Argo Lab AM 40-D Pro User Manual

Safety instructions

•
During work, staff must prevent risks of:
o
Splashing and / or evaporation of liquids;
o
Emission of toxic or combustible gases.
•
Place the instrument in a suitable area, on a stable, clean, non-slip, dry and fireproof surface;
•
Do not use the instrument in explosive atmospheres, containing dangerous substances or under water;
•
Gradually increase the stirring speed;
•
The set heating temperature must always be at least 25 ° C lower than the combustion temperature of the
heated substance used;
•
Pay close attention to the risks due to:
o
Flammable materials or samples with low boiling temperature;
o
Excessive filling of samples;
o
Unsafe and / or unsuitable containers for heating;
•
Use any pathogenic samples only in closed containers;
•
Check that the instrument and accessories are in optimal condition before use. Never use damaged
components. Optimal safety and operation are guaranteed only if the instrument and accessories described
are in order. The accessories must also be firmly connected to the device;
•
The instrument can be disconnected by disconnecting it from the power supply or by disconnecting the cable;
•
The operating voltage indicated on the instrument label must correspond to that of the network to which it is
connected;
•
Make sure that the power cable does not touch the heating plate;
•
The tool can only be opened by specialized technicians;
•
Keep the instrument away from electromagnetic fields;
•
Respect the minimum distance between the device and between the device and the wall (minimum 10 cm).

Assembly of accessories

•
Attachment of the agitator to the rod
The stand must be mounted according to the instructions below. Adjust the height of the main unit and the
distance from the support rod by turning the locking device. The anti-slip protection ring can be positioned at
will along the rod.
•
Installation of the accessory
Insert the accessory shaft into the spindle and adjust the stirring depth of the blade in the container. Turn the
spindle with your fingers to fix the blade, and then tighten the spindle by turning the spindle key clockwise and
evenly.
Note:
1. The rod stirrer is a tool that can work at high speed. The system, therefore, it is necessary to properly lock the various
components, to avoid any accidental movement of the main unit or damage to people or things.
2. The support rod is a stirrer support device. The components attached to it must therefore be firmly anchored to it to
avoid any accidental movement of the main unit or damage to people or things.
User manual Mechanical rod stirrer AM 40-D Pro
•
Read the instructions carefully before use
•
Make sure that only qualified personnel use this tool
•
Do not heat easily flammable or highly volatile substances
•
Before use, make sure that the instrument is connected to an earthed socket
UM Agitatore meccanico digitale ad asta AM 40-D Pro ENG rev.0 12.05.2020
