- Page 1 ESSCH60RC User Guide & Installation Handbook Part No 083341900 Date 05/12/2013...
- Page 2 CONTENTS & INTRODUCTION CONTENTS WARRANTY • SAFETY Your new appliance comes with our 2 year electrical and mechanical breakdown war- • USING THE PRODUCT ranty. To register your appliance please • CLEANING call: 01759 48 78 32 • INSTALLATION INSTRUCTIONS •...
- Page 3 SAFETY appliance. Cleaning and BEFORE USING THE PRODUCT Make sure that you have removed all user maintenance shall packaging and wrapping. Some of the not be made by children items inside this appliance may have additional wrapping. without supervision. GENERAL WARNING! - WARNING! - The Unattended cooking on...
- Page 4 SAFETY during use, as this will correctly fitted. seriously affect the WARNING! - There is safety and performance, a risk of electric shock, particularly in relation so always make sure to surface temperatures you have turned off becoming hot and gas and unplugged your operated parts not appliance before...
- Page 5 SAFETY electrical switch. on the hob surface since they can get hot. Contact your local gas supplier immediately. Ensure you switch off the appropriate cook ELECTRIC INDUCTION HOB zone individually or (by WARNING:- the central on/off key if Unattended cooking on touch control) when you a hob can be dangerous have finished cooking,...
- Page 6 SAFETY fail-safe. The pacemaker Prolonged intensive use must be designed of the appliance may call in compliance with for additional ventilation, the appropriate for example opening regulations. of a window, or more effective ventilation, Caution: This appliance for example increasing is for cooking purposes the level of mechanical only.
- Page 7 SAFETY the hob when you’re not damaged. around - take them off The glass ceramic can the cook zone if you get hot whilst cooking; have to leave the kitchen even though the cook even if you think it will zone itself does not only be for a moment, generate heat.
- Page 8 SAFETY This hob is not intended to be kitchen: opertated by means of a external • Pull the plug out, or switch off the timer or seperate remote control power at the fuse box - this may be system. enough to stop the fire immediately Fire Safety Advice •...
- Page 9 USING THE HOB - ELECTRIC (CERAMIC) Using Rotary Controls switched on a cook zone and remains lit for a while after all the cook zones • Select the cooking zone you wish to have been switched off to show that use.
- Page 10 CLEANING ELECTRIC HOB follow the circular grooves and avoid damaging the red spots. Make sure Ceramic glass hobs that you allow the hotplate to dry before use by switching on the ele- • It is recommended that you clean ments at a low heat. and wash the hob surface before using for the first time.
- Page 11 INSTALLATION General information between hob base and appliance must be maintained. Installation should only be carried out by Installation above an oven a qualified installer or engineer. Please keep to the following points most Refer to the manufacturer’s instructions carefully; for clearances above the oven.
- Page 12 INSTALLATION Clearances and dimension – require- There must be a minimum clearance of ments 50mm between the rear edge of the hob and the rear wall. This clearance must No shelf or overhang of combustible be maintained up to 650mm above the material should be closer than 650mm worktop.
- Page 13 INSTALLATION Fitting into worktop Recessed Method Cut a hole in the work surface to the Recess the work top to the appropriate required size. The worktop must be of depth (Approx 5mm) and shape to fit the heat-resistant material or covered with hob (add 1mm to overall glass size).
- Page 14 INSTALLATION Installation Bracket Advice Installation pack 2 Secure the hob to the worktop by means 4 x Cranked installation bracket of the brackets provided, taking the thick- 4 x Spire clips (70/77/90cm appliances ness of the worktop into account. only) 4 x No8 Screws UNDERSIDE OF HOB Depending on your appliance the cranked...
- Page 15 INSTALLATION CONNECT TO THE ELECTRICITY • Remove the cable clamp screw and SUPPLY release the cable clamp retaining arm. WARNING: This appliance must be earthed. Only connect to the electrical Note; mains terminal with the power switched The cable clamp has a ratchet type off.
- Page 16 TECHNICAL DATA SUPPLY: 220 -240V ~ 50Hz 4.85kW - 6.20kW Refer to the data badge on the under side of your hob for specific power rating of your model...
- Page 17 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 18 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 19 Please keep this handbook for future reference, or for anyone else who may use the appliance.
- Page 20 CUSTOMER CARE To contact essentials about your appliance, please call Warranty Registration 01759 48 78 32 to register your appliance Customer Care Helpline 0843 507 3431 in case of difficulty within the UK Please ensure that you have the product’s model no and serial no available when you call.
