- Page 1 Instructions for Use and Installation 60cm built-in electric oven HNTB65XL...
-
Page 2: Table Of Contents
Contents For Your Safety ........3 Use and Care Controls . -
Page 3: For Your Safety
For Your Safety We recommend that you read the instructions in this owner's manual carefully before use for the best performance and to extend the life of your appliance. It will provide you with all the information you need to ensure its safe installation, use and maintenance. Retain this owner's manual for future reference. - Page 4 For Your Safety Packaging items such as plastic bags, polystyrene, nails, etc. are potentially dangerous, and therefore appropriate measures must be taken to prevent children and the disabled from coming into contact with them. Avoid the following: Touching the appliance with wet parts of the body. ・...
- Page 5 For Your Safety WARNINGS: ・ DO NOT steam clean the oven. ・ DO NOT use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
-
Page 6: Use And Care
Use and Care Controls Oven Temperature Indicator Light 5 Function Model °C Cooking Mode Cooking Temperature Selection Knob Selection Knob Decrease time Function Increase time... -
Page 7: Oven & Accessories
Use and Care Oven & Accessories Depending on which model you have, ovens are supplied with chrome wire Shelf Supports or chrome wire/telescopic Shelf Supports. There are five shelf positions for all models, some models include two telescopic supports. Grill Tray with Level 5 removable insert Level 4... -
Page 8: How To Use Your Oven
Use and Care How to use your oven This Fan Forced Oven is an extremely versatile appliance that allows you to choose easily and safely between different cooking modes. The various cooking modes are selected by means of a cooking mode selection knob, located on the control panel. To operate the oven: ・... -
Page 9: Positioning The Oven Trays & Shelves
Use and Care Positioning the oven trays & shelves The Grill Tray or Oven Shelf can be located in any of the five height positions in the oven. Refer to the ‘Cooking Guide Table’ for the recommended shelf position. When fitting the trays or shelves, ensure they are fitted between the two wires that are closest together as shown below. -
Page 10: Cooking Modes
Use and Care COOKING MODES Grill mode Select ‘Grill’ mode with cooking mode selection knob and turn cooking temperature selection knob to ‘Max’. When set to Grill mode, the top element operates. The extremely high and direct temperature of the grill makes it possible to brown the surface of meats and roasts while locking the juices in to keep them tender. - Page 11 Use and Care Defrost mode When set to ‘Defrost’ mode, the fan located at the back of the oven circulates room temperature air around the food. This is recommended for the defrosting of all types of food, but in particular for delicate types of food which do not require heat, for example: ice cream cakes, cream or custard desserts, fruit cakes, etc.
-
Page 12: Button Digital Clock
Use and Care 3 BUTTON DIGITAL CLOCK This model has a digital display, 24hr clock with 3 control buttons. When the power is connected, the screen displays ‘12:00’ and the bar above the symbol. Adjusting the digital clock To set the correct time, press the + or - button to advance forward or backward until the correct time is displayed. - Page 13 Use and Care When the clock displays 14:00, the oven automatically stops cooking. The alarm will ring and the bar will flash, press any button and the ringing will stop. Semi-automatic setting There are two methods of semi-automatic cooking: A. Start cooking now and set cooking time: This semi-automatic setting of the oven allows you to start cooking immediately, set the cooking time (up to 10 hours), select the temperature and cooking mode.
- Page 14 Use and Care Timer The digital countdown timer can be set up to 23 hours and 59 minutes maximum. To set the timer, press the function button repeatedly until the bar above is displayed. Once the function button is released, the current time is displayed and the bar above flashes.
-
Page 15: The Oven Light
Use and Care The oven light Set cooking mode selection knob to symbol to switch on the oven light/s. The oven light/s stay on when the oven is operating. Cooling ventilation In order to cool down the exterior of the appliance, this model is equipped with a cooling fan, which switches on automatically. - Page 16 Use and Care Multi shelf cooking If you want to cook food on several shelves, select the ‘Fan Forced’ mode as this is the only cooking mode that allows you to do so. When cooking delicate foods on more than one shelf, use the ‘Fan Forced’...
- Page 17 Use and Care Baking cakes When baking cakes ,always place them in a preheated oven. Make sure you wait until the oven has been preheated thoroughly (the indicator light will turn off). To prevent heat loss and the cake from dropping, do not open the oven door during baking.
- Page 18 Use and Care Cooking pizza For best results when cooking pizza, use the ‘Fan Forced’ mode · Preheat the oven for at least 10 minutes. · Use a light aluminum pizza pan, placing it on the shelf supplied with the oven. Don’t use the dripping pan since this will extend the cooking time, making it difficult to get a crispy crust.
-
Page 19: Cooking Guide
Use and Care Cooking guide (on 2 shelves) (on 2 shelves) (on 2 shelves) (on 3 shelves) (on 3 shelves) (on 3 shelves) Note: Cooking times are approximate and may vary according to personal taste. When cooking using the grill or fan assisted grill, the dripping pan must always be placed on the 1st oven shelf from the bottom. -
Page 20: Cleaning And Maintenance
Use and Care Cleaning and maintenance Before cleaning your oven or performing maintenance, make sure that the cooking mode selection knob is set to ‘OFF’ and the cooking temperature selection knob is set to ‘OFF’. To extend the life of your oven, it must be cleaned frequently. The enamelled or stainless steel parts should be washed with lukewarm water without using any abrasive powders or corrosive substances. -
Page 21: How To Dismantle The Oven Door For Cleaning
Use and Care How to dismantle the oven door for cleaning Method 1 1. Open the door or remove the door (can be done either way) and push the round pins on either side of the door. 2. While holding them pressed in, pull the end panel (A) out. 3. - Page 22 Use and Care How to dismantle the oven door for cleaning Method 2 1. Flip the glass pane retainers outwards to open them. 2. Gently lift up the inner pane and remove it. 3. Gently lift up the middle pane/s and remove it. 4.
-
Page 23: How To Remove The Oven Door
Use and Care How to remove the oven door You can remove the oven door for better access to the oven when cleaning. Proceed as follows to remove the door: · Open the door fully (1). · Lift up and turn the latch situated on each of the two hinges (2). ·... -
Page 24: Replacing The Oven Lamp
Use and Care Replacing the oven lamp WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. Remove the glass cover of the lamp-holder as shown below. Remove the lamp and replace with a lamp resistant to high temperatures (300°C) with the following characteristics: - Voltage: 220-240V - Wattage: 25W... -
Page 25: Installation
Installation IMPORTANT: Installation, assembly and electrical connections must be carried out by authorised personnel. Cabinet details In order to ensure that the built-in appliance functions properly, the cabinet containing it must be appropriate. The figure below gives the dimensions of the cut-out for installation under the counter or in a wall cabinet unit. -
Page 26: Electrical Connection
Installation The panels of the adjacent cabinets must be made of heat- resistant material. In particular, cabinets with a veneer exterior must be assembled with glues which can withstand temperatures of up to 75°C. In compliance with current safety standards, contact with the electrical parts of the oven must not be possible once it has been installed. -
Page 27: Technical Data
Installation Technical data Inner dimensions of the oven: Width: 45cm Depth: 41cm Height: 40cm Gross Oven Volume: 83 litres. Net Oven Volume: 70 litres. Voltage and Frequency of Power Supply: 220-240V ~ 50-60Hz Power Usage: 2215-2635W... - Page 28 READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING THE APPLIANCE. The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. The manufacturer is not responsible for any inaccuracies, due to printing or transcription errors, contained in this handout.
