Vertical Contact
Bun Toasters
Standard Length Feed Tray:
#184BT18A
120V • 1600W
Extended Length Feed Tray:
#184BT18AXL
120V • 1600W
Warning:
Improper installation, adjustment, alteration, service, or
maintenance can cause property damage, injury, or death.
Read the installation, operating, and maintenance Instructions
thoroughly before installing or servicing this equipment.
www.AvantcoEquipment.com
User Manual
#184BT18H
208/240V • 2800/3200W
#184BT18HXL
208/240V • 2800/3200W
For Your Safety:
Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
Note:
Please read and keep these instructions. Indoor use only.
09/2023
Advertisement
Table of Contents
Related Manuals for Avantco Equipment 184BT18H
Summary of Contents for Avantco Equipment 184BT18H
- Page 1 User Manual 09/2023 Vertical Contact Bun Toasters Standard Length Feed Tray: #184BT18A 120V • 1600W #184BT18H 208/240V • 2800/3200W Extended Length Feed Tray: #184BT18AXL 120V • 1600W #184BT18HXL 208/240V • 2800/3200W Warning: For Your Safety: Improper installation, adjustment, alteration, service, or Do not store or use gasoline or other flammable vapors or maintenance can cause property damage, injury, or death.
- Page 2 Safety Precautions .............................3 Upon Arrival ..............................4 Installation ..............................4 Operation ..............................6 Cleaning & Maintenance .......................... 7 Troubleshooting ............................8 #184BT18A & #184BT18AXL NEMA 5009704 5009704 5-15P #184BT18H & #184BT18HXL NEMA 5009704 5009704 6-20P CONFORMS TO NSF/ANSI STD. 4 CONFORMS TO UL STD. UL-197 www.AvantcoEquipment.com...
- Page 3 User Manual Vertical Contact Bun Toasters Safety Precautions WARNING • Read all instructions carefully and completely. • For commercial use only. • DO NOT touch hot surfaces. • Protect against electrical shock by keeping all cords, plugs, and other electrical components away from water or other liquids.
- Page 4 User Manual Vertical Contact Bun Toasters Upon Arrival Examine carton for damage. The freight carrier has assumed responsibility for its safe transit and delivery. If equipment is received damaged, either apparent or concealed, a claim must be made with carrier. •...
- Page 5 User Manual Vertical Contact Bun Toasters Installation NOTE: It is highly recommended that you install the non-stick sheet for best performance. Every unit is shipped with (10) non-stick sheets. Please contact customer service if you did not receive these sheets. If you do not install the non-stick sheet, there is a risk that buns will stick to the plate and burn.
- Page 6 User Manual Vertical Contact Bun Toasters Operation GENERAL USE Thoroughly clean the unit as described in the cleaning section of this manual. 2. Turn on the main switch. The conveyor will now run. 3. Set the temperature to approx. 400˚F, which is between 6 and 7 on the scale.
- Page 7 Cleaning User Manual Vertical Contact Bun Toasters Operation CONVEYOR ADJUSTMENT If optimal bun grilling is not achieved using the speed and temperature settings, it is possible to adjust the position of the conveyor system relative to the grill plate. Moving the conveyor closer to the grill plate will apply more pressure to the bun and result in more effective toasting.
- Page 8 User Manual Vertical Contact Bun Toasters Troubleshooting Problem Possible Causes Action No power at wall receptacle. Check supply circuit breaker. Plug disconnected. Check that plug is fully connected. Unit dead, no power. Main switch off. Check that the switch is on. Supply circuit breaker tripped.
