- Page 1 INSTALLATION AND CARE GUIDE STAINLESS STEEL SINK FOR UNDERMOUNT INSTALLATION...
- Page 3 CONGRATULATIONS ON THE ACQUISITION OF YOUR NEW HOME REFINEMENTS SINK. At Home Refinements, all our products are manufactured with the greatest care and have been tested to ensure their highest quality. Each sink model has been created to enhance the functionality and aesthetics of your kitchen.
-
Page 4: Table Of Contents
TABLE OF CONTENTS BEFORE YOU START PRECAUTIONS CLEANING MAINTENANCE INSTALLATION OF AN UNDERMOUNT SINK WARRANTY PLAN AHEAD COUNTERTOP SELECTION AND MOUNTING INSTALLATION TYPE STEPS 1 TO 5 INSTALLATION OF A SINK WITH A LA CARTE OPTIONS APRONFRONT BUILT-IN DRAINBOARD BUILT-IN DRAWER UNDERMOUNT REVEAL INSTALLATION UNDERMOUNT REVEAL FOR SMARTSTATION... -
Page 5: Before You Start
For best results, enlist the help of a professional installer to cut the countertop, install the sink, and connect it. Improper installation will invalidate the warranty. Julien recommends that the sink be installed in such a way that it can be removed without damaging the countertop. -
Page 6: Installation Of An Undermount Sink
INSTALLATION OF AN UNDERMOUNT SINK PLAN AHEAD Make sure the inside width of the cabinet (side to side) is a minimum of the overall left-to-right sink dimension + 2" to allow for bracket installation. Make sure enough space is left behind the sink for faucet clearance. A printed cutout template is supplied with the sink and a digital format is available online at homerefinements.ca*. -
Page 7: Countertop Selection And Mounting
COUNTERTOP SELECTION AND MOUNTING STONE, QUARTZ OR SOLID SURFACE Stone, quartz or solid surface Pre-drilled hole Silicon Threaded insert Sink Bracket* Overhanging countertop approx. 1/8" or Self-tapping screw recessed installation REV10 (3/8") * Included STONE, QUARTZ OR SOLID SURFACE WITH WOOD BACKING Stone, quartz or solid surface Wood backing Pilot hole... -
Page 8: Installation Type
Our standard installations will guarantee a perfect fit with our sink accessories. *Excludes À la Carte Home Refinements sinks ordered with the REV option. In this case, please refer to the cutout template supplied. UNDERMOUNT REVEAL OPTION**... - Page 9 STEPS 1. Cut your countertop according to the template*. Plan ahead for threaded insert holes if you are installing your sink in a stone countertop. Consider using the digital template available on our website. To ensure you choose the right countertop cutting tools, refer to your supplier.
- Page 10 FINISHING UP The drains offered by Home Refinements are specially designed to ensure the sink optimum drainage. We also offer a full range of faucets and accessories to complete your dream kitchen. Please refer to your sink dealer or visit homerefinements.ca to discover our product offering.
-
Page 11: Installation Of A Sink With A La Carte Options
APRONFRONT UAF / UAC Home Refinements apronfront sinks are designed for a 3/4" reveal installation on the rear ledge, ensuring an optimal fit of our Home Refinements accessories on the sink ledge. 1/8'' 3/4'' * Method A can also be used on the rear ledge for installation without accessories. -
Page 12: Apronfront
Apronfront sinks can be installed in several ways. If you decide to use a method other than the one recommended by Home Refinements, the countertop cutout will be different from the one illustrated in this installation guide. Faucet clearance... - Page 13 2. Fasten the frame to the cabinet, leaving 1/16” free above it and ensuring it is level. 1/16'' [1,5 mm] Cabinet Frame 3. Place the sink on the frame. Sink 4. Measure the countertop. Refer to the sink to determine the cutout required for your desired installation. 1 1/2"...
-
Page 14: Built-In Drainboard
BUILT-IN DRAINBOARD DB1XX / DB2XX Use the diagram below to determine the dimension you need to add to the cutout template of the sink model you chose depending on the width of the drainboard you selected. Only the width will be affected by this change. The front-to-back dimension of the cutout will remain the same. -
Page 15: Undermount Reveal Installation
If you’ve chosen a sink with a reveal option, add 7/8” (22 mm) to the front and back of the cutout template for your base sink model. Center your sink in the cutout with a space of 3/4” at the front and back so you have room for your Home Refinements accessories. The cutout width remains the same. 3/4" [19 mm] 7/8"... -
Page 16: Top-Mount/Flushmount
TOP-MOUNT/FLUSHMOUNT If you’ve chosen a sink with a top-mount installation option, add 5/8” to the front, back, and sides of your base sink model’s cutout template. 5/8'' Top-mount sink [16 mm] 5/8'' [16 mm] Cutout template for sink model without options Cutout for top-mount installation HOLE(S) FOR FAUCET AND ACCESSORIE(S) Ensure you have your sink to validate the hole location before drilling your countertop. -
Page 17: Divider
DIVIDER If you have chosen a sink with a 1"-wide divider option, follow the regular installation method for an undermount installation. For a 4"-wide divider, use the diagram below to modify the cutout template for your base sink model. 3" [76 mm] Variable 4"... -
Page 18: Precautions
CLEANING Daily cleaning : Julien recommends using Julien Cleaner and Polish, available at your sink retailer, for best results. Otherwise, use a well-wrung-out damp cloth, previously soaked in soapy water, and wipe toward the metal grain. Rinse with clear water and dry. -
Page 19: Maintenance
Attention The warranty will be null and void for any damage resulting from an installation that does not comply with these instructions, and Julien will not be held responsible for any costs incurred. In the event of a limited warranty claim, original proof of purchase will be required—save the original sales receipt. - Page 20 955, rue Lachance, Quebec (Quebec) Canada G1P 2H3 T 1 866 901-5624 · 418 687-3630 | F 1 866 397-9090 · 418 687-9129 homerefinements.ca...
