PCB Piezotronics ICP W393B05 Installation And Operating Manual page 17

PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
1.28 [32.5]
A
1 ADD CABLE FOR SENSOR WITH WATER RESISTANCE CONNECTOR OPTION
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010
ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH
1"≤ LENGTH < 1' = +1"/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
5'≤ LENGTH < 100' = +6"/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII
.003 - .005
2
.97 [24.6]
DIMENSIONS IN MILLIMETERS
JJF
[ IN BRACKETS ]
DECIMALS X ± 0.8
XX ± 0.25
TITLE
ANGLES  2 DEGREES
CABLE TOLERANCES IN METRIC
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
FILLETS AND RADII
0.07 - 0.13
2
REV
D
INTEGRAL SEALED CABLE 1
10-32 UNF - 2A
COAXIAL
ELECTRICAL CONNECTOR
DRAWN CHECKED
5/10/22 5/10/22
JJF
OUTLINE DRAWING
MODEL 393B04/ 393B05 SERIES
ACCELEROMETER
1
REVISIONS
DESCRIPTION
OAL 1.28 [32.5] WAS 1.27 [32.3]

10-32 UNF - 2B .17[4.3]
 
.21[5.3] .020[0.51]
MOUNTING HOLE
 
.99 [ 25.1]
ENGINEER
5/10/22
BAM
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE: 2X
1
DIN
52850
B
A
14129
SHEET 1 OF 1
