INSTALLATION AND OPERATION MANUAL
5000
(OP00050 model)
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION REQUIREMENTS IN YOUR AREA.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET FUEL-
BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN
PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3
After-sale service: 418-908-8002
This manual is available for free download on the manufacturer's web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may update this manual from time to
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources
Printed in Canada
www.osburn-mfg.com
Stove Builder International Inc.
READ AND KEEP THIS MANUAL FOR REFERENCE
Safety tested according to ULC S627,
UL1482 and ASTM E1509, and also
according to Oregon Administrative Rules
for Mobile Homes 814-23-900 through
E-mail: tech@sbi-international.com
814-23-909
.
45548A
05-07-2018
Advertisement
Table of Contents
Related Manuals for Beyond OSBURN 5000
Summary of Contents for Beyond OSBURN 5000
- Page 1 INSTALLATION AND OPERATION MANUAL 5000 (OP00050 model) Safety tested according to ULC S627, UL1482 and ASTM E1509, and also according to Oregon Administrative Rules for Mobile Homes 814-23-900 through 814-23-909 CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA.
- Page 2 5000 Pellet Stove Installation and Operation Manual THANK YOU FOR CHOOSING THIS OSBURN PELLET STOVE As one of North America’s largest and most respected pellet stove, wood stove and fireplace manufacturers, Stove Builder International takes pride in the quality and performance of all its products.
-
Page 3: Table Of Contents
5000 Pellet Stove Installation and Operation Manual Table of contents INTRODUCTION..............................5 About Pellet Heating ............................5 1.1.1 Top 10 Reasons for Buying a Pellet Stove ....................5 Appliance performance ............................. 6 General Features ..............................7 Overall Exterior Dimensions ..........................8 PART A –... - Page 4 5000 Pellet Stove Installation and Operation Manual Stove operation ...............................36 First Startup ................................36 Everyday Startup ..............................36 Running Out of Pellets ............................36 Refilling ................................36 Shutting Down Procedure ...........................37 Signs of an Overheating Stove ..........................37 MAINTENANCE ..............................38 Stove Maintenance ..............................38 8.1.1 Recommended Maintenance Schedule ......................38 8.1.2 Cleaning the Baffle, the Heat Exchangers and the Combustion Chamber ..........39 8.1.3...
-
Page 5: Introduction
5000 Pellet Stove Installation and Operation Manual 1 INTRODUCTION 1.1 ABOUT PELLET HEATING Pellet stoves offer a dramatic improvement in the convenience of heating with solid fuel. Wood pellets are handled in bags and are therefore easily and cleanly stored. A single loading of a pellet stove can provide long hours of warmth. -
Page 6: Appliance Performance
5000 Pellet Stove Installation and Operation Manual 1.2 APPLIANCE PERFORMANCE ☨ Fuel type Wood Pellet (Premium grade or better) Recommended heating area 750 to 2,400 ft² (46 to 223 m²) Hopper capacity 70 lb (32 kg) Maximum burn time 64 h Maximum heat input rate 47,300 BTU/h (13.9 kW) Overall heat output rate (min. -
Page 7: General Features
5000 Pellet Stove Installation and Operation Manual 1.3 GENERAL FEATURES Recommended chimney diameter 3 po (see Section 4.3: Equivalent Vent Length (EVL)) Flue outlet diameter 3 po (75 mm) Type of chimney ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L) Baffle material Stainless Steel Approved for alcove installation Not approved... -
Page 8: Overall Exterior Dimensions
