant fuse spur. This is to signify which pump station the high level alarm is connected to and which spur/s feed it. -
Page 7: Connecting External Devices
AlertMaxx2 AlertMaxx2 14.0 Connecting external devices 18.0 Error codes The AlertMaxx2 unit has volt free contacts to connect external devices such as a sounder or beacon. Code Fault Action When the alarm is activated the relay sends a signal continuously. -
Page 8: Troubleshooting
Finger float has been installed upside down. For wiring the pumps, please refer to the PowerMaxx manual. The AlertMaxx2 must be installed in series to the PowerMaxx2 – this means the AlertMaxx2 must be installed in between the PowerMaxx2 & the pump/s. - Page 9 0330 9000 999 info@ppspumps.com www.ppspumps.com Packaged Pumps Systems Ltd. Unit 11, Haslemere Industrial Estate, Pig Lane, Bishop’s Stortford, CM23 3HG...
