Castex PX-1000 Operator And Parts Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model No.:
607781
607794 - PAC
TENNANT COMPANY
701 NORTH LILAC DRIVE
MINNEAPOLIS, MN 55422
MAILING ADDRESS:
TENNANT COMPANY
P.O. BOX 1452
MINNEAPOLIS, MN 55440- -1452
CASTEX CUSTOMER SERVICE:
1- - 800- - 365- - 6625
FAX: 1- - 800- - 678- - 4240
TECHNICAL SUPPORT:
1- - 800- - 522- - 7839 EXT. 5356
Home
Find... Go To..
PX-1000
Portable Carpet Extractor
Operator and Parts Manual
Rev. 01 (03-04)
608052

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PX-1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Castex PX-1000

Summary of Contents for Castex PX-1000

  • Page 1 701 NORTH LILAC DRIVE MINNEAPOLIS, MN 55422 MAILING ADDRESS: TENNANT COMPANY P.O. BOX 1452 MINNEAPOLIS, MN 55440- -1452 CASTEX CUSTOMER SERVICE: 1- - 800- - 365- - 6625 FAX: 1- - 800- - 678- - 4240 608052 TECHNICAL SUPPORT: Rev. 01 (03-04) 1- - 800- - 522- - 7839 EXT.

  • Page 2: Table Of Contents

    E 1999, 2004 Tennant Company Printed in U.S.A. subsidiaries. Castex is a registered United States trademark of Tennant Company. This machine will provide excellent service. However, the best results will be obtained at minimum costs if: The machine is operated with reasonable care.

  • Page 3: Safety Precautions

    Unplug cord from wall outlet. be replaced by the manufacturer or it’s service agent or a similarly qualified person in order to avoid a hazard. WARNING: Do Not Use Outdoors. Do Not Expose To Rain. Store Indoors. PX-1000 (03- -04) Home Find... Go To..

  • Page 4: Grounding Instructions

    3 Hole Outlet Ground Pin SAFETY LABEL The safety label appears on the machine in the location indicated. Replace label if it becomes damaged or illegible. WARNING LABEL - - Located on back of machine. PX-1000 (03- -04) Home Find... Go To..

  • Page 5: Machine Components

    406mm (16 in) Floor Tool (optional) 7. Main Power ON/OFF Switch 15. 7.6m (25 ft) Power Supply Cord 8. Power Supply Cord Pigtail 16. Power Supply Cord Hook 9. Recovery Tank Drain Hose PX-1000 (03- -04) Home Find... Go To..

  • Page 6: Machine Setup

    4. Replace lid securely after filling. machine mobility while operating cleaning tool. 5. Connect the supplied extension cord to machine. Plug cord into a grounded wall outlet (Figure 2). Grounded 3 Hole Outlet Ground Pin FIG. 2 PX-1000 (03- -04) Home Find... Go To..

  • Page 7: Machine Operation

    Cord Before Servicing Machine. If the supply cord is damaged or broken, it must be replaced by the manufacturer or it’s service agent or a similarly qualified person in order to avoid a hazard. PX-1000 (03- -04) Home Find... Go To..

  • Page 8: Optional Hand Tool Operation

    5. When finished cleaning, turn off switches and drain recovery tank (See DRAINING RECOVERY TANK). 6. After cleaning, relieve water pressure from tool before disconnecting hose. Squeeze trigger for five seconds after turning main power switch off. FIG. 10 PX-1000 (03- -04) Home Find... Go To..

  • Page 9: Draining Solution Tank

    2. Remove and clean float shut--off screen, located in up to six hours. Do not use pointed objects to recovery tank (Figure 12). unplug tips, damage will occur (Figure 15). FIG. 12 FIG. 15 PX-1000 (03- -04) Home Find... Go To..

  • Page 10: Monthly Maintenance

    Allow solution to remain in system for up to 6 hours in above freezing temperatures. Later, spray out solution into a bucket or drain. Then run 11 L (3 gal) of clean water through system to flush out impurities. PX-1000 (03- -04) Home Find... Go To..

  • Page 11: Storing Machine

    Install valve rebuild kit or contact Service Center. Hose split or fittings loose. Replace hose and tighten fittings. Quick coupler and plug not fully Reconnect quick coupler. engaged. Valve stem worn. Replace or contact Service Center. PX-1000 (03- -04) Home Find... Go To..

  • Page 12: Specifications

    120 volt, 3--stage, 1.66 hp, 13 amp, 1513 watts SEALED WATER LIFT 3.5m (137 in) DECIBEL RATING AT OPERATOR’S EAR, INDOORS ON 80dB(A) CARPET MACHINE DIMENSIONS 1054.1 mm (41.5 in) 965.2 mm (38.0 in) 330.2 mm (13.0 in) PX-1000 (03- -04) Home Find... Go To..

