NORTON
Owner's Manual & Safety Instructions
Die Grinder –
25,000 MAX RPM (0.9 HP)
Please read, understand and follow all the instructions and safety information prior to use. Keep
these instructions for future reference.
This tool is intended for use in industrial applications by trained professionals in accordance with
the instructions in this manual. The die grinder is designed for use with specialties like cartridge
rolls, small diameter flap wheels, mounted points, carbide burrs and Bear-Tex® unified wheels.
This is an UNGUARDED tool and should NEVER be used with cut-off discs or other bonded
abrasive grinding wheels. Never use any accessory that has a MAX RPM rating less that the
RPM marked on the tool.
WARNING
Failure to read, understand
and follow all the safety warnings and
instructions may result in serious injury.
Important Safety Information
Intended Uses
- 1 -
Advertisement
Table of Contents
Related Manuals for SAINT-GOBAIN Norton 69957308000
Summary of Contents for SAINT-GOBAIN Norton 69957308000
- Page 1 NORTON Owner’s Manual & Safety Instructions Die Grinder – 25,000 MAX RPM (0.9 HP) Important Safety Information Please read, understand and follow all the instructions and safety information prior to use. Keep these instructions for future reference. Intended Uses This tool is intended for use in industrial applications by trained professionals in accordance with the instructions in this manual.
- Page 2 WARNING Failure to read, understand and follow these safety warnings and instructions may result in serious injury or death to the operator and/or bystanders. General safety rules contain chemicals known to cause cancer and birth defects. Examples are: lead from lead based paint, crystalline silica Only qualified and trained operators should install, adjust or from cement and masonry products, arsenic and chromium use the power tool.
- Page 3 Operating / Maintenance Instructions Keep tool clean after each use. Before each use: Follow all local and federal regulations for the disposal of Always operate, inspect and maintain tool in accordance waste. with all regulations (local, state, federal and country), that Only use accessories recommended by the tool may apply to hand held pneumatic tools.
- Page 4 Specifications/Conformance Instructions Model number 69957308000 Type of tool Die Grinder Dimension 7x2x3” (180x48x75mm) Weight of tool 1.76 lbs. (0.8kg) Compressed air Maximum permissible operating pressure 6.2 bar (90psi) Recommended operating pressure 6.2 bar (90psi) Free Speed 25000 rpm Air Consumption @ 90psi 116 l/min (4 CFM) Noise values according to EN ISO 15744 A-weighted sound pressure level at workstation...
