Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 1
Original operating instructions
Petrol Chainsaw
Art.-Nr.: 45.016.36
I.-Nr.: 11013
BPC 1235/1

Advertisement

loading

Related Manuals for Bavaria 45.016.36

Summary of Contents for Bavaria 45.016.36

  • Page 1 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 1 Original operating instructions Petrol Chainsaw Art.-Nr.: 45.016.36 I.-Nr.: 11013 BPC 1235/1...
  • Page 2 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 2 Read and follow the operating instructions and safety information before using for the first time.
  • Page 3 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 3...
  • Page 4 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 4...
  • Page 5 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 5...
  • Page 6 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 6...
  • Page 7 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 7...

  • Page 8: Table Of Contents

    Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 19 Table of contents: 1. Safety regulations 2. Layout 3. Intended use 4. Technical data 5. Before starting the equipment 6. Operation 7. Cleaning, maintenance, storage and ordering of spare parts 8. Disposal and recycling 9. Troubleshooting guide...

  • Page 9: Layout

    Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 20 Safety features (fig.1) Important! LOW KICKBACK SAW CHAIN helps significantly When using equipment, a few safety precautions reduce kickback, or the intensity of kickback, due must be observed to avoid injuries and damage. to specially designed depth gauges and guard Please read the complete operating manual with due links.

  • Page 10: Technical Data

    Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 21 4. Technical data Keep the noise emissions and vibrations to a minimum. Only use appliances which are in perfect working order. Maximum engine capacity 1.2 kW Service and clean the appliance regularly. Adapt your working style to suit the appliance. Max.
  • Page 11 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 22 lever when, as in the event of kickback, operator’s not slip off the bar when you do this. Tighten the hand strikes the lever. When the brake is actuated, two nuts by hand and then follow the instructions chain movement stops abruptly.

  • Page 12: Operation

    Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 23 5. Push in the throttle lever (B) as far as it will go (Fig. 9B). 6. Hold saw firmly and pull starter rapidly 4 times. Engine should start (Fig. 9D). 7. Let the engine run for 10 seconds to warm up. Press the throttle lever (D) briefly, the engine will go to “idling”...
  • Page 13 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 24 Warning: Do not cut down a tree during high or Warning: Never cut tree limbs while standing on changing winds or if there is a danger to property. tree trunk. t l u . l a there is a danger of striking utility wires;...

  • Page 14: Cleaning, Maintenance, Storage And Ordering Of Spare Parts

    Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 25 7. Cleaning, maintenance, storage and 7.2.2 Air filter ordering of spare parts Warning: Never operate saw without the air filter. Dust and dirt will be drawn into engine and . t i t l i f t l i f Disconnect the spark plug boot before doing any be cleaned or replaced after every 20 hours of...
  • Page 15 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 26 service. 4. Rotate saw chain by hand. Repeat lubrication 1. Set the On/Off switch to Stop (0)”. procedure until the entire sprocket tip has been greased. 2. Remove the top cover (A) by undoing the cover fastening screw (B) on the cover.
  • Page 16 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 27 the guide bar. To check the chain lubrication, hold the chain saw, Never starve the bar and chain of lubricating oil. with the chain, over a piece of paper and run it at full Running the saw dry or with too little oil will decrease speed for a few seconds.

  • Page 17: Disposal And Recycling

    Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 28 8. Disposal and recycling The unit is supplied in packaging to prevent its being damaged in transit. This packaging is raw material and can therefore be reused or can be returned to the raw material system. The unit and its accessories are made of various types of material, such as metal and plastic.

  • Page 18: Troubleshooting Guide

    Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 29 9. Troubleshooting guide Problem Probable cause Corrective Action Unit won’t start or starts but will not Incorrect starting procedures. Follow instructions in the User run. Manual. Incorrect carburetor mixture Have carburetor adjusted by an adjustment setting. Authorized Service Center.
  • Page 19 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 30 The guarantee provided in this Guarantee Certificate is given by Einhell Australia Pty Limited ACN 134 632 858 of 6/166 Wellington Street, Collingwood, Victoria (Telephone number 1300 922 271) (Einhell Express Guarantee). CERTIFICATE GUARANTEE Dear Customer, All of our products undergo strict quality checks.
  • Page 20 Anleitung_BPC_1235_1_SPK7__ 06.05.13 08:58 Seite 31 EH 07/2013 (01)
