Page 2
CONTENTS IMPORTANT SAFETY INSTRUCTIONS ....1 INSTALLATION INSTRUCTIONS ........4 NORMAL SOUNDS ...........18 AIR CONDITIONER FEATURES .......18 CARE AND CLEANING ..........20 TROUBLESHOOTING TIPS ........21...
Page 3
● Plug in power plug properly. Otherwise, it may cause electric shock or fire due to excess heat generation. ● Do not operate or stop the unit by inserting or pulling out the power plug. It may cause electric shock or fire due to heat generation. ●...
Page 4
● When the air filter is to be removed, do not touch the metal parts of the unit. It may cause an injury. ● Do not put a pet or house plant where it will be exposed to direct air flow. This could injure the pet or plant.
Page 5
Do not unplug and plug in the cord to turn the unit on or off.
Page 8
If there is an existing sleeve and rear grille, they will need to be replaced by the one included in the accessory kit.
Page 13
Install (2) tapered spacer blocks to the floor of the sleeve as shown. with the tapered end 1/2 from the back of the sleeve. This helps induce a rearward slop on the unit.
Page 18
The previous directions are the preferred installation method for the rear grille for optimal performance. Only use the Direct Mounting option as a last resort. As a last resort, direct mounting of the grille to the unit can be considered. Align the top of the grille with the top of the unit making sure the overhang on both sides is equal.
Page 19
between the wall-sleeve and the unit using a flat-head screwdriver or putty knife.
Page 20
Before you begin, thoroughly familiarize yourself with the control panel and functions (shown below). This unit can be controlled by the control panel or with the included remote. default to seen on the display and the temperature will be automatically maintained. The unit’s operating range is between...
Page 21
Press to select the Fan Speed: Auto, Low, Med, or High. On certain models the fan speed cannot be to cycle through modes: Auto, Cool, Dry, Heat (select adjusted under HEAT mode. On Dry mode the Fan models), and Fan. An indicator light will show the selected Speed will automatically be set to Low.
Page 22
Here are more control features you should be familiar with: The Cool circuit has an automatic 3-minute time delay if the unit is turned off and on quickly. This is a safeguard to prevent overheating of the compressor and possible tripping of the circuit breaker.
Page 23
Take the filter by the center and pull up and out. Wash the filter using liquid dishwashing detergent and warm water. Rinse filter thoroughly and gently shake to remove excess water from the filter. Gently shake excess water from the filter. Be sure the filter is thoroughly dry before replacing.
