Summary of Contents for LG HW964TZ-AMP

  • Page 1 HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 1 Model : HW964TZ (HW964TZ-AMP, SH94TZ-F/S/C/W, W94R) HW964PZ (HW964PZ-AMP, SH94PZ-F/S/C/W, W94R) Full HD up-scaling (1080p) HDMI In Home theater Speaker ez Set-up (Go to page 8) (Go to page 9) (Go to page 17) USB Direct Recording...
  • Page 2 European representative : center. LG Electronics Service Europe B.V. Use of controls, adjustments or the performance of procedures other than those Veluwezoom 15, 1327 AE Almere, The Netherlands specified herein may result in hazardous radiation exposure.
  • Page 3: Table Of Contents

    LG TV with SIMPLINK are connected through HDMI connection. • Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Language Codes .......22 Power Off, etc.
  • Page 4: Setting Up

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 4 Setting up Connect the wires to the DVD receiver. Match each wire’s coloured band to the same coloured connection The speakers are detached from the speaker stands. terminal on the rear of the DVD receiver. To connect the cable to the DVD receiver, press each plastic finger pad to open the connection terminal.
  • Page 5: Led Indicator Of Wireless Receiver

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 5 LED indicator of Wireless Receiver Setting an ID of Wireless Operation LED color When the unit is manufactured, the ID is already set. If an interference occurs or you use a new Wireless Receiver, an ID should be set again. BLUE The Wireless Receiver is receiving the signal of the Wireless transmitter.
  • Page 6 HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 6 Setting up About Ferrite Core (for EMI only) Be careful of the following Be sure to attach the ferrite core to the speaker cable (for connecting to this unit and wireless receiver). • Be careful to make sure children do not put their hands or any objects into the *speaker duct.
  • Page 7: Hooking Up The Unit

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 7 Hooking up the unit a Connect jacks on the unit and your TV (DVD player or Digital Device etc.) using the cables. Check the jacks of your TV, and choose the A, B or C connection. Picture quality improves in order from A to C. Component Video connection ( AM/ FM connection Connect the COMPONENT...
  • Page 8 HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 8 Hooking up the unit Available resolution according to connection Displayed resolution in display window and outputted resolution may different Resolution Setting according to connection type. You can change the resolution for component video and HDMI output. [HDMI OUT]: 1080p, 1080i, 720p and 480p (or 576p) and 480i (or 576i) Press RESOLUTION repeatedly to select the desired resolution - 480i (or 576i), [COMPONENT VIDEO OUT]: 480p (or 576p) and 480i (or 576i)
  • Page 9: Main Unit

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 9 Hooking up the unit Main Unit 4 5 6 HDMI In connection Connect the HDMI INPUT jack on the unit to the HDMI output jack on your Set-Top box (or Digital Device etc.) using an HDMI cable. Set the external source to HDMI IN by pressing FUNCTION.
  • Page 10: Remote Control

    You can control the sound level, input source, and (进入): : Acknowledges menu selection. ENTER(进入) power switching of LG TVs as well. Hold POWER (TV) and press PR/CH (+/–) button repeatedly until the TV turns on or off. (返回): : Moving backwards in the menu.
  • Page 11: Osd Initial Language Settings - Optional

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 11 OSD Initial language settings - Optional Adjusting the general settings During the first use of this unit, the initial language setup menu ON REMOTE appears on your TV screen. You must complete initial language 1 Display setup menu : SETUP selection before using the unit.
  • Page 12: 5.1 Speaker Setup

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 12 Adjusting the display settings 5.1 Speaker Setup TV Aspect – Select which screen aspect to use based on the shape of your TV screen. ON REMOTE [4:3] : Select when a standard 4:3 TV is connected. 1 Open the settings menu: SETUP [16:9] : Select when a 16:9 wide TV is connected.
  • Page 13: Enjoying A Preprogrammed Sound Field

