Bios setup
Table of Contents

Advertisement

MultiCore Enhancement
[Auto]
This item allows you to maximize the oveclocking performance
optimized by core ratio settings.
[Disabled]
This item allows you to set to default core ratio settings.
CPU Core Ratio
This item allows you to set the CPU core ratios.
Configuration options: [Auto] [Sync All Cores] [By Core Usage]
BCLK Frequency : DRAM Frequency Ratio
[Auto]
The BCLK frequency to DRAM frequency ratio will be set to the optimized
setting.
[100:133]
The BCLK frequency to DRAM frequency ratio will be set to 100:133.
[100:100]
The BCLK frequency to DRAM frequency ratio will be set to 100:100.
DRAM Frequency
This item allows you to set the memory operating frequency. The configurable options vary
with the BCLK (base clock) frequency setting. Select the auto mode to apply the optimized
setting.
Configuration options: [Auto] [DDR4-800MHz] - [DDR4-4266MHz]
TPU
This item allows you to automatically overclock the CPU and DRAM frequencies and voltage
for an enhanced system performance.
[Keep Current Settings] Keep the current settings without changing anything.
[TPU I]
[TPU II]
Ensure to use water cooling device before selecting [TPU II].
Internal CPU Power Management
The subitems in this menu allow you to set the CPU ratio and features.
Intel(R) SpeedStep(tm)
Allows the operating system to dynamically adjust the processor voltage and cores
frequency to decrease the average power consumption and decrease average heat
production. Configuration options: [Auto] [Enabled] [Disabled]
Turbo Mode
Allows you to enable your processor cores to run faster than the base operating
frequency when it is below power, current and specification limit. Configuration options:
[Disabled] [Enabled]
Applies air cooling overclocking conditions.
Applies water cooling overclocking conditions.
15