5000 Pellet Stove Installation and Operation Manual 1.4 OVERALL EXTERIOR DIMENSIONS A: FRESH AIR INTAKE B: EXHAUST 8 _______________________________________________________________________________... -
Page 9: Part A - Installation
5000 Pellet Stove Installation and Operation Manual PART A – INSTALLATION 2 INSTALLATION SAFETY INFORMATION 2.1 INSTALLATION WARNINGS, CAUTIONS AND RECOMMENDATIONS • PROFESSIONNAL INSTALLATION IS HIGHLY RECOMMENDED. • YOU MAY NEED TO OBTAIN A BUILDING PERMIT FOR THE INSTALLATION OF THIS STOVE AND ITS VENTING SYSTEM. -
Page 10: Regulations Covering Pellet Stove Installation
5000 Pellet Stove Installation and Operation Manual • NEVER BLOCK ANY LOUVERS OF THE STOVE. • IF REQUIRED, A FRESH AIR INTAKE KIT CAN BE INSTALLED TO SUPPLY COMBUSTION AIR TO THE ROOM OR SPACE (see Appendix E: Combustion Air Supply). •... -
Page 11: Clearances To Combustible Material
The clearances shown in this section have been determined by test according to procedures set out in safety standards ULC S627 (Canada), ASTM E1509 (U.S.A). When the pellet stove is installed so that its surfaces are at, or beyond, the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions. -
Page 12: Back Wall Installation
5000 Pellet Stove Installation and Operation Manual 3.3 BACK WALL INSTALLATION For a back wall installation, in order to allow the LCD sliding support to move freely and fully extend, you should allow a minimum of 4″(105 mm) clearance from the side wall (B) and 3″(80 mm) clearance at the back of the stove, from the fresh air intake (A). -
Page 13: Ceiling Clearances
5000 Pellet Stove Installation and Operation Manual 3.5 CEILING CLEARANCES For ceiling clearances refer to the table in Section 3.2 Minimum Clearances to Combustibles. 3.6 FLOOR PROTECTION For floor protection clearances refer to the following table. FLOOR PROTECTION LETTER CANADA 18″... -
Page 14: Venting System
5000 Pellet Stove Installation and Operation Manual 4 VENTING SYSTEM 4.1 GENERAL Even though the chimney draft is mechanical, a suitable venting system will ensure a natural draft which will prevent smoke spillage in your home if a power outage occurs. Moreover, a suitable venting system configuration will help getting the best efficiency out of your stove when installed in accordance with the required EVL (see Section 4.3 Equivalent Vent Length (EVL)). -
Page 15: Termination Location
5000 Pellet Stove Installation and Operation Manual Here is an example to help you calculate Equivalent Vent Length. On the following figure the EVL can be calculated like this: • 2 horizontal run of 1’ = (2 X 1’) X 1’ = 2’ of EVL •... -
Page 16: Permitted Termination Location
5000 Pellet Stove Installation and Operation Manual 4.4.1 PERMITTED TERMINATION LOCATION Refer to NFPA 211 (USA) or CSA B365 (Canada) for rules for the distance of exit terminal from windows and openings. The exit terminal of a mechanical draft system, other than a direct vent appliance shall be located in accordance with the following. - Page 17 5000 Pellet Stove Installation and Operation Manual A vent shall not terminate underneath a veranda, porch, or deck ______________________________________________________________________________ 17...
-
Page 18: Installation Configurations
5000 Pellet Stove Installation and Operation Manual United States: • Not Less than 36’’ (91 cm) above any forced air inlet located within 10 feet (305 cm); • Not Less than 48’’ (122 cm) below and horizontally from, or one foot (30 cm) above, any door, window or gravity air inlet into any building;... -
Page 19: Through Wall Installation (Main Floor Or Basement)
2. Install wall thimble as per vent manufacturer’s instructions. 3. Attach enough piping length to go through the wall thimble and extend at least 6 inches beyond the exterior wall. 4. Attach cap and seal outside wall thimbles with high temperature waterproof silicone sealant. -
