Akai ACS-656 User Manual

Hide thumbs Also See for ACS-656:

Available languages

Download this manual

ACS-656

USER GUIDE

6.5" - 4 WAY SPEAKERS

▪ FREQUENCY: 70-21KHZ

▪ SENSITIVITY: 89dB/W/M

▪ MAX POWER: 200W

▪ MAGNET: 219 GRAMS

▪ VOICE COIL: 25MM

▪ MIDRANGE AND TWEETER: 40MM MYLAR

DOME TWEETER AND 2x15MM PIEZO TWEETER

■

WIRING CONNECTION (Fig. I)

Please watch for polarity

⑤

Car stereo

⑥ Left

⑦ Right

⑧ Red

⑨ Black

⑩ Red

⑪ Black

⑫ Left speaker (4 ohms)

⑬ Right speaker (4 ohms)

■ CONNECTION DIAGRAM

■

CONTENTS

■ CONNECTION DIAGRAM

EN-ENGLISH

Page 1 EN-ENGLISH ACS-656 USER GUIDE ■ CONTENTS 6.5" - 4 WAY SPEAKERS ▪ FREQUENCY: 70-21KHZ ▪ SENSITIVITY: 89dB/W/M ▪ MAX POWER: 200W ▪ MAGNET: 219 GRAMS ▪ VOICE COIL: 25MM ▪ MIDRANGE AND TWEETER: 40MM MYLAR DOME TWEETER AND 2x15MM PIEZO TWEETER ■...
Page 2 EN-ENGLISH DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIPMENT This symbol on the product or packaging means that the product should not be treated as household waste. Do not throw garbage at the end of its life, but take it to a collection center for recycling.
Page 3 RO-ROMANA ACS-656 GHID DE UTILIZARE CONȚINUT ■ DIFUZOARE DE 6.5" - 4 CĂI ▪ FRECVENȚĂ: 70-21KHZ ▪ SENSIBILITATE: 89dB/W/M ▪ PUTERE MAXIMĂ: 200W ▪ MAGNET: 219 GRAME ▪ BOBINĂ VOCALĂ: 25MM ▪ MIDRANGE ȘI TWEETER: 40MM MYLAR DOME TWEETER ȘI 2x15MM PIEZO TWEETER ■...
