- Page 1 DBC430AV / DBC520AV Gasoline Brush Cutter USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY ..............................2 2. QUICK START ............................7 3. STARTING PROCEDURE ........................11 4. STOPPING PROCEDURE ........................13 5. USING THE MACHINE .......................... 14 6. MAINTENANCE ............................. 16 7. TROUBLESHOOTING ........................... 20 8. SPECIFICATIONS ..........................21 9. PARTS LOCATION ..........................21 10. -
Page 3: Safety
1. SAFETY 1.1. General safety notes. 1.1.1. The operator of the machine is responsible for, and has a duty of care in making sure that the machine is operated safely and in accordance with the instructions in this user manual. Keep the manual safe and pass it on if the machine is loaned or sold to another user. - Page 4 1.2. Carbon monoxide (where applicable). 1.2.1. Carbon monoxide is a colourless and odourless gas. Inhaling this gas can cause death as well as serious long term health problems such as brain damage. 1.2.2. The symptoms of carbon monoxide poisoning can include but are not limited to the following; Headaches, dizziness, nausea, breathlessness, collapsing or loss of consciousness.
- Page 5 lidded bin. 1.3.5. ALWAYS dispose of waste fuels correctly. 1.4. Fuelling/De-fuelling (where applicable). CAUTION ALL FUELS ARE FLAMMABLE 1.4.1. ALWAYS fuel and defuel in a wellventilated area outside of buildings. 1.4.2. ALWAYS wear correct, suitable and fit for purpose Personal Protective Equipment (PPE), suggested items are but not limited to safety gloves and overalls.
- Page 6 electrolyte may be in liquid or gel form. 1.6.2. Should you come into contact with electrolyte you should; 1.6.2.1. Remove all clothing contaminated with electrolyte. If you cannot remove then saturate in water. 1.6.2.2. Get medical assistance as soon as possible. You must advise the medical staff of the type acid.
- Page 7 1.9. Additional safety labels. Keep all children, bystanders and helpers 15 meters from the machine. Warning against flying objects wear helmet, goggles and ear protection. Warning: Danger from hot components, especially exhaust - Keep clear of combustible materials. 1.10. Additional safety instructions. 1.10.1.
-
Page 8: Quick Start
2. QUICK START 2.1. This guide is meant to serve as a quick reference for operating your DAEWOO brush cutter It is for convenience and the user should read the safety section first. OUTDOOR USE ONLY. This brush-cutter produces carbon monoxide - a poisonous, colourless & odourless gas that can cause death or serious injury. - Page 9 Align hole on drive spacer with groove on the guard, then using the Allen key lock the shaft in place – once shaft is locked you can tighten the trimmer head. 2.8. Cutting blade assembly. (Instruction to suit either 3 or 5 bladed cutter). Place the drive spacer over the threaded drive –...
- Page 10 Place the over the threaded drive, then place spacer over threaded drive– N.B. Raised area to be toward the thread. N.B. There should be now writing showing. Once blade is in place, put the stainless steel cover over the spacer, put lock-nut onto threaded shaft and loosely tighten (anti-clockwise direction).
- Page 11 2.12. Mixing two stroke oil. Fill the mixing bottle with fresh unleaded petrol to the fuel level line. For the first fill use the ratio of 25:1 thereafter use a ratio of 40:1. 2.13. Adding fuel. Unscrew the fuel tank cap and carefully add a fuel/2 stroke oil mixture as in section 2.12. DO NOT overfill and allow a 25 mm gap at the top of the tank.
-
Page 12: Starting Procedure
3. STARTING PROCEDURE Fill with fuel/oil mixture, make sure the fuel cap is secure. - Set the ignition switch on the handle to the ON position. Pump the primer bulb several times until fuel shows in the bulb. - Page 13 For COLD start set the choke lever to the ON position by moving upwards as shown. For a WARM start keep the choke lever at the OFF position. Place one hand on the machine, and using the other hand pull the recoil until you feel a resistance, then pull briskly.
-
Page 14: Stopping Procedure
Once the engine has started press the throttle lever and throttle safety together. This will accelerate the machine to cutting speed. To lock the throttle press the throttle lock button. To release the throttle lock lightly press the throttle lever. 4. -
Page 15: Using The Machine
5. USING THE MACHINE 5.1. Before starting work. 5.1.1. YOU MUST check the work area for obstacles such as stones, metal rods or other objects. If these cannot be removed, mark these positions, so you can avoid contact with the trimmer head and objects. - Page 16 5.4. Trimming techniques. CAUTION If you are not familiar with the trimming, practice with the machine with the machine stopped. 5.4.1. Always trim or cut with the engine running at high speed. 5.4.2. Do not run the machine slowly except for when warming up before use or cooling down after use.
-
Page 17: Maintenance
6. MAINTENANCE WARNING Always stop the engine and unplug the spark plug before doing any repairs or maintenance. Never touch the rotating nylon cord or blade. Check and maintain fuel level regularly, and maintain the fuel/oil mix to the correct ratio. Frequently check the brush cutter and make sure that all grass deposits are removed from the trimmer head and/or blade Check the blade, in order to obtain a good cut, the blade should always be sharp and well balanced. - Page 18 6.1 Air filter Never let the engine run without the air filter. A dirty air affects the engine performance, increases fuel consumption and makes it difficult to start. If you notice a loss of engine power. 6.1.1. Push clip (1) down and pull filter cover (2) away from machine, take care to release lower clips (3).
- Page 19 6.2.8. Refit the spark plug cap onto the spark plug. 6.3 Trimmer blade sharpening WARNING When sharpening the blade you MUST wear safety gloves. 6.3.1. Remove the cutting blade (2) from the shield (1). 6.3.2. Put cutting blade securely into a vice. 6.3.3.
- Page 20 6.4. Storage. WARNING If you do not follow these steps, deposit may arise in the carburetor. This will cause starting difficul- ties and may cause permanent damage. 6.4.1. Perform all the general maintenance that the maintenance section of your ‘User Manual’ is recommended.
-
Page 21: Troubleshooting
7. TROUBLESHOOTING CAUTION 7.1. If troubleshooting does not solve the problem, contact your dealer or the manufacturer directly. Use only original parts approved by the manufacturer, otherwise a hazard risk arises. NO SPARK. MOTOR DOES NOT COME UP TO SPEED Possible causes;... -
Page 22: Specifications
8. SPECIFICATION DBC520AV DBC430AV Engine model:1E44F-5 Engine model: 1E40F-5 Engine type: Air cooled, two stroke, Engine type: Air cooled, two stroke, single cylinder single cylinder Displacement: 52 cc Displacement: 43 cc Power: 1.45 kW / 2.0 hp Power: 1.25 kW / 1.7 hp Idling speed: 3000±200 rpm... -
Page 23: Recycling & Products Disposal
10. RECYCLING & PRODUCT DISPOSAL 11.1. We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries instead the responsibility to dispose of WEEE and or Batteries is passed onto you by us. So when it becomes necessary to dispose of your machine you must take it to your local Civic. -
Page 24: Warranty
Manufactured under license of Daewoo International Corporation, Korea...