Page 20: Through Roof Installation
5000 Pellet Stove Installation and Operation Manual 4.5.3 THROUGH ROOF INSTALLATION 1. Position stove following clearances given in Section 3.2 Minimum Clearances to Combustibles following vent manufacturer’s instructions. 2. Install a cleanout tee to the stove exhaust. If necessary, use a horizontal additional length between the exhaust and the tee. -
Page 21: Through A Prefabricated Chimney
5000 Pellet Stove Installation and Operation Manual 4.5.4 THROUGH A PREFABRICATED CHIMNEY The best method to make an installation through a prefabricated chimney is to run a 3" stainless steel liner inside the prefabricated chimney (or a 4" stainless steel liner depending on the Equivalent Vent Length calculated in Section 4.3 Equivalent Vent Length (EVL)). -
Page 22: Through An Existing Masonery Fireplace
5000 Pellet Stove Installation and Operation Manual 4.5.5 THROUGH AN EXISTING MASONERY FIREPLACE 1. Position stove, following clearances shown in Section 3.2 Minimum Clearances to Combustibles following vent manufacturer’s instructions. 2. Build and Install a blocking plate inside the chimney to seal the fireplace damper. Stainless steel plate and screws are recommended. -
Page 23: Through An Existing Masonery Chimney
5000 Pellet Stove Installation and Operation Manual 4.5.6 THROUGH AN EXISTING MASONERY CHIMNEY 1. Position stove following clearances shown in Section 3.2 Minimum Clearances to Combustibles following vent manufacturer’s instructions. 2. Mark the center of the hole where the vent pipe will go through the masonry chimney. -
Page 24: Part B - Operation
5000 Pellet Stove Installation and Operation Manual PART B - OPERATION 5 GENERAL INFORMATION 5.1 OPERATION WARNINGS, CAUTIONS AND RECOMMENDATIONS • KEEP THIS MANUAL FOR REFERENCE. • DURING THE FIRST FEW FIRES, YOUR STOVE WILL EMIT AN ODOR AND A SMALL AMOUNT OF FUMES AS THE HIGH TEMPERATURE PAINT CURES OR BECOMES SEASONED TO THE METAL. - Page 25 5000 Pellet Stove Installation and Operation Manual CONTAINER SHOULD BE PLACED ON A NONCOMBUSTIBLE FLOOR OR ON THE GROUND, WELL AWAY FROM ALL COMBUSTIBLE MATERIALS, PENDING FINAL DISPOSAL. IF THE ASHES ARE DISPOSED OF BY BURIAL IN SOIL OR OTHERWISE LOCALLY DISPERSED, THEY SHOULD BE RETAINED IN THE CLOSED CONTAINER UNTIL ALL ASHES HAVE BEEN THOROUGHLY COOLED.
-
Page 26: Zone Heating And How To Make It Work For You
5000 Pellet Stove Installation and Operation Manual THE FIREBOX FOR A FEW SECONDS JUST BEFORE THE IGNITOR IS HOT ENOUGH TO FIRE-UP THE PELLETS IN THE BURN POT. THIS IS NORMAL. AS SOON AS THERE IS FIRE IN THE BURN POT, SMOKE WILL DISAPPEAR. -
Page 27: Combustible
5000 Pellet Stove Installation and Operation Manual 5.2 COMBUSTIBLE 5.2.1 PROPER FUEL Each type of pellet has its properties and will burn differently. The amount of ashes produced can also vary greatly. Factory-approved pellets are those ¼” or 5/16” in diameter and not over 1” long. Longer or thicker pellets will prevent proper pellet feed. -
Page 28: Stove Controls
5000 Pellet Stove Installation and Operation Manual 6 STOVE CONTROLS 6.1 GENERAL INFORMATION The stove uses a LCD touch screen, the latest technology in control devices. The blowers and feed system are controlled from this screen. The LCD touch screen is factory-installed on the right hand side of the stove when facing it. See Appendix B: LCD Sliding Bracket Mounting for left hand side installation. - Page 29 5000 Pellet Stove Installation and Operation Manual Description of each main status page icon: Indicates that the stove is in the manual mode. It will therefore run continuously on the selected setting until it is manually modified, turned OFF or if the stove runs out of pellets (see Section 6.1.8 Selecting Manual or Thermostat Mode).
