Page 1: Table Of Contents
Safe and Efficient Use ... 19 Bluetooth Capability Statement... 24 Important Information ... 24 Declaration of Conformity ... 25 Index Ericsson HBH-10 Third edition (November 2000) This User’s Guide is published by Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this User’s Guide necessitated by...
Page 2: Introduction
Introduction The Bluetooth™ Headset HBH-10 is a cordless portable handsfree solution based on Bluetooth wireless technology. Please read the “Guidelines for Safe and Efficient Use” and “Limited Warranty” chapters before using your Headset. What is Bluetooth Wireless Technology? The Bluetooth wireless technology makes it possible to connect any compatible portable and stationary communications device without using cables.
Page 3: Using Your Headset
Using Your Headset Overview Any device that you want to use with the Bluetooth Headset has to be compatible with Bluetooth wireless technology and support the Headset Profile. To be able to use the Headset together with a mobile phone, you need to have a phone with built-in Bluetooth capability, or a phone with a Bluetooth adapter connected to it.
Page 4: Looking After The Headset
The Headset comes with a cradle, which holds the Headset during charging. The Cradle Release catch Looking After the Headset Always keep the Headset in a case or in the cradle when not wearing it on your ear. You can keep the Headset in the cradle even when not charging it.
Page 5: Putting On The Headset
Putting On the Headset Press down the lever as shown. • Put on the Headset with the ear • hook behind your ear. Make sure the microphone is • pointing towards your mouth. Right or Left Ear If you want to wear the Headset on your left ear, you have to change the orientation of the ear hook.
Page 6 Turn the hook 180 degrees. Attach the ear hook by gently pressing it into place. You also have to change the orientation of the volume button. You can do this either using the Headset, or, if using an Ericsson phone, via the menu system in the phone.
Page 7: Charging
Charging The Headset comes with a built-in rechargeable battery. The battery is not fully charged when you buy the Headset. We recommend that you charge the Headset until the indicator light turns green before using it for the first time. Put the Headset into the cradle to charge it. To remind you that you will soon need to recharge the battery, •...
Page 8 Connector pins • • • Using Your Headset Insert the Headset into the charging cradle as shown in the picture. Make sure the connector pins are aligned with the connector holes in the Headset Gently press the Headset until it clicks into place. To remove the Headset from the cradle, slide the release catch backwards and lift the Headset up.
Page 9: Disconnecting The Charger
Disconnecting the Charger Tilt the plug upwards • to remove it. Turning the Headset On or Off To turn the Headset on Press and hold the Headset button until you hear a short low tone • followed by a short high tone. The Headset indicator light flashes green.
Page 10 Using an Ericsson Phone with Built-in Bluetooth Capability You pair the Headset with your phone by adding it to a list of paired devices in the phone. They then recognize each other when they connect. To pair the Headset with the phone In the phone, scroll to Extras, Paired devices, A list of device types that you can pair with your phone is shown.
Page 11: Resetting The Headset
Using Another Device or a Non-Ericsson Phone The device or phone must have Bluetooth capability and support the Headset profile. To pair the Headset with another device Activate the Bluetooth function in the other device if necessary. To do this, please refer to the user documentation for the device. With the Headset turned off, press and hold the Headset button for up to 10 seconds until the indicator light on the Headset flashes green and red.
Page 12: Adjusting The Ring Volume
To adjust the listening volume To increase the volume, slide the Headset button up. • To decrease the volume, slide the Headset button down. • Note: must also change the orientation of the volume button. See “To change the orientation of the volume button” on page 6. Adjusting the Ring Volume You can adjust the Headset ring volume when you are not engaged in a call.
Page 13: Answering Calls
Making Calls To make a call using voice dialling Make sure the phone and the Headset are on and within range of each other. Press the Headset button once. After the beep, voice dial as you normally would. Note: If using the Bluetooth phone adapter: Say the voice label after the phone beep (not after the Headset beep).
Page 14 Transferring Sound from Phone to Headset If you make a call without using the Headset, you can transfer the sound to the Headset if the Headset is on, paired with the phone and within range. To transfer the sound to the Headset With an Ericsson phone with built-in Bluetooth capability: During •...
