Innsky 55PA2US - Air Fryer Manual

Specifications

Model 55PA2US
Rated Voltage 110-120V 60Hz
Power 1700W
Capacity 5.8QT

warning Note: Please contact Innsky Customer Support Team should you encounter problems or require accessories replacement.

Important Safeguards

  1. This appliance is not intended for use by persons (including childrenyounger than 8) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they are under supervision.
  2. Check if the voltage indicated on the appliance corresponds to thelocal main voltage before you connect the appliance.
  3. Do not use the appliance if the plug, the main cord or the applianceitself is damaged. Always make sure that the plug is inserted properly into a wall outlet.
  4. Close supervision is necessary when any appliance is used by or nearchildren. Children should be supervised to ensure that they do not play with the appliance. Cleaning and user maintenance shall not be done by children unless they are older than 8 and supervised.
  5. Do not let the cord hang over the edge of table or counter. Keep awayfrom hot surfaces.
  6. To protect against electric shock do not immerse cord, plugs, orappliance in water or other liquid. Do not plug in the appliance or operate the control panel with wet hands.
  7. Never connect this appliance to an external timer switch or separateremote-control system in order to avoid a hazardous situation. To disconnect, turn off the appliance, then remove plug from the wall outlet.
  8. Do not place the appliance on or near combustible materials such asa tablecloth or curtain. The accessible surfaces may become hot during use. Do not place on or near a hot gas or electric burner, or in a heated oven.
  9. Do not place the appliance against a wall or other appliances. Leave at least 4 inches of free space on the back and sides and 4 inches of free space above the appliance. Do not place anything on top of the appliance.
  10. Do not use the appliance for any other purpose than described in thismanual. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
  11. Do not let the appliance operate unattended. Extreme caution must beused when moving an appliance containing hot oil or other hot liquids.
  12. Do not use outdoors.
  13. Do not touch the hot surfaces; use handle. During hot air frying, hotsteam is released through the air outlet openings. Keep your hands and face at a safe distance from the steam and from the air outlet openings.
  14. Also be careful of hot steam and air when you remove the pan fromthe appliance.
  15. After using the appliance, the metal cover inside is very hot, avoidcontact with it after cooking. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.
  16. Immediately unplug the appliance if you see dark smoke coming out ofthe appliance. Wait for the smoke emission to stop, before you remove the pan from the appliance.
  17. FOR HOUSEHOLD USE ONLY.

Features

Thank you for purchasing Innsky Air Fryer. Please read this Manual carefully BEFORE using for your own safety. There are many benefits of using an Air Fryer:

  • Easy controls for cooking quick, healthy meals.
  • Generous 5.8QT frying capacity.
  • Rapid air circulation system makes cooking faster with lower energy.
  • Healthy alternative to cook deep fried food with no oil.
  • Air frying makes food tasty while retains its nutritional value.

Product Diagram

Product Diagram

  1. Control Panel
  2. Main Body
  3. Heating Element
  4. Safety Switch
  5. Frying Basket Handle
  6. Frying Tray
  7. Frying Basket
  8. Frying Basket Release Button Cover
  9. Frying Basket Release Button

Control Panel

Control Panel

  1. Mode Indicators
  2. Time +
  3. Time Indicator
  4. Time –
  5. Mode Button
  6. Power Button
  7. LED Display
  8. Start / Stop
  9. Temperature –
  10. Temperature Indicator
  11. Temperature +

Before First Use

  1. Remove all packaging and any stickers or labels from the appliance.
  2. Thoroughly clean the pan and basket with warm water, some dishwash ing detergent and a non-abrasive sponge.
  3. Wipe the inside and outside of the appliance with a moist cloth.

warning Note:
During the first a few times of using your new Air Fryer there might be a "hot plastic" smell. This is perfectly normal in new Air Fryers as the material is heated for first time. It will go away after several uses.

Preparing for Use

  1. Place the appliance on a stable, horizontal, even and heat-resistant surface.
  2. Put the basket into the pan. Place the ingredients in the basket-do notoverload.
  3. Plug the Air Fryer into an electrical wall outlet. The unit is in standbymode with the Power Button indicator lighting up in red.
  4. Place the frying tray into the main body.

warning Note:
Please cover the Frying Basket Release Button with its cover when operating to avoid accidental pressing of the Button dropping the frying tray.

Power On / Off

Tap the Power Button to turn on / off the unit.

