Summary of Contents for SANKI S-CON MINI SCLV
- Page 1 S-CON MINI ® Horizontal Entrance Type BELT REPLACEMENT OPERATING AND SERVICE MANUAL SCLV model SZLV model...
- Page 2 Thank you very much for purchasing our S-CON MINI Series. To use the machine ® properly, please read this operating and service manual carefully before use. Keep the manual where the machine is installed, so that it may be referred to when needed.
- Page 3 Upon delivery of this product, check the package contents to ensure the product matches your order. If the delivered items do not match your order, please contact our local agent directly before use. Head Drive Center Drive (SCLV) (SZLV) Serial number and model label Serial number and model label (affixed on side of drive unit) (affixed on underside of chain cover)
- Page 4 BELT REPLACEMENT 1. DISASSEMBLING BENT UNIT ① For head drive type SCLV model: ① On both sides of conveyor, loosen hexagon socket flush head bolts. Loosen ① belt by turning right and left take-up bolts. ① For center drive type SZLV model: ①...
- Page 5 ⑥ On both sides of conveyor, remove hexagon socket head cap screws. (Bend ⑥ pulley will then be released.) ⑦ Pull out bend pulley from the hole. ⑥ (See “Point for pulling out bend pulley” below.) ⑧ Pull up belt. ⑨...
- Page 6 2. BELT REPLACEMENT OF HEAD DRIVE TYPE SCLV MODEL ⑩ Remove side cover. ⑪ Remove side plate in order below: ⑪-A Remove fixing plate attachment bolt (1 bolt on side plate). ⑪-B Remove side plate attachment bolts (2 bolts). ⑪-C Remove brace attachment bolts (2 bolts). ⑪-D Remove stand attachment bolts (2 bolts).
- Page 7 3. BELT REPLACEMENT OF CENTER DRIVE TYPE SZLV MODEL ⑩ Remove under covers on knob side and motor side. →See fig. 1. ⑪ Remove side cover L. ⑫ Remove all the return rollers. (The number of return rollers depends on machine length.) ⑬...
- Page 8 Contact us ● Particular attention is given to the manufacture and transportation of SANKI conveyors. However, if you need any information about the use or failure of the machine or any other matters, please contact our customer service. Also do not hesitate to ask us for information about conveyors in general.