Page 15: Using The Phone's Extras Menu
Using the Phone’s Extras Menu If you are using an Ericsson mobile phone that supports Bluetooth wireless technology, you will find an additional set of menus under the Extras menu, when you have paired the phone with the Headset. The Headset has to be turned on and within range of the Ericsson phone.
Page 16: Adjusting The Volume
To select a device Scroll to Extras, Paired Devices, Scroll to the device you want the Headset to communicate with and press You can add devices to the list of paired devices. When you choose to add a device, Bluetooth pairing is enabled in the Headset. If the device is accepted, it is added to the list.
Page 17: Headset Battery Status
Headset Battery Status The Headset comes with a built-in battery. You can check the status of the battery. To check the battery status Scroll to Extras, Y E S Battery Status, Y E S The battery status is indicated by one of these three levels: High •...
Page 18: Additional Information
If you notice that you cannot make use of all the features in the HBH-10 Headset, please check that your Ericsson phone has the right software version. For more information, contact a Certified Service Centre or an Ericsson Service Point, or visit the HBH-10 page on http://mobileinternet.ericsson.com. Additional Information...
Page 19: Ericsson Mobile Internet
Note: Read this information before using your Bluetooth Headset. Product Care and Maintenance Your Bluetooth Headset is a highly sophisticated electronic device. To get the most out of your Headset read this text about product care, safe and efficient use.
Page 20: Radio Frequency Exposure
Radio Frequency Exposure This Bluetooth Headset contains a small radio transmitter and receiver. During a call, it communicates with the mobile phone by receiving and transmitting radio frequency (RF) electromagnetic fields (microwaves) in the frequency range 2400 to 2500 MHz.
Page 21: Potentially Explosive Atmospheres
Blasting Areas Turn off your electronic device when in a blasting area or in areas posted “turn off two-way radio” to avoid interfering with blasting operations. Construction crews often use remote control RF devices to set off explosives. Potentially Explosive Atmospheres Turn off your electronic device when in any area with a potentially explosive atmosphere.
Page 22: Battery Information
Remember that in order to make or receive calls, the Headset and the electronic device connected to it must be switched on and in a service area with adequate cellular signal strength. Emergency calls may not be possible on all cellular phone networks or when certain network services and/or phone features are in use.
Page 23 Our Warranty Ericsson warrants this Product to be free from defects in material and workmanship at the time of its original purchase by a consumer, and for a subsequent period of one (1) year. All accessories for the Product are covered by a warranty for a period of one (1) year from the date of its original purchase by a consumer.
Page 24: Bluetooth Capability Statement
THERE ARE NO OTHER EXPRESS WARRANTIES, WHETHER WRITTEN OR ORAL, OTHER THAN THIS PRINTED LIMITED WARRANTY. ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL ERICSSON BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOST...
Page 25: Declaration Of Conformity
Declaration of Conformity We, Ericsson Mobile Communications AB of Torshamnsgatan 27 S-164 80 Stockholm, Sweden declare under our sole responsibility that our product Ericsson type 8404003-BV, and Ericsson type 8505001 to which this declaration relates is in conformity with the appropriate standards ETS 300 328, ETS 300 342-1, ETS 300 826 and EN 60950 following the provisions of Radio Equipment and Telecommunication Equipment directive 1995/5/EC with requirements covering EMC...
Page 26 Additional Information...
Page 27: Index
Index Adjusting listening volume 12, 16 ring volume 12, 16 Answering calls 12, 13 Battery charging 7 status 17 use and care 22 Calls answering 12, 13 making 12, 13 transferring sound 12, 14 Cases 4 Changing headset name 17 orientation of ear hook 5 passkey/PIN 17 volume 11...
Page 28 Resetting the headset 11 Ring volume 12, 16 Selecting device 15 Speaker 3 volume 12 Transferring sound 12, 14 Troubleshooting 18 Turning on/off headset 3 Voice dialling 13 Volume adjusting 11 listening 12, 16 ring 12, 16 Volume button changing orientation 6, 15 Warranty 22 Wearing headset 5...