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 13 Adjusting the lock settings Enjoying a pre-programmed sound field To access the lock options, you must enter the 4-digit password. If you have not yet entered a password you are prompted to do so. Enter a 4-digit password This system has a number of pre-set surround sound fields.
  • Page 14: Displaying Disc Information

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 14 Displaying Disc Information Playing a Disc or file ON REMOTE ON REMOTE Z Z OPEN/CLOSE 1 Press DISPLAY : 1 Insert a disc on unit : DISPLAY 2 Select a DVD/CD : FUNCTION 2 Select an item : U U u u U U u u I I i i I I i i...
  • Page 15 HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 15 Selecting a subtitle language DivX Viewing the DVD MENU During playback, press SUBTITLE ( ) repeatedly to select a desired subtitle Press MENU to display the disc menu, if available. language. Changing the character set to display DivX ®...
  • Page 16: Viewing Photo Files

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 16 Creating your own program Viewing photo files You can play the contents of a disc in the order you want by arranging the order of the musics on the disc. To add a music(s) on the program list, press ON REMOTE PROG/MEMO to enter the program edit mode ( mark appears on the menu).
  • Page 17: Listening To The Radio

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 17 Home theater Speaker ez Set-up Listening to the radio Be sure that both FM and AM aerials are connected. Listen to sound from TV, DVD and Digital Device with 5.1(2.1 or 2)ch mode. Even in power off mode, if you press TVtHT SPK, then power is ON REMOTE on and automatically changed to AUX OPT mode.
  • Page 18: Using An Usb Device

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 18 Compatible USB Devices Using an USB device • MP3 Player : Flash type MP3 player. • USB Flash Drive : Devices that support USB2.0 or USB1.1. You can enjoy media files saved on an USB device by connecting the •...
  • Page 19: Recording To Usb

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 19 When you are recording, look out for the following Recording to USB • You can check the recording percentage rate for the USB record on the ON REMOTE screen during the recording.(AUDIO CD or MP3/ WMA CD only) •...
  • Page 20: Playing The Ipod

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 20 Playing the iPod - more you can do Playing the iPod Pauseing playback For detail refer to iPod guide. iPod mode: You can operate your iPod by using the supplied remote Press PAUSE/STEP (X X ) or PLAY (B B ) to pause playback. Press PAUSE/STEP control and directly control on your iPod.
  • Page 21: Listening To Music From Your Portable Player Or External Device

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 21 Other operations Listening to music from your portable player or external device Fall asleep while listening to your player Press SLEEP one or more times to select delay time between 10 and 180 The unit can be used to play the music from many types of portable player or minutes, after the player will turn off.
  • Page 22: Language Codes

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 22 Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Language Code Language Code Afar 6565 Croatian 7282...
  • Page 23: Troubleshooting

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 23 Troubleshooting PROBLEM CAUSE CORRECTION No power Plug the power cord into the wall outlet securely. The power cord is disconnected. No picture Select the appropriate video input mode on the TV so the The TV is not set to receive the DVD signal. picture from the DVD Receiver appears on the TV screen.
  • Page 24: Types Of Playable Discs

    LG players when formatting rewritable discs. When setting pending. DTS and DTS Digital Surround are registered trademarks and the the option to Live File System, you cannot use it on LG players. DTS logos and Symbol are trademarks of DTS, Inc. © 1996-2007 DTS, Inc. All (Mastered/ Live File System : Disc format system for Windows Vista) Rights Reserved.
  • Page 25: Specifications

    HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 25 Specifications Specifications General Speakers (HW964TZ) Power supply Refer to main label. Front Rear Speaker speaker Power consumption Refer to main label. Net Weight 3.7 kg Type 2 Way 3 Speaker 2 Way 3 Speaker External dimensions (W x H x D) 430 x 73 x 303 mm 4 Ω...
  • Page 26 HW964TZ-AMP_DCHNLL_ENG_5808 7/24/09 11:17 AM Page 26...
