FTX OUTBACK FURX 2.0 Instruction Book page 7

5. TUNING THE STEERING TRIM
STEERING TRIM KNOB
Gently pull the trigger to allow your car to run slowly.
Meantime, tune the steering trim to allow the front
wheels to be aligned.
6. TUNING THE THROTTLE TRIM
THROTTLE TRIM KNOB
Throttle Trim is used to set the idle speed of the car.
7. TO TUNE THE STEERING DUAL RATE CONTOL DIAL
STEERING D/R KNOB
This dial adjusts the overall travel of the steering servo.
Push the dial forward for maximum steering.
Pull the dial back to reduce
the steering level.
Set the Steering Dual Rate Control Dial to minimum first.
To set the desired steering wheel level increase it again whilst
decelerating your vehicle.
8. STEERING/THROTTLE REVERSE
STEERING REVERSE: Allows you to electronically switch the
direction of steering servo travel. For example, if you move the
steering wheel to the right and the steering servo moves to the
left, flip the the Sterring Reverse switch to make the steering
servo to the left.
THROTTLE REVERSE: Allows you to electronically switch the
direction that the motor operates in relation to the throttle
trigger. For example, if you pull the throttle trigger to accelerate
forward but the model goes in reverse, flip the Throttle Reverse
switch to make the model accelerate forward.
RUNNING YOUR CAR
DECREASE
INCREASE
STEERING
THROTTLE TRIM
STEERING D/R
CH2 Throttle D/R
CH1 Steering
Speed Switch
Reverse Switch
Set/Bind Button
CH1 Steering Trim
Power Switch
7
CH2 Throttle Reverse
Switch
LED Indicator
CH2 Throttle Trim
CH1 Steering D/R
