PCB Piezotronics IMI Sensors 603C11/015BZ Installation And Operating Manual page 19

PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
BENDING RADIUS)
.687 [17.45] HEX
A
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010
ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH
1"≤ LENGTH < 1' = +1"/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
5'≤ LENGTH < 100' = +6"/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII
.003 - .005
2
4.7 [119]
( TO TYPICAL
.026 [.65]
DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
DECIMALS X ± 0.8
XX ± 0.25
TITLE
ANGLES  2 DEGREES
CABLE TOLERANCES IN METRIC
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
FILLETS AND RADII
0.07 - 0.13
2
REV
A
MOLDED INTEGRAL,
2 CONDUCTOR CABLE
TERMINATING IN BLUNT
CUT 10 FEET [3 METERS]
FROM APPLICATION
 
2X .672 [ 17.07]
1/4-28 UNF - 2B
 .266 [6.76]
DRAWN CHECKED
5/17/22 5/17/22
JJF JJF
OUTLINE DRAWING
INTEGRAL CABLE
603C1X, M SERIES
1
REVISIONS
DESCRIPTION
UPDATED TITLE BLOCK
RED:
SIGNAL/POWER
BLUE:
GROUND

.21 [5.3]
 .020 [0.51]
ENGINEER
5/17/22
GGS
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE: FULL
1
DIN
52852
B
A
16959
SHEET 1 OF 1