-
Page 30: Configuration And Operation Diagram
5000 Pellet Stove Installation and Operation Manual 6.1.2 CONFIGURATION AND OPERATION DIAGRAM Select the language displayed on the LCD screen (french, english) Select the pilot mode COOL COOL (30,45,60 minutes, always on or always off) This page will help the user troubleshoot the unit if 45 MIN Select the scale of... -
Page 31: Changing Temperature Unit (⁰F Or ⁰C)
5000 Pellet Stove Installation and Operation Manual 6.1.5 CHANGING TEMPERATURE UNIT (⁰F OR ⁰C) From the main status page, choose the letter icon . Select “SETUP” and then “⁰F / ⁰C”. Select icon F or C in order to display temperatures in the desired unit 6.1.6 ADJUSTING THE COMBUSTION LEVEL (HEAT OUTPUT) COMBUSTION LEVEL FUEL QUALITY ADJUSTMENT... -
Page 32: Convection Fan Speed Reduction (Optional)
5000 Pellet Stove Installation and Operation Manual 6.1.6.1 PILOT ADJUST. (Pilot Settings Adjustment) The “PILOT SETTINGS ADJUSTEMENT” will allow you to modify default settings by +/- 5% for auger motor 1 and +/- 10% for exhaust fan, but will only apply during pilot cycle: To restore default setting, select “DEFAULT”. -
Page 33: Selecting Manual Or Thermostat Mode
5000 Pellet Stove Installation and Operation Manual FAN SPEED CONTROL SLIDE THE CURSOR TO SELECT THE FAN SPEED BACK SAVE & EXIT Fan with red arrows icon will display on the Main Status Page as you “SAVE & EXIT”. Fan speed reduction will be more noticeable on higher combustion level settings. -
Page 34: Selecting The Pilot Cycle
5000 Pellet Stove Installation and Operation Manual 6.1.9 SELECTING THE PILOT CYCLE Note: This icon will be visible on the Main Status Page only on thermostat mode. To change the pilot cycle press the hourglass icon , or, from the Main Status Page, choose 135ºF the letter icon then select “SETUP”... -
Page 35: Filling Or Purging Auger Housing
5000 Pellet Stove Installation and Operation Manual 6.1.10 FILLING OR PURGING AUGER HOUSING Note: This function is disabled when the stove is running. To fill or purge the auger housing press the auger icon and select either “FEED AND START”, “PURGE SCREW”... -
Page 36: Stove Operation
5000 Pellet Stove Installation and Operation Manual 7 STOVE OPERATION 7.1 FIRST STARTUP Before starting your stove, make sure that the burn pot, the baffles and the maintenance access panels are properly installed. Also make sure that venting system is properly sealed and all doors are closed. -
Page 37: Shutting Down Procedure
5000 Pellet Stove Installation and Operation Manual 7.5 SHUTTING DOWN PROCEDURE To turn your stove off, press the “ON/OFF” icon on the Main Status Page. The flame at the center of the icon will disappear when the stove is turned off. The cooling cycle will take a few minutes and the blowers will continue to work while the stove is cooling down. -
Page 38: Maintenance
5000 Pellet Stove Installation and Operation Manual 8 MAINTENANCE 8.1 STOVE MAINTENANCE 8.1.1 RECOMMENDED MAINTENANCE SCHEDULE Use this as a guide under average use conditions. Weekly Twice a year Annually Components or after or after +/- 250 pounds +/- 1 tons per 2 tons of pellets Baffle Vacuum... -
Page 39: Cleaning The Baffle, The Heat Exchangers And The Combustion Chamber
5000 Pellet Stove Installation and Operation Manual 8.1.2 CLEANING THE BAFFLE, THE HEAT EXCHANGERS AND THE COMBUSTION CHAMBER Remove and clean the three parts of the baffle that are located inside the combustion chamber. Use the small metal tabs to remove the panels in the order shown on the following pictures. Vacuum heat exchanger tubes. - Page 40 5000 Pellet Stove Installation and Operation Manual 1. Clean the burn pot using the scraper provided with the stove or a brush. 2. Release the clips on both sides of the burn pot then, remove the burn pot by lifting and pulling it out.
