TMG -GLS34 Product Manual

34ton tow behind log splitter
Hide thumbs

Advertisement

Quick Links

PRODUCT MANUAL
V2022.03.02
MODEL TMG-GLS34
34TON TOW BEHIND LOG SPLITTER
KOHLER
POWERED
®
Please read and understand the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
www.tmgindustrial.com
Toll Free:1-877-761-2819

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMG-GLS34 and is the answer not in the manual?

Questions and answers

Related Manuals for TMG TMG-GLS34

Summary of Contents for TMG TMG-GLS34

  • Page 1 PRODUCT MANUAL V2022.03.02 MODEL TMG-GLS34 34TON TOW BEHIND LOG SPLITTER KOHLER POWERED ® Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS General Safety Rules............................2 Parts Description And Function..........................8 Products Specifications............................9 Unpacking & Assembly........................... . 1 0 Operating the Log Splitter........................15 Maintaining the Log Splitter.......................17 Troubleshooting..........................19 PART VI: Explosion View...........................21 Conventions used in this manual WARNING This indicates a hazardous situation, which, if not avoided, could result in death or serious injury.

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING Read this Safety & Operating Instructions manual before you use the LOG SPLITTER. Become familiar with the operation and service recommendations to ensure the best performance of your machine. Labels The LOG SPLITTER carries prominent labels as reminders for its proper and safe use. Shown below are copies of all the Safety and Information labels that appear on the equipment.
  • Page 4 4014 4015 0013 4014 4011 4012 0010 4010 4013 4015 www.tmgindustrial.com 4/23 Toll Free:1-877-761-2819...
  • Page 5 Protecting Yourself and Those Around You WARNING This is a high-powered machine, with moving parts operating with high energy. You must operate the machine safely. Unsafe operation can create a number of hazards for you, as well as anyone else in the nearby area.
  • Page 6 prevent a fire hazard and properly dispose of the waste. Allow the engine to cool completely before storing in any enclosure. Never store a machine that has gas in the tank, or a fuel container, near an open flame or spark such as a water heater, space heater, clothes dryer or furnace.
  • Page 7 Never allow people who are unfamiliar with these instructions to use the Log Splitter. Allow only responsible individuals who are familiar with these rules of safe operation to use your machine. Never overload or attempt to split logs beyond the manufacturer’s recommendation. It could result in personal injury or damage to the machine.

  • Page 8: Parts Description And Function

    PARTS DESCRIPTION AND FUNCTION It may be helpful to familiarize yourself with the controls and features of your LOG SPLITTER as shown in Figure 2, before beginning these procedures. If you have any question, please contact the dealers in your area.

  • Page 9: Products Specifications

    PRODUCTS SPECIFICATIONS Splitting Force 34Ton Engine 7HP four strokes, Recoil Start Power Gasoline Control Two-hands control Wedge Height 7” Log Length Capacity 24” Log Diameter Capacity 28” Cycle Time 3 seconds(Approximate) Sprocket Rate Flywheel Max RPM Tire 16/8.0-7 H-beam height 26”...

  • Page 10: Unpacking & Assembly

    UNPACKING & ASSEMBLY 1. After unpacking, check the following components * All numbers are not part numbers in the drawings. For correct part numbers, see explosive diagram Description Main frame Tow bar Stand foot Stand foot installation Tire Operation handle Safety handle ball Wheel axle Wheel hub cover...
  • Page 11 2. Installation the axle of tire Parts no. Description Specifications Quantity Engine back-plate Wheel axle Self-lock nut Bolt M10x25 3. Installation the tire Put a larger washer (#A31) inside and outside of the wheel axle(#21), put the tire (#27) into the wheel axle,tighten the slotted nut(#A30), cotter pin(#A21) www.tmgindustrial.com 11/23...
  • Page 12 Parts no. Description Specifications Quantity Wheel axle Tire 16”/8.0-7 Cotter pin Ø4 Slot nut Larger washer Ø25-45 4. Installation the operation table and foot fixation A4, A5, A6 A4, A5, A8 www.tmgindustrial.com 12/23 Toll Free:1-877-761-2819...
  • Page 13 Parts no. Description Specifications Quantity Stand foot installation Operation table Beam Self-lock nut Spring washer Ø10 Hex bolt M10×25 Cylinder bolt M10×35 5. Installation the operation foot A4, A5 A5, A7 Parts no. Description Specifications Quantity Stand foot installation Stand foot B-pin Self-lock nut Spring washer...
  • Page 14 A1, A2 7. Installation the operation handle and safety handle ball www.tmgindustrial.com 14/23 Toll Free:1-877-761-2819...

  • Page 15: Operating The Log Splitter

    A22, A23 Parts no. Description Specifications Quantity Safety handle ball Operation handle Bolt M6×35 Self-lock nut OPERATING THE LOG SPLITTER It may be helpful to better familiarize yourself with the features of your Log Splitter by reviewing before beginning the steps outlined in this chapter. WARNING Read and understand all instructions, safety precautions, and/or warnings listed in “General Safety Rules”...
  • Page 16 Starting Position your Log Splitter on flat, dry ground, and then stop the front wheel with brake, make sure the machine cannot be moved. Make sure the fuel shut-off valve is in the “ON” position. Move the choke control lever to the “CHOKE” position (should only be needed if the engine is cold). Move the throttle control lever to the “FAST”...

  • Page 17: Maintaining The Log Splitter

    WARNING Do not place your hands on the ends of the log when loading the Log Splitter. This is a very UNSAFE method and could result in injury to your hands. Do not reach or step across the rail while the Log Splitter is running. This is a very UNSAFE method which could cause personal injury, even death.
  • Page 18 Regular Maintenance Checklist Procedure Before Each Use Every 3 Hours Every 25 Hours Every 100 Hours Check engine oil level Δ Check general equipment Δ condition Check wedge for sharpness Δ Grease surface of slide rail Δ Check belts Δ Grease rack and pinion Δ...
  • Page 19 Greasing the rack and Pinion NOTICE All the rack and pinion should be greased before every use. Replace the rack WARNING You must stop the engine before replacing the rack. Or a piece of broken iron will fly out and endanger your life.

  • Page 20: Troubleshooting

    TROUBLESHOOTING Most problems are easy to fix. Consult the Troubleshooting Table below for common problems and their solutions. If you continue to experience problems, contact the dealers in your area. WARNING Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow all parts to cool.
  • Page 21 gear or not staying Ram has been overloaded at lower part of face. Check rack gear for  in gear. straightness. Rack slamming Wedge end of machine too high. Must be almost level with ram end or just  back too fast. slightly higher.
  • Page 22 EXPLODED VIEW & PARTS LIST www.tmgindustrial.com 22/23 Toll Free:1-877-761-2819...
  • Page 23 PARTS LIST Ref.No. Description Ref.No. Description Tow hitch Pulley Chain Tire Tension wheel Wheel Dust cover Stand foot installation Belt cover Stand foot Cover Motor heat protection Operation Table Transmission shaft Tension wheel fitting Safety handle ball Spring(of gear rod) Operation handle Split head Trigger...