Choose the Cooking Mode

  1. When the unit is on, tap the Mode Button to choose the cooking modeas desired. The corresponding mode indicator and the Start / Stop indicator will keep flashing.
  2. Tap the Start / Stop Button to start cooking in the chosen mode. Themode indicator will light up accordingly.
  3. Take out the frying tray during the cooking process, the air fryer willpause working. Place it back into place to resume working under previous remaining time and temperature.
  4. A beep will be heard when cooking is completed.

information Tip:
After hot air frying, the pan and the ingredients are hot - avoid touching. Depending on the type of the ingredients in the air fryer, steam may escape from the pan.

Set the Cooking Time

  1. Tap the Time Buttons to increase / decrease the cooking time with adifference of one minute in each tap.
  2. Once set, the cooking time on the LED display will flash three times toconfirm your setting.

Set the Cooking Temperature

  1. Tap the Temperature Buttons to increase / decrease the cookingtemperature with a difference of 10℉ in each tap.
  2. Once set, the cooking temperature on the LED display will flash three times to confirm your setting.

Recommendation for Cooking Time and Temperature

Min-max Amount (g) Time (min.) Temperature (°C) Shake Extra information
Potato & fries
Thin frozen fries 400-500 18-12 200 Shake
Thick frozen fries 200 Shake
Potato gratin 600 20-25 200 Shake
Meat & Poultry
Steak 100-600 10-15 180
Pork chops 100-600 10-15 180
Hamburger 100-600 10-15 180
Sausage roll 100-600 13-15 200
Drumsticks 100-600 25-30 180
Chicken breast 100-600 15-20 180
Snacks
Spring rolls 100-500 8-10 200 Shake Use ovenready
Frozen chicken nuggets 100-600 6-10 200 Shake Use ovenready
Frozen fish fingers 100-500 6-10 200 Use ovenready
Frozen bread crumbed cheese snacks 100-500 8-10 180 Use ovenready
Stuffed vegetables 100-500 10 160
Baking
Cake 400 20-25 160

Use baking

tin

Quiche 500 20-22 180 Use baking tin/oven dish
Muffins 400 15-18 200

Use baking

tin

Sweet snacks 500 20 160 Use baking tin/oven dish

warning Note:

  • The above information is for reference only, cooking time and temper ature may vary as per the size, origin, shape and other factors of the ingredients.
  • Add 3 minutes to the preparation time when you start frying while the air fryer is still cold.

Cleaning

Please always unplug the appliance from the power source and let it cool down before cleaning.

  1. Push the Frying Basket Release Button Cover, and press the FryingBasket Release Button to remove the frying basket from the tray. Clean the frying tray and basket with moderate detergent. Rinse under tap water. Never use metal cleaning brush to avoid damaging the non-stick coating. Or put them into dishwasher for cleaning.
  2. Clean the heating element with a cleaning brush to remove any foodresidues.
  3. Wipe the main body of the unit with damp cloth.
    Cleaning

warning Note:

  • Clean the appliance after every use.
  • It is recommended to use degreasing liquid to remove any remaining dirt.

information Tip:
If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot water with some washing-up liquid. Put the basket in the pan and soak for approximately 10 minutes.

Storage

  1. Unplug the appliance and let it cool down.
  2. Make sure all parts are clean and dry.

Troubleshooting

Problem Possible Cause Solution
The air fryer does not work The appliance is not plugged in Plug the power plug into a grounded wall socket
Did not set the time Tap the Time Buttons to set the cooking time
The pan is not put into the appliance properly Place the pan into the appliance properly
The ingredients fried in the air fryer are not done The amount of ingredients in the basket is too much Put smaller batches of ingredients into the basket for more even frying
The set temperature is too low Tap the Temperature + Button to increase the cooking temperature
The cooking time is too short Tap the Time + Button to increase the cooking time
The ingredients are fried unevenly in the air fryer Certain types of ingredients need to be shaken halfway through the cooking time Take out the frying tray and shake it during a cooking process
Fried snacks are not crispy when they come out of the air fryer You used a type of snack meant to be prepared in a traditional deep fryer Use oven snacks or lightly brush some oil onto the snacks for a crispier result
Failed to slide the pan into the appliance properly The basket is overfilled Do not fill the basket beyond max line
White smoke comes out of the appliance You are preparing greasy ingredients When you fry greasy ingredients in the air fryer, a large amount of oil will leak into the pan. The oil produces white smoke and the pan may heat up more than usual. This does not affect the appliance or the end result
The pan still contains grease residues from previous use White smoke is caused by grease heating up in the pan. Make sure you clean the pan and basket properly after each use
