- Page 1 K K K K K K K C OOKER HOOD INSTRUCTON MANUAL Read this manual carefully before operation Pictures in this manual are for reference only, the product in kind prevail. S 260 INOX...
- Page 2 Information and advice Model E：220-240V~/50Hz ES 260 INOX In certain circumstances electrical appliance may be a danger hazard. A) There shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels.
- Page 3 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 4 U) Regarding the instructions for the blub replacement, thanks to refer to the section “Replacing Bulb”. Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. The appliance uses 4 hob elements at most. CAUTION: Accessible parts may become hot when used with cooking appliance.
-
Page 5: Installation
Installation Ensure the power has been turned off before beginning this installation. Plug must be assembled in places easy to drag and insert . To install this hood you will require two assistants. You will need the following tools and material to complete this installation: *Drill*Flat head screwdriver *Phillips head screwdriver or cordless drill and Phillips head bit*Tin snip*... - Page 6 of hood in the cabinet. The wood strips should be line up with the 4 keyholes slots on the top of the range hood. On the cabinet, install 4 screws (supplied) according to the relative position of 4 key holes on the bottom of hood. The extent of screwing should be convenience to the next installation.
- Page 7 Method 2 In the installation surface in cabinet don’t adapt to install the cooker hood, then as per fig, fix the position of cooker hood on the wall. On the wall, install 2 screws(supplied) according to the relative position of 2 key holes on the back of hood.
- Page 8 Check valve Installation Hold on check valve with your hands, align the box gap, put in the check valve , and then spin to a certain angle until three angl es of the valve are stuck. Installation is complete. Carbon Filter Activated carbon filter can be used to trap odors.Normally the activated carbon filter should be changed at three or six month s...
- Page 9 Hood Using Method Operation Check beforehand Check the safe condition of the appliance： - Check whether there are visible defects. - Check that all parts of the appliance have been securely fitted. Switching on/off - Slide the front part of the cooker hood.(For some models) ·...
-
Page 10: Cleaning Instruction
Replacing Bulb Replacing Bulb: 1.Switch off the extractor hood and isolate the extrator hood by pulling out the mains plug or switching off the fuse. 2.Remove the grease filter. 3.Replace the lamp(commercially available filament lamps (max. atts) 4.Reconnect the power by inserting the mains plug or by switchingonthe fuse. Max Power Voltage Picture... - Page 11 It is recommendable to clean the metallic filter every three months by carrying out the following instruction: —Remove the metallic filter from the cooker hood and wash it in a solution of water and neutral liquid detergent, leaving to soak —Rinse thoroughly with warm water and leave to dry.
- Page 12 The manufacturer shall decline all responsibility if the foregoing recommendations and instruction regarding installation, maintenance and use are not observed and respected when using the cooker hood. P/N:16173000A10914...
