Mcombo 6360-SEC212W Operating Instruction

Electric toilet lift
Hide thumbs Also See for 6360-SEC212W:
Table of Contents

Advertisement

Quick Links

Download this manual
Electric Toilet Li�
6360-SEC212W
Pfillo GmbH
Kreuzweg 60,47809 Krefeld,
Deutschland
E-Mail: pfillo.de@gmail.com
Distributor and Dealer:This manual must be given to the user of the product.
User:Before using your toilet li� read this manual and save for future reference.
©2023 MCombo

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6360-SEC212W and is the answer not in the manual?

Questions and answers

Related Manuals for Mcombo 6360-SEC212W

Summary of Contents for Mcombo 6360-SEC212W

  • Page 1 Electric Toilet Li� 6360-SEC212W Pfillo GmbH Kreuzweg 60,47809 Krefeld, Deutschland E-Mail: pfillo.de@gmail.com Distributor and Dealer:This manual must be given to the user of the product. User:Before using your toilet li� read this manual and save for future reference. ©2023 MCombo...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION 1 GENERAL INFORMATION OPERATING INSTRUCTION INTRODUCTION DISCLAIMER WARNING SYMBOLS AND LABEL LOCATION PRODUCT OVERVIEW SECTION 2 INSTALLATION AND ASSEMBLY (English) UNPACKING YOUR TOILET LIFT UNIT ASSEMBLY INSTALLINGTHE TOILET LIFT AROUND TOILET Sec�on 3 Installa�on und Montage (Deutsch) AUSPACKUNG DES TOILETTENLIFTS MONTAGE DES TOILETTENLIFTS INSTALLATION DES TOILETTENLIFTS RUND UM DER TOILETTE...

  • Page 3: Section 1 General Information

    We ask that you read this manual completely before assembling and opera�ng your new MCombo Toilet Li�. We are not and cannot be held responsible for any damage or injury incurred due to improper or unsafe use of the MCombo Toilet Li�. We specifically disclaim responsibility for any bodily injury or property damage that may...

  • Page 4: Warning

    WARNING! • Rated load: 145kg. Never exceed rated load. • Please keep the original packaging a�er receiving the product. • Read and follow all instruc�ons and warnings prior to assembly and use. Correct installa�on,proper use,following instruc�ons and obeying warnings are neces- sary for safe opera�on.

  • Page 5: Symbols And Label Location

    STMBOLS The WARNING symbol indicates a poten�ally hazardous condi�on/situa�on.The safety warnings throughout this manual, and on your equipment, if any, are for the protec�on of people and property. Failure by any operator to abide by safety warnings will result in a waiver of all liabili�es, loss of your warranty, and could result in equipment damage and or failure, property damage, risk of serious bodily injury,and or death.The symbol may appear in various colors and in conjunc�on with other symbols.

  • Page 6: Product Overview

    PRODUCT OVERVIEW 1.Structure - Provides the ver�cal，horizontal,and rota�onal li� necessary to support the sit-to-stand process. 2. Handle Bar - Handle bars for pa�ent to place their hands on during the sit-to-stand process. 3.Linear Actuator - Linear actuator is mounted to the frame to move the device up and down.

  • Page 7: Unpacking Your Toilet Lift

    SECTION 1 GENERAL INFORMATION UNPACKING YOUR TOILET LIFT Warning! Check all parts for shipping damage before using. In case of damage,do not use the equipment. Contact us via email: pfillo.de@gmail.com for further instruc�ons. lnspec�on of the Box Contents Your toilet li� comes in one box. The box contains: A x 1 B x 1...
  • Page 8 M10*55mm (non-slip screw) 1 x 4 1*P1 1*P2 2*P3 1*P4 M10*25mm (non-slip screw) 2 x 4 1*P5 1*P2 1*P3 1*P4 M10*25mm (non-slip screw) 3 x 4 1*P5 1*P2 2*P3 1*P4 M10*85mm (Nylon Washer) (non-slip screw) 4 x 2 1*P6 2*P7 1*P8 1*P4 Head Posi�oning Pins...