-
Page 41: Ash Removal
5000 Pellet Stove Installation and Operation Manual 4. Verify that the clean out trap gasket is still in good condition, replace it if needed. 8.1.4 ASH REMOVAL 1. To empty the ash drawer of its contents, open the ash pan access door by lifting the latch on the right hand side. -
Page 42: Cleaning The Air Wash System
5000 Pellet Stove Installation and Operation Manual 8.1.5 CLEANING THE AIR WASH SYSTEM Vacuum the ashes that may have accumulated in the airwash system inlet between the bottom glass retainer and the glass. This will allow an optimum air flow along the inside portion of the glass and prevents the glass from sooting-up. -
Page 43: Door Gasket Maintenance
5000 Pellet Stove Installation and Operation Manual WARNING: REPLACEMENT GLASS SHOULD ONLY BE PURCHASED FROM AN AUTHORIZED DEALER (SEE “REPLACEMENT PARTS’’ SECTION). TEMPERED GLASS OR ORDINARY GLASS WILL NOT WITHSTAND THE HIGH TEMPERATURES OF THE STOVE. WARNING: IF YOU HAVE TO CHANGE THE DOOR GLASS, MAKE SURE YOU INSTALL THE NEW GASKETS AT THE SAME PLACE AS THE ORIGINAL IN ORDER TO KEEP THE AIRWASH WORKING PROPERLY. - Page 44 5000 Pellet Stove Installation and Operation Manual Clean and vacuum any dirt or ash build-up in the exhaust channels and exhaust blower housing being careful not to damage the blower’s blades. Use the scraper provided with the stove to clean heat exchanger outlet.
-
Page 45: Venting System Maintenance
5000 Pellet Stove Installation and Operation Manual 8.2 VENTING SYSTEM MAINTENANCE CAUTION: REGULARLY EXAMINE THE VENTING SYSTEM, THE JOINTS, AND THE SEALING TRIMS TO ENSURE THAT THE SMOKE AND THE COMBUSTION GASES ARE NOT DRAWN BY THE CONVECTION BLOWER. The most efficient method to sweep the venting system is by using a 3’’ or 4’’ pellet brush depending on your installation. -
Page 46: Troubleshooting
5000 Pellet Stove Installation and Operation Manual 9 TROUBLESHOOTING When you have issues with your stove, your first reaction may be to call technical support. This section will help you save time and money by enabling you to solve simple problems by yourself. Most common problems are generally caused by the following five factors: 1. -
Page 47: Testing Components
5000 Pellet Stove Installation and Operation Manual WARNING: RISK OF ELECTRICAL SHOCK. IF YOU NEED TO MANUALLY TEST, MANIPULATE OR REPLACE ANY COMPONENTS, THE STOVE NEEDS TO BE DISCONNECTED FROM THE WALL OUTLET. To validate the status of a component, you need to go to the “TROUBLESHOOT” page. From the Main Status Page, Press the “LETTER”... -
Page 48: Main Error Codes, Possible Causes And Solutions
5000 Pellet Stove Installation and Operation Manual the menu. Page 4 and 5 will allow you to test every electrical component. Note that you will be able COOL to test only components when the stove is cold (showing this icon For example, if you press on the white square next to “GEAR MOTOR 1”, the auger 1 will turn for 30 seconds. - Page 49 5000 Pellet Stove Installation and Operation Manual THE FOLLOWING MAY HAVE CAUSED YOUR THE FOLLOWING MAY HAVE CAUSED YOUR BLOCKED FLUE PROBLEM (BLOCKED FLUE): PROBLEM (BLOCKED FLUE): • THE PRESSURE SWITCH WIRE • THE PRESSURE TAP IS BLOCKED • THE FLUE IS BLOCKED OR CONNECTIONS ARE FAULTY A BLOCKAGE WAS •...
- Page 50 5000 Pellet Stove Installation and Operation Manual THE FOLLOWING MAY HAVE CAUSED YOUR NO FUEL PROBLEM (NO FUEL): • THE STOVE RAN OUT OF PELLETS THE EXHAUST • THE BURN POT HOLES ARE BLOCKED • THE AUGER JAMMED TEMPERATURE INDICATES •...
- Page 51 5000 Pellet Stove Installation and Operation Manual THE FOLLOWING MAY HAVE CAUSED YOUR FAILED IGNITION PROBLEM (FAILED IGNITION): THE EXHAUST • INADEQUATE FUEL IS USED TEMPERATURE HAS NOT • THE IGNITER IS DEFECTIVE • THE FLUE TEMPERATURE SENSOR REACHED ITS START-UP FAILED VALUE AFTER TWO CONSULT OWNER’S MANUAL FOR...
