- Page 1 CG180 OPERATING INSTRUCTIONS...
-
Page 2: Declaration Of Conformity
Valid for machines with serial number from: 20150000 Storage location of the technical documents: Saint-Gobain Abrasives 190, Bd. J. F. Kennedy 4930 BASCHARAGE, LUXEMBOURG This declaration of conformity loses its validity when the product is converted or modified without agreement. -
Page 3: Important Safety Instructions
ENGLISH Important Safety Instructions Important instructions and warning notices are allegorized on the machine by means of symbols: Before you start working, read the operating instructions of the machine. Work concentrated and carefully. Keep your work-place clean and avoid dangerous situations. - Page 4 Specifications Concrete Grinder CG 180 Rated voltage 230 V Power input 2500 W Frequency: 50 - 60 Hz Rated speed: 6000 rpm No-load speed: 9500 rpm Max. disc diameter: 180 mm Spindle: Ø 22,2mm Protection class: Degree of protection: IP 20 Net weight: about 8,4 kg Interference suppression:...
- Page 5 Do not use the tool in an environment with danger of explosion. Do not grin into asbestos-containing materials. Modifications of the tool are prohibited. Never use the machine without dust guard. Use machine with partly removed dust guard in corners only. For other applications the dust guard must always be closed.
- Page 6 Attention! The tool still runs for a little while after the machine was switched off. For further safety instructions, please refer to the enclosure! Electrical Connection Before starting the machine check the correspondence between voltage and frequency according to the data mentioned on the identification plate. Voltage differences from + 6 % and –...
- Page 7 For grinding works right into edges of the wall one segment of the dust guard can be removed by means of the chucking device. This allows grinding on surfaces which are usually hard to reach. For it loosen both wing screws and pull the segment off (see fig. below). Attention! All other grinding works have to be done with the complete closed dust guard.
- Page 8 The assembly works the other way round! After mounting the grinding wheel, let the machine run for a short period of time and in a safe position. If the machine does not run easily, stop working immediately. Use only original accessory! Overload Protection In order to protect the operator, motor and drill bit, the concrete grinder is equipped with an electronic and thermal overload protection.
- Page 9 The tool’s plastic components are marked according to their material, which makes it possible to remove environmental friendly and differentiated because of available collection facilities. Only for EU countries Do not dispose of electric tools together with household waste material! In observance of the European Directive 2012/19/EU on waste electrical and electronic equipment and its implementation in accordance with national law, electric...
- Page 10 Certain kinds of dust are classified as carcinogenic such as oak and beech dust especially in conjunction with additives for wood conditioning (chromate, wood preservative). Material containing asbestos must only be treated by specialists. Where the use of a dust extraction device is possible it shall be used. To achieve a high level of dust collection, use industrial vacuum cleaner dust class M for wood and/or minerals together with this tool.
- Page 11 VERS.2017.06.10 CG180_MAN_EN...