  • Page 9: Unit Assembly

    UNIT ASSEMBLY Unpacking 1. Carefully unpack all items and lay out contents for inspec�on. Remove any packaging tape or supplies. 2. Check contents against parts list. If anything is missing contact us via email: pfillo.de@gmail.com STEP 1 Note: There is a small hole on part A, please make this small hole face down when installing. x 1PC B x 1PC C x 1PC...
  • Page 10 STEP 3 Note: None-slip screws, requiring two wrenches with a lot of force to tighten them. 1 x 4 STEP 4 Note: If the following holes can’t be aligned, please loosen the screws here and tighten them after finishing assembling. 2 x 4...
  • Page 11 STEP 5 Note: 1.None-slip screws, requiring two wrenches with a lot of force to tighten them. 2.Please turn the parts upside down for easier installation. 3.Install the part E according to the direction in the picture. 3 x 4 E x 1 STEP 6 5 x 4...
  • Page 12 STEP 7 G x 1PC STEP 8 plug in plug in...
  • Page 13 STEP 9 Ⅰ Ⅱ Note: None-slip screws, requiring two wrenches with a lot of force to tighten them. 4 x 2 F x 1PC STEP 10 Connect power supply and hand remote to li� actuator. I x 1PC H x 1PC G x 1PC...
  • Page 14 STEP 11 Plug power supply into a 220V outlet and cycle the unit to the highest position. If unit doesn’t cycle when plugged into a 220V outlet, contact us at via Note: email: pfillo.de@gmail.com...

  • Page 15: Installingthe Toilet Lift Around Toilet

    INSTALLING THE TOILET LIFT AROUND YOUR TOILET Cau�on: Make sure the exis�ng toilet seat is removed from the toilet. 1. A�ach toilet seat to the unit. Make sure toilet seat is aligned to top plate.Then slide the toilet li� around the toilet so the unit is centered le�-to-right and front-to-back. Cau�on: Make sure the back of the seat does not interfere with the back of the toilet 2.Test the movement up and down making sure there are no interference issues.
  • Page 16 Cau�on: The bo�om of the toilet li� should not be closer than 2.5cm to the top of the toilet rim.To adjust the height, adjust the leveling feet. 3. Use the leveling feet as needed to adjust the proper height of the unit over the toilet. Lowest Adjust Height...

  • Page 17: Auspackung Des Toilettenlifts

    Sec�on 3 Installa�on und Montage AUSPACKUNG DES TOILETTENLIFTS Warnung! Überprüfen Sie alle Teile vor Gebrauch auf Transportschäden. Verwenden Sie das Gerät nicht, wenn es beschädigt ist. Bi�e kontak�eren Sie uns per E-Mail: pfillo.de@gmail.com für weitere Anweisungen. Überprüfung des Inhalts der Box Ihr Toile�enli�...
  • Page 18 (An�-Rutsch Schraube) M10*55mm 1 x 4 1*P1 1*P2 2*P3 1*P4 (An�-Rutsch Schraube) M10*25mm 2 x 4 1*P5 1*P2 1*P3 1*P4 (An�-Rutsch M10*25mm Schraube) 3 x 4 1*P5 1*P2 2*P3 1*P4 (An�-Rutsch M10*85mm (Dichtung) Schraube) 4 x 2 2*P7 1*P8 1*P6 1*P4 Fußstütze Bolzen...