- Page 52 5000 Pellet Stove Installation and Operation Manual THE FOLLOWING MAY HAVE CAUSED YOUR AUGER FUSE PROBLEM (AUGER FUSE): • THE AUGER IS JAMMED • THE AUGER MOTOR IS DEFECTIVE THE AUGER FUSE BLEW UP • THE WIRING HARNESS SHORTED CONSULT OWNER’S MANUAL FOR MORE DETAILS RESET DETAILS...
- Page 53 5000 Pellet Stove Installation and Operation Manual ❖ The flue is blocked or needs cleaning. One of the following components is obstructed or blocked; air intake shutter, combustion blower, burn pot, heat exchangers and channels, exhaust blower and or venting system. Refer to the maintenance section. ❖...
- Page 54 ❖ Negative pressure. A faint wood-burning odor during ignition or shut down is normal. Although, if this increases beyond normal or if you notice an unusual soot build-up on walls or furniture, check your venting system carefully for leaks and make sure all gaskets are in good condition. Also, make sure recommended maintenance schedule has been performed.
-
Page 55: Wiring Diagram
5000 Pellet Stove Installation and Operation Manual 10 WIRING DIAGRAM _____________________________________________________________________________ 55... -
Page 56: Fuses Access
5000 Pellet Stove Installation and Operation Manual 11 FUSES ACCESS WARNING: UNPLUG THE STOVE BEFORE CHANGING THE FUSES. All fuses are located inside the housing of the electronic board; the housing is on the back of your stove. Unplug your stove and turn the four spring clip to open the housing. 56 _____________________________________________________________________________... - Page 57 5000 Pellet Stove Installation and Operation Manual _____________________________________________________________________________ 57...
-
Page 58: Component Location
5000 Pellet Stove Installation and Operation Manual 12 COMPONENT LOCATION 58 _____________________________________________________________________________... -
Page 59: Exploded View And Replacement Parts
5000 Pellet Stove Installation and Operation Manual 13 EXPLODED VIEW AND REPLACEMENT PARTS ______________________________________________________________________________ 59... - Page 60 5000 Pellet Stove Installation and Operation Manual IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your stove, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrade or availability. Contact an authorized dealer to obtain any of these parts.
- Page 61 5000 Pellet Stove Installation and Operation Manual ITEM DESCRIPTION SE64379 EXHAUST BLOWER MAINTENANCE ACCESS DOOR SE64375 EXHAUST CHANEL ASSEMBLY 21384 EXHAUST GASKET 44095 THERMISTOR ASSEMBLY SE44144 EXHAUST FAN ASSEMBLY 21382 OUTLET EXHAUST BLOWER GASKET PL64462 BLOWER OUTLET SPACER PL64463 ROUND EXHAUST PLATE 21392 EXHAUST ADAPTER GASKET 30762...
- Page 62 99999 BUILD TO ORDER SE64440 ASH DRAWER ACCESS DOOR 30566 DOOR HINGE 30022 MECHANICAL SCREW 10-32 X 1/2'' FLAT HEAD 100 AC06725 GLUE & 3/4" WHITE GASKET KIT 101 PL64498 SCRAPER 102 SE45548 OSBURN 5000 INSTRUCTION MANUAL KIT 62 ______________________________________________________________________________...
-
Page 63: Appendix A: Horizontal And Vertical Vent Chart
5000 Pellet Stove Installation and Operation Manual APPENDIX A: HORIZONTAL AND VERTICAL VENT CHART Possible Horizontal vent length (feet) For example, let’s imagine an installation consisting of a horizontal vent coming out at the back of the stove on a total distance of 8 feet. This horizontal run is followed by a tee and a 6-foot vertical rise. - Page 64 5000 Pellet Stove Installation and Operation Manual Instead, if the installation consisted of a horizontal vent coming out at the back of the stove on a total distance of 4 feet, followed by a tee and a 6-foot vertical rise, it would be acceptable. The installation end should be within the allowable configuration zone on the chart since it would have at least one foot of vertical rise for each foot of horizontal run.
