List of contents 1 Technical description of the radio modem AMB8350 ............3 2 Pin connections, dimensions, technical data..............4 2.1 Pin connections of the pin connector ST1............... 4 2.2 Antenna input........................4 2.3 Status LEDs........................5 2.3.1 Meaning of the LEDs........................5 2.3.2...
1 Technical description of the radio modem AMB8350 With the design of the new data radio modem AMB8350 we are continuing on the consistent path of implementing customer wishes and using new, powerful processors. New functions have been integrated in the AMB8350, which simplify the connection to existing systems. The radio modem AMB8350 is compatible with OPC1426 and is consequently both a complement and replacement.
2 Pin connections, dimensions, technical data Solder bridge SJ1 LED Antenna connection 2.1 Pin connections of the pin connector ST1 The pitch distance of the pin connectors is 2.54mm. AMB8350 pin connector ST1 PC SUB-D-9 w Direction Name Meaning Name No function Ground Supply voltage +(4,0...10,0)V...
The LED signals are located additionally on the multi-point connector ST4 so that, for instance, LEDs can be externally mountable. If external LEDs are used, the LEDs on the AMB8350 must be switched off to avoid overloading the ports of the controller. To switch off the LEDs the solder bridge SJ1 (see illustration above) must be removed.
** The user is responsible of the duty cycle compliance, the choice of the transmitting frequency and the adjustment of the transmitting power in accordance with the table in chapter 2.5.3. AMB8350 Manual V1.2 Page 6 of 21 As of: 9.2.2007...
869.621 MHz 27 dBm authorised Note on duty cycle classes according to EN300220-1 DC class 1: <0.1% DC class 2: <1.0% DC class 3: <10% DC class 4: up to 100% AMB8350 Manual V1.2 Page 7 of 21 As of: 9.2.2007...
1. AT instruction set with a terminal program (chapter 3) see also external document “Hyperterminal_HB” (short description) 2. “AMBER wireless Config Center” Windows-Tool ACC (chapter 4) see also external document “ACC_HB” In handling the module the ESD regulations must at all costs be observed to avoid damage through static discharge! AMB8350 Manual V1.2...
For this the correct interface parameters in the terminal program are a precondition. The data format, the data rate and the handshake must be set as in the AMB8350 (on this see the external short description “Hyperterminal_HB”).
Issue product information (0-9) ATI2 Product-specific information can be identified with this command. Product identification Product ID : AMB8350 Information on manufacturer Vendor ID : AMBER wireless GmbH Germany Soft- and hardware release Software release: 1.1.0 Empty Empty Empty Empty...
Page 11
Default setting: 80 (typ. 20mW) Software reset of modem A software reset of the modem is carried out with this command, similar to switching the modem on and off again. AMB8350 Manual V1.2 Page 11 of 21 As of: 9.2.2007...
Default setting: 20 S4=x Tx Time delay (in ms) (0-255) ATS4=5 for operating modes 2-5 only Time after which characters are transmitted wirelessly (regardless of how many are buffered). Default setting: 5 AMB8350 Manual V1.2 Page 12 of 21 As of: 9.2.2007...
Page 13
The default ETX sequence consists of the characters first byte dec 13 (0x0D = control character CR) and second byte dec 10 (0x0A = control character LF). Enter decimal values when choosing one or two new ETX characters. Default setting: 13, 10 AMB8350 Manual V1.2 Page 13 of 21 As of: 9.2.2007...
(monitoring function). Note: This setting takes effect the next time radio transmission is activated (ato) • The setting is stored permanently with the AT&W command • Default setting: 1 AMB8350 Manual V1.2 Page 14 of 21 As of: 9.2.2007...
Page 15
: 80 atp80 Escape Char ats5=+ Char Delay : 20 ats3=20 Time Delay ats4=5 End Delimiter first Byte : 13 ats7=13,10 (0d) End Delimiter second Byte : 10 ats7=13,10 (0a) AMB8350 Manual V1.2 Page 15 of 21 As of: 9.2.2007...
4 Configuration with “AMBER wireless Config Center” (ACC) The AMBER module can be configured per RS232 using the PC software ACC. The RxD, TxD and GND lines are required. In contrast to parameterisation with AT commands in the terminal program, the RS232 interface parameters for communicating with ACC, as configured in the module, have no effect.
ETX sequence is found. In cases where this is not desirable, the “Tx Time delay ms” selected must be large enough (see S-Register 4). The S-Register 7 is used to change the ETX characters in the sequence. AMB8350 Manual V1.2 Page 17 of 21 As of: 9.2.2007...
If a data connection link exists between two outside devices, data traffic is permanent and RTS remains at low. AMB8350 Manual V1.2 Page 18 of 21 As of: 9.2.2007...
Data flows transmitted to the RS232 can be sent in fragments by the radio module owing to the division into radio data packets and output in fragments at the receiving RS232. AMB8350 Manual V1.2 Page 19 of 21 As of: 9.2.2007...
7 Statement of compliance Approval tests in progress The transceiver can be used throughout the EU AMB8350 Manual V1.2 Page 20 of 21 As of: 9.2.2007...