  • Page 13: Electrical Diagrams

    ELECTRICAL DIAGRAMS 120V WIRING DIAGRAM BLACK BLACK WHITE MAIN SWITCH GREEN HANDLE CORD POWER 14- -4 CORD BLACK GREEN VACUUM GREEN MOTOR SOLUTION PUMP PX-1000 (03- -04) Home Find... Go To..

  • Page 14: Parts List

    PARTS LIST RECOVERY TANK GROUP PX-1000 (03- -04) Home Find... Go To..
  • Page 15 1008639 DASM., CAP, DRAIN HOSE 601349 TANK, RECOVERY BLUE 1008637 DO- -RING, 1.48”ID X 1.76”OD 120101 LABEL, LOGO CASTEX WHT MED 614157 CLAMP, HOSE 27MM TO 51MM 608053 DECAL, PX-1000 SIDE ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS...

  • Page 16: Chassis Group

    PARTS LIST CHASSIS GROUP PX-1000 (03- -04) Home Find... Go To..
  • Page 17 CLAMP, HOSE 1- -5/16 TO 2- -1/4 140015 WASHER, LOCK SPLIT .31 230390 HINGE, SOL. REC. TANK 231026.BK HANDLE, LIFT WELDMENT BLACK 140885 SCREW, TRS .25- -20 X 0.50 PHL D RECOMMENDED STOCK ITEMS PX-1000 (03- -04) Home Find... Go To..

  • Page 18: Control Console Group

    PARTS LIST CONTROL CONSOLE GROUP PX-1000 (03- -04) Home Find... Go To..
  • Page 19 SCREW, TRS .25- -20X0.50 PHL 130227 DCORD, 14/3X20” YELLOW 130040 TIE, WIRE 6”X.12 NY SMOOTH 130166 DGRIP, STRAIN-RELIEF W/NUT 602616 CORD, 16/3X47 BLACK ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS N/S = NOT SHOWN PX-1000 (03- -04) Home Find... Go To..

  • Page 20: Pump Breakdown

    DKIT, PRESSURE SWITCH 190124 DKIT, CHECK VALVE ONLY 190172 DKIT PRESSURE SWITCH (VITON) 190171 DKIT, VALVE (VITON) 190134 DKIT, DIAPHRAGM ONLY 190131 DKIT, SERVICE D RECOMMENDED STOCK ITEMS 190130 DKIT, LOWER PUMP HOUSING PX-1000 (03- -04) Home Find... Go To..

  • Page 21: Options

    TOOL, CREVICE BLACK 160106 HOSE, SOLUTION 200975 DFITTING, TIP #5002 V- -JET 150100 FITTING, 1/4MX1/8F BUSHING 210014 DVALVE, TOGGLE W/NUT 150913 FITTING, 1/4F QD FML COUPLER ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS PX-1000 (03- -04) Home Find... Go To..

  • Page 22: 330Mm (13 In) Low Pressure Wand Group

    OPTIONS 330mm (13 in) LOW PRESSURE WAND GROUP PX-1000 (03- -04) Home Find... Go To..
  • Page 23 DFITTING, TIP 11003 T- -JET 150403 FITTING, E45 04PM/04PF 200994 DCAP, NOZZLE, SPRAY #8002 150913 DFITTING, QDC PF04 SER. 60 150615 FITTING, 04PM CLOSE ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS PX-1000 (03- -04) Home Find... Go To..

  • Page 24: 406Mm (16 In) Low Pressure Wand Group

    OPTIONS 406mm (16 in) LOW PRESSURE WAND GROUP PX-1000 (03- -04) Home Find... Go To..
  • Page 25 FITTING, E45 04PM/049F 200964 DFITTING, TIP 11003 T- -JET 150913 DFITTING, QDC PF04 SER. 60 200994 DCAP, NOZZLE, SPRAY #8002 150615 FITTING, 04PM CLOSE ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS PX-1000 (03- -04) Home Find... Go To..

  • Page 26: Upholstery Tool Group

    874966 DALL IN ONE CLEANER, 1/2GAL 6 BOTTLES PER CASE 874958 DALL IN ONE CLEANER, 1GAL 4 BOTTLES PER CASE ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS N/S = NOT SHOWN PX-1000 (03- -04) Home Find... Go To..

  • Page 27: Solution And Vacuum Hoses Group

    DCUFF, HOSE 1- -1/2” 150933 PLUG, QUICK COUPLER 160451 DCONNECTOR, 1- -1/2” VAC HOSE 150615 NIPPLE 220040 DBAG, HOSE W/DRAW STRING (OPTIONAL) ∇ ASSEMBLY INCLUDED IN ASSEMBLY D RECOMMENDED STOCK ITEMS N/S = NOT SHOWN PX-1000 (03- -04) Home Find... Go To..
