- Page 1 Electric Toilet Li� 6360-SEC212W NEWACME LLC 2808 Vail Ave Commerce, CA, 90040 323-597-1109 sales@mcombo.com Distributor and Dealer: This manual must be given to the user of the product. User: Before using your toilet li� read this manual and save for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION 1 GENERAL INFORMATION OPERATING INSTRUCTION ..................2 INTRODUCTION......................2 DISCLAIMER........................2 WARNING........................3 SYMBOLS AND LABEL LOCATION................... 4 PRODUCT OVERVIEW..................... 5 SECTION 2 INSTALLATION AND ASSEMBLY UNPACKING YOUR TOILET LIFT..................6 UNIT ASSEMBLY......................8 INSTALLING THE TOILET LIFT AROUND TOILET............. 14 SECTION 3 USING YOUR TOILET LIFT INSTRUCTIONS FOR INDIVIDUAL USERS.............. -
Page 3: Section 1 General Information
We ask that you read this manual completely before assembling and operating your new Mcombo Toilet Lift. We are not and cannot be held responsible for any damage or injury incurred due to improper or unsafe use of the Mcombo Toilet Lift. We... -
Page 4: Warning
For additional information, or to obtain replacement copies of instructions or labels, call 323-597-1109 or email us sales@mcombo.com. ● Understand and learn the location and function of all the features before operating. -
Page 5: Symbols And Label Location
SYMBOLS The WARNING symbol indicates a potentially hazardous condition/situation. The safety warnings throughout this manual, and on your equipment, if any, are for the protection of people and property. Failure by any operator to abide by safety warnings will result in a waiver of all liabilities, loss of your warranty, and could result in equipment damage and or failure, property damage, risk of serious bodily injury, and or death. -
Page 6: Product Overview
PRODUCT OVERVIEW 1. Structure – Provides the vertical, horizontal, and rotational lift necessary to support the sit-to-stand process. 2. Handle Bar – Handle bars for patient to place their hands on during the sit-to-stand process. 3. Linear Actuator – Linear actuator is mounted to the frame to move the device up and down. -
Page 7: Section 2 Installation And Assembly
UNPACKING YOUR TOILET LIFT Warning! Check all parts for shipping damage before using. In case of damage, do not use the equipment. Contact us at 323-597-1109 or email: sales@mcombo.com for further instruc�ons. Inspection of the Box Contents Your toilet lift comes in one box. - Page 8 M10*55mm (Non-slip Screw) 1 x 4 1*P1 1*P2 2*P3 1*P4 M10*25mm 2 x 4 1*P5 1*P2 1*P3 M10*25mm (Non-slip Screw) 3 x 4 1*P5 1*P2 2*P3 1*P4 20mm 10.2mm 12mm M10*85mm (Nylon Washer) (Non-slip Screw) 4 x 2 2*P7 1*P8 1*P6 1*P4 Leveling Feet...
-
Page 9: Unit Assembly
1. Carefully unpack all items and lay out contents for inspec�on. Remove any packaging tape or supplies. 2. Check contents against parts list. If anything is missing contact us at 323-597-1109 or email: sales@mcombo.com STEP 1 Note: There is a small hole on part A, please make this small hole face down when installing. - Page 10 STEP 3 Note: None-slip screws, requiring two wrenches with a lot of force to tighten them. 1 x 4 STEP 4 Note: If the following holes can’t be aligned, please loosen the screws here and tight- en them after finishing assembling. 2 x 4...
- Page 11 STEP 5 Note: 1.None-slip screws, requiring two wrenches with a lot of force to tighten them. 2.Please turn the parts upside down for easier installation. 3.Install the part E according to the direction in the picture. 3 x 4 E x 1 STEP 6 5 x 4...
- Page 12 STEP 7 G x 1PC STEP 8 plug in plug in...
- Page 13 STEP 9 Ⅰ Ⅱ Note: None-slip screws, requiring two wrenches with a lot of force to tighten them. 4 x 2 F x 1PC STEP 10 Connect power supply and hand remote to lift actuator. I x 1PC H x 1PC G x 1PC...
- Page 14 STEP 11 Plug power supply into a 110V outlet and cycle the unit to the highest position. Note: If unit doesn’t cycle when plugged into a 110V outlet, contact us at 323-597-1109 or email: sales@mcombo.com...
-
Page 15: Installing The Toilet Lift Around Toilet
INSTALLING THE TOILET LIFT AROUND YOUR TOILET Caution: Make sure the existing toilet seat is removed from the toilet. 1. A�ach toilet seat to the unit. Make sure toilet seat is aligned to top plate.Then slide the toilet li� around the toilet so the unit is centered le�-to-right and front-to-back. Caution: Make sure the back of the seat does not interfere with the back of the toilet 2. - Page 16 Caution: The bottom of the toilet lift should not be closer than 1 inch to the top of the toilet rim. To adjust the height, adjust the leveling feet. 3. Use the leveling feet as needed to adjust the proper height of the unit over the toilet.
-
Page 17: Section 3 Using Your Toilet Lift
SECTION 3 USING YOUR TOILET LIFT INSTRUCTIONS FOR INDIVIDUAL USERS Do not attempt any transfer without approval of the patients physician, nurse or medical assistant. Thoroughly read the instructions in this Owner’s Manual. Use common sense every time using the toilet lift. Special care must be taken with people with disabilities who can’t operate the toilet li�... - Page 18 Figure 5 Figure 6 Press the Down bu�on on the hand For your safety, once you are pendant. You must keep the bu�on done toile�ng, stay seated pressed down for the toilet li� to while comple�ng all your con�nue moving to the seated hygiene ac�vi�es.
-
Page 19: Instructions For Caregivers
INSTRUCTIONS FOR CAREGIVERS Caregivers should follow the Instructions for Individual Users, with the following additions. 1. Move the toilet lift to the fully raised position (or to the most comfortable position for the patient). 2. With the hand pendant in one hand, stabilize the patient in front of the toilet lift. Place your free arm securely under the patient’s arm between the patient’s arm and body. -
Page 20: Cleaning Guidelines
CLEANING GUIDELINES Proper cleaning and regular inspection is essential to keep the toilet lift operating at maximum efficiency and providing the best possible safety for each user of this product. If the toilet lift is not cleaned on a regular basis, the top plate of the unit could prematurely rust due to the highly corrosive nature of urine. -
Page 21: Section 4 Additional Information
If at any time you do not feel comfortable performing the troubleshooting steps listed in this manual, please contact the Mcombo Customer Service for service. Please have the model number ‘6360-SEC212W ’, order ID, and nature of the problem when calling or emailing. -
Page 22: Limited Warranty
LIMITED WARRANTY For a period of 24 months from the date of shipment. Mcombo warrants the powder metal paint finish, hand pendant, and linear actuator for a 12 month period from the date of purchase. If within such warranty period any such product should be proven to be defective, such product shall be repaired or replaced, at Mcombo option.