  • Page 19: Montage Des Toilettenlifts

    MONTAGE DES TOILETTENLIFTS Auspackung 1. Packen Sie das Produkt vorsich�g aus und legen Sie die Teilen zur Überprüfung aus. En�ernen Sie das Verpackungsband oder Beutel. 2. Überprüfen Sie die Teilen anhand der Teileliste. Sollte etwas fehlen, kontak�eren Sie uns bi�e per E-Mail: pfillo.de@gmail.com STEP 1 Hinweis:...
  • Page 20 STEP 3 Hinweis: festzuziehen der Anti-Rutsch-Schrauben erfordert die Hilfe von zwei Schraubenschlüsseln und viel Kraft. 1 x 4 STEP 4 Hinweis: wenn die Löcher lassen sich nicht ausgerichteten, lösen Sie bitte die Schrauben hier und ziehen Sie sie nach der Montage fest. 2 x 4...
  • Page 21 STEP 5 Hinweis: 1.festzuziehen der Anti-Rutsch-Schrauben erfordert die Hilfe von zwei Schraubenschlüsseln und viel Kraft. 2.bitte drehen Sie die Teile für eine einfachere Installation auf den Kopf. 3.installieren Sie das Teil #E entsprechend der Richtung im Bild. 3 x 4 E x 1 STEP 6 5 x 4...
  • Page 22 STEP 7 G x 1PC STEP 8 Einstecken Einstecken...
  • Page 23 STEP 9 Ⅰ Ⅱ Hinweis: festziehen der Anti-Rutsch-Schrauben erfordert die Hilfe von zwei Schraubenschlüsseln und viel Kraft. 4 x 2 F x 1PC STEP 10 Schließen Sie das Netzteil und die Fernbedienung an den Motor an. I x 1PC H x 1PC G x 1PC...
  • Page 24 STEP 11 Stecken Sie das Netzteil in eine 220V-Steckdose und stellen Sie das Gerät in die höchste Position ein. sollte das Gerät nach dem Anschließen des Netzteils nicht funktionieren, Hinweis: kontaktieren Sie uns bitte per E-Mail: pfillo.de@gmail.com.

  • Page 25: Installation Des Toilettenlifts Rund Um Der Toilette

    INSTALLATION DES TOILETTENLIFTS RUND UM DER TOILETTE Vorsicht: stellen Sie sicher, dass der vorhandene Toile�ensitz aus der Toile�e en�ernt ist. 1.Befes�gen Sie den Toile�ensitz am Toile�enli�. Stellen Sie sicher, dass der Toile�ensitz auf der oberen Pla�e ausgerichtet ist. Schieben Sie dann den Toile�enli� um die Toile�e, so dass das Gerät von links nach rechts und von vorne nach hinten zentriert ist.
  • Page 26 Vorsicht: die Unterseite des Toile�enli�s sollte nicht näher als 2.5 Cm an der Oberseite des Toile�enrandes sein. Um die Höhe einzustellen, stellen Sie die Nivellierfüße ein. 3.Verwenden Sie die Nivellierfüße nach Bedarf, um die rich�ge Höhe des Geräts über der Toile�e einzustellen.

  • Page 27: Section 4 Using Your Toilet Lift

    SECTION 3 USING YOUR TO I T LIFT INSTRUCTIONS FOR INDIVIDUAL USERS Do not a�empt any transfer without approval of the pa�ents physician, nurse or medical assistant. Thoroughly read the instruc�ons in this Owner's Manual. Use common sense ever y�me using the toilet li�. Special care must be taken with people with disabili�es who can't operate the toilet li�...
  • Page 28 Figure 5 Figure 6 Press the Down bu�on on the hand For your safety, once you are done pendant. You must keep the bu�on toile�ng, stay seated while comple�ng pressed down for the toilet li� to all your hygiene ac�vi�es. con�nue moving to the seated posi�on.

  • Page 29: Instructions For Caregivers

    INSTRUCTIONS FOR CAREGIVERS Caregivers should follow the lnstruc�ons for lndividual Users, with the following addi�ons. 1.Move the toilet li�t to the fully raised posi�on (or to the most comtortable posi�onfor the pa�ent). 2.With the hand pendant in one hand, stabilize the pa�ent in front of the toilet li�.Place your free arm securely under the pa�ent's arm between the pa�ent's arm and body.

  • Page 30: Cleaning Guidelines

    CLEANING GUIDELINES Proper cleaning and regular inspec�on is essen�al to keep the toilet li� opera�ng at maximum efficiency and providing the best possible safety for each user of this product. lf the toilet li� is not cleaned on a regular basis, the top plate of the unit could prematurely rust due to the highly corrosive nature of urine.

  • Page 31: Section 5 Additional Information

    �me you do not feel comfortable performing the troubleshoo�ng steps listed in this manual, please contact the MCombo Customer Service for service. Please have the model number ‘6260-M212W, order ID, and nature of the problem when emailing.