-
Page 65: Appendix B: Lcd Sliding Bracket Mounting
5000 Pellet Stove Installation and Operation Manual APPENDIX B: LCD SLIDING BRACKET MOUNTING Step 1 The LCD sliding bracket is preassembled on the right hand side when facing the stove. To reverse the assembly to a left side configuration, extend the rail with the LCD support (E) in order to access the two screws (A) which secures the rail mechanism to the mounting bracket. - Page 66 5000 Pellet Stove Installation and Operation Manual Step 3 Take the Telco black wire (D) which is located on the rear bottom panel and plug it into the back of the LCD touch screen interface receptacle. Step 4 Finally, secure the LCD touch screen housing (F) on the rail (E). 66 ______________________________________________________________________________...
-
Page 67: Appendix C: Installing A Thermostat
5000 Pellet Stove Installation and Operation Manual APPENDIX C: INSTALLING A THERMOSTAT Using a thermostat will help you maintain a constant temperature throughout the house. A low voltage thermostat is required. A fixed wall mount or hand held model can be used. Note: Thermostat manufacturer’s instruction always overrides the information published in the following section. - Page 68 5000 Pellet Stove Installation and Operation Manual Here is an example of what your thermostat could look like: Connect one wire on “RH” and the other wire on “W”. Red wire jumper can be left installed. For further information refer to the manufacturer’s instructions. Wireless thermostat If you are using a wireless thermostat or a hand held thermostatic remote control, connect the two thermostat wires to the terminal block located at the rear on the right hand side of the stove while...
- Page 69 5000 Pellet Stove Installation and Operation Manual QUICK CONNECT TERMINALS To do so, open the right hand side decorative panels and disconnect the two (2) harness wires attached to the rear of the terminal block and connect them to the receiver wires. ______________________________________________________________________________ 69...
-
Page 70: Appendix D: Mobile Home Installation
5000 Pellet Stove Installation and Operation Manual APPENDIX D: MOBILE HOME INSTALLATION Anchor the stove WARNING: FOR MOBILE HOME INSTALLATION, IT IS MANDATORY TO CONNECT THE STOVE TO AN OUTSIDE COMBUSTION AIR SOURCE. (SEE APPENDIX E) When installed in a mobile home, the stove must be anchored to the floor with two screws. Use the two holes located for this purpose on each side of the pedestal, as shown on the following image. -
Page 71: Appendix E: Combustion Air Supply
5000 Pellet Stove Installation and Operation Manual APPENDIX E: COMBUSTION AIR SUPPLY WARNING: FOR MOBILE HOME INSTALLATION, IT IS MANDATORY TO CONNECT THE STOVE TO AN OUTSIDE COMBUSTION AIR SOURCE. INSULATED PIPE SHOULD NEVER EXCEED 10 FEET. It is recommended to install a fresh air intake in or near the room where the stove is installed. When doing so, it is preferable to choose a wall which is not exposed to dominant winds, depending on the conditions surrounding your house. - Page 72 5000 Pellet Stove Installation and Operation Manual Also make sure that the fresh air intake backdraft shutter works freely. The fresh air intake backdraft shutter is located at the middle of the stove’s right hand side. Sources of Outside Combustion Air •...
-
Page 73: Appendix F: Installing The Door Overlay
5000 Pellet Stove Installation and Operation Manual APPENDIX F: INSTALLING THE DOOR OVERLAY In order to complete the assembly of your Osburn 5000, you need to install the door overlay (A). See figure below for installation instructions: 1- Remove the wooden handle which is secured by a Philips type screw and a washer. -
Page 74: Osburn Limited Lifetime Warranty
5000 Pellet Stove Installation and Operation Manual OSBURN LIMITED LIFETIME WARRANTY The warranty of the manufacturer extends only to the original retail purchaser and is not transferable. This warranty covers brand new products only, which have not been altered, modified nor repaired since shipment from factory. Proof of purchase (dated bill of sale), model name and serial number must be supplied when making any warranty claim to your OSBURN dealer.
