DIRECT-VENT SYSTEM TO PREFABRICATED METAL CHIMNEY / MASONRY CHIMNEY
FOR DIRECT-VENT GAS BURNING STOVES AND FIREPLACE INSERTS
CAT. NUMBERS SV4MCK, SV4CCK1, SV4CCK2, SV4CCK3, SV4MCK, SV4FK, SV4FAK AND SV4FBK
f i r e - p a r t s . c o m
Innovative Hearth Products
1508 Elm Hill Pike, Suite 108
Nashville, TN 37210
www.IHP.us.com
US
P/N PISVKITS-A
REV. B, 02/2015
Portland
PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE
APPLICATION
Check the appliance manufacturer's rating plate to confirm that
the SECURE VENT
system is approved for use on the appliance
®
you have selected.
IMPORTANT
Read all instructions carefully before starting the installation.
Failure to follow these instructions may create a fire or other
safety hazard, and will void the warranty. Be sure to check the
appliance manufacturer's installation instructions for specific
venting and clearance to combustible requirements, which may
vary from one appliance to another.
WARNING
• It is of utmost importance to maintain the required minimum
clearances to combustible materials for the unit and the
chimney system. These spaces must be unobstructed; do
not fill them with insulating material.
• Multiple venting into a common flue is prohibited.
RECOMMENDATIONS
• For your safety, always wear goggles and gloves.
• Make sure to locate the electric wires before drilling through
the wall.
INSTALLATION
INSTRUCTIONS
SECURE VENT
CONVERSION KITS
®
VENTING INSTRUCTIONS
1
