iColor 540 User Manual

Digital Color + White Transfer Printer Digital Color + White Transfer Printer
1. Remove The Packing Materials
And Check the Components
Uninet IColor
ProRIP dongle

3. Remove Orange Security Tape Inside Printer

5. Using one of the provided cables (Network or USB), connect the printer to your PC (USB) or router/switch (network).
To set a static IP address for the printer, please refer to the IColor 540 User Manual.
•
6. The Uninet IColor 540 Digital Color + White Transfer Media Printer Has THREE Configurations To Suit Any Printing Project
These coincide with the 'Print Queues' in the iColor ProRIP (Step 14)
A. Standard CMYK
REAR
Cyan
Magenta
Yellow
Black
FRONT
Slot Order (Front to Back)

7. Install the Uninet IColor ProRIP

Choose your language and follow the install steps
•
ProRIP
Production Workflow Software Production Workflow Software
SetUp
Application Type. Choose either 32-bit or
64-bit application type. To Continue, select
Next.
IColor ProRIP Setup
ProRIP
Production Workflow Software Production Workflow Software
IColor ProRIP Setup
Choose Destination Location. Select folder
where setup will install files. To Continue,
select Next.
Uninet IColor 540

4. Remove White Cartridge and...

Remove protective foam from inside the machine and
•
protective film from the white cartridge and reinstall.
(stored on the provided dongle)
IColor ProRIP Setup
ProRIP
Production Workflow Software Production Workflow Software
IColor ProRIP Setup
InstallShield Wizard for IColor ProRIP
The InstallShield Wizard will install IColor ProRIP
on your computer. To Continue, select Next.
IColor ProRIP Setup
Production Workflow Software Production Workflow Software
IColor ProRIP Setup
Select Program Folder. Please select a program
folder. Setup will add program icons to the
Program Folder listed below. You may type a new
folder name, or select one from the existing
folders list. Select Next to continue.
For detailed instructions, please refer to the Uninet IColor 540 Printer User Manual
2. Remove Orange
From all sides
•
Then open the top lid
•
If operating in a 110v environment, connect the power transformer.
•
Ensure the input voltage on the back of the transformer is set to '115' using the red switch
B. Spot Color Underprinting.
(Typically used for right side
reading applications.)
REAR
White/Clear
Magenta
Yellow
Cyan
FRONT
Slot Order (Front to Back)
Please disable/uninstall any Anti Virus software before installation of the UNINET ProRIP
IColor ProRIP Setup
ProRIP
Production Workflow Software Production Workflow Software
IColor ProRIP Setup
License Agreement
Please read the following license agreement
carefully. If you agree, Accept and select Next.
ProRIP
and the Uninet IColor® ProRIP User Manual
Tape
Insert power cord in the back of
the machine and plug into power.
C. Spot Color Overprinting
(Typically used for reverse
printing applications.)
REAR
Cyan
Magenta
Yellow
White/Clear
FRONT
Slot Order (Front to Back)
IColor ProRIP Setup
ProRIP
Production Workflow Software Production Workflow Software
IColor ProRIP Setup
Installation Choices
Choose 'Full install of iColor ProRIP' and
select Next.
ProRIP
Production Workflow Software Production Workflow Software
IColor ProRIP Setup
Agree to license terms and select Install.
Quick Start Guide
