DTS ALCHEMY 3 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ALCHEMY 3
USER'S MANUAL rel. 1.1 GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALCHEMY 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DTS ALCHEMY 3

Summary of Contents for DTS ALCHEMY 3

  • Page 1 ALCHEMY 3 USER’S MANUAL rel. 1.1 GB...
  • Page 2 Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S . D.T.S.

  • Page 3: Table Of Contents

    INDEX: 1 - SYMBOLS ........................ 4 2 - GENERAL WARNING ..................... 5 3 - GENERAL WARRANTY CONDITIONS ..............5 4 - TECHNICAL FEATURES ..................5 5 - ACCESSORIES ....................... 7 6 - IMPORTANT SAFETY INFORMATION ..............8 6.1 Fire prevention...................... 8 6.2 Prevention of electric shock ..................

  • Page 4: Symbols

    1- SYMBOLS Graphic symbols used on this manual: THIS SYMBOL INDICATES A HOT SURFACE THIS SYMBOL INDICATES ELECTRIC SHOCK RISK THIS SYMBOL INDICATES GENERAL RISK THIS SYMBOL MEANS “SUITABLE FOR INDOOR USE ONLY” THIS SYMBOL INDICATES THE MAXIMUM OPERATING AMBIENT TEMPERATURE THIS SYMBOL INDICATES THE MINIMUM DISTANCE FROM THE OBJECTS AND THE PEOPLE LIT BY THE LIGHT BEAM...

  • Page 5: General Warning

    The warranty covers defects in materials and workmanship. The warranty is not appliable where a defect is caused by misuse or unauthorised repair of the product. Any functional or/and physical modification of the product is not allowed. 4- TECHNICAL FEATURES DTS Product Code: 03.MW010 ALCHEMY 3 OUTPUT •...
  • Page 6 • Art-Net 4, sACN protocols available on request • ‘Standard’ and ‘Silent’ operation modes • Internal operating system updatable via DTS dongle firmware uploader • Li-Fe backup battery for controlling the display settings even when the unit is not powered •...

  • Page 7: Accessories

    (indicated for any kind of loads vertical / horizontal) • Professional Quick trigger clamp (Max load 100 Kg) (code 0521A037) (not indicated for horizontal load) • Safety cable 3 x 600 mm (Max load 30 Kg) (code 0521A010) • DTS Dongle firmware uploader (code 03.LA.206)

  • Page 8: Important Safety Information

    Unplug the unit prior to performing any function which involves touching the inside of the moving head. -The level of technology inherent in the ALCHEMY 3 requires the assistance of specialised personnel for all servicing. Please refer to an authorised DTS service centre.

  • Page 9: Retractable Top Hat

    ALCHEMY 3 is moving. Four 1/4 turn Fast Locks connections placed in the base of the unit allow to hang the ALCHEMY 3 by using a Omega bracket (provided in the box) in conjunction with Aliscaf clamp (available on demand).

  • Page 10: Safety Cable

    8.1- Safety cable A safety cable must be securely fixed to the ALCHEMY 3 and to the suspension truss in order to avoid the fixture accidentally falling should the main fixing point fail. Make sure that the safety cable or chain can bear the weight of the entire unit.

  • Page 11: Protection Against Liquids

    Max 3 ALCHEMY units @ 100Vac PowerCON TRUE1 female panel connector 9.1- Protection The use of a thermal magnetic circuit breaker is recommended for each ALCHEMY 3. A good earth connection is essential for the correct operation of the projector.

  • Page 12: Dmx Signal Connection

    10- DMX SIGNAL CONNECTION The unit operates using the digital DMX 512 signal. Connection between the mixer and the projector or between projectors must be carried out using a two pair screened ø 0.5 mm cable and a XLR 5 or 3 pins connector. Ensure that the conductors do not touch each other.

  • Page 13: Dmx Addresses

    11- Art-Net / sACN SIGNAL CONNECTION ALCHEMY 3 can operates by using the Art-Net / sACN signal. The product with Ethernet interface on board is available on request. Connection between the mixer and the projector must be carried out using a category 5 network cable and a standard RJ45 connector.

  • Page 14: Ethernet To Rdm/Dmx Operation

    11.2-Ethernet to RDM/DMX operation For Ethernet to RDM/DMX operation connect the mixer Art-Net / sACN signal via Ethernet switch to the etherCON RJ45 input connector of the first unit only. In this configuration the first unit works as an Ethernet to DMX converter and sends RDM/DMX signal to its DMX output connector.

  • Page 15: Rdm Functions

    12- RDM FUNCTIONS By using a RDM controller it is possible to read / set DMX address, DMX mode and other parameters. ALCHEMY 3 accepts the following RDM commands: RDM Device Model ID: 0x0018 RDM PID DESCRIPTION RDM PID VALUE Category –...
  • Page 16 12- RDM FUNCTIONS RDM ADDITIONAL MESSAGEs: CURVE CURVE DESCRIPTION LINEAR QUADRATIC (default) GAMMA 2.2 S-CURVE OUTPUT RESPONSE TIME OUTPUT_RESPONSE_TIME_DESCRIPTION SMOOTH OFF SMOOTH 1 ( 25 ms) SMOOTH 2 ( 50 ms) SMOOTH 3 ( 75 ms) SMOOTH 4 (100 ms) (default) SMOOTH 5 (125 ms) SMOOTH 6 (150 ms) SMOOTH 7 (175 ms)
  • Page 17 12- RDM FUNCTIONS RDM ADDITIONAL MESSAGEs: MODULATION FREQUENCY MODULATION FREQUENCY DESCRIPTION 610 Hz 800 Hz 1.000 Hz (default) 1.500 Hz 2.000 Hz 2.500 Hz 3.000 Hz 3.500 Hz 4.000 Hz 4.500 Hz 5.000 Hz RDM MANUFACTURER’S SPECIFIC PIDs: RDM CUSTOM PID DESCRIPTION Set parameter DISPLAY –...

  • Page 18: Firmware Updating

    Updating the firmware release. Please follow the procedure below to perform the update: 1. Connect the DTS Dongle Firmware Uploader to a spare USB port on the PC. 2. Connect the unit DMX input to the DTS Dongle Firmware Uploader DMX output with a standard DMX cable and turn ON the unit.

  • Page 19: Display Functions

    Using these options, it is possible to change the fixture’s setting. Changing the DTS settings can vary the functions of the unit so that it does not respond to the DMX 512 used to control it. Carefully follow the instructions below before carrying out any variations or selections.
  • Page 20 MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION Allows to set the Pan PAN DIRECTION NORMAL movement. REVERSE Normal or Reverse. Normal (Default). Allows to set the Tilt TILT DIRECTION NORMAL movement. REVERSE Normal or Reverse. Normal (Default). Allows to set the Zoom ZOOM NORMAL movement.
  • Page 21 MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION Allows to set the NO DMX KEEP LAST DMX desired unit’s behavior ACTION in case DMX signal is missing or not available. Keep last valid DMX signal (Default). 48 pre-programmed PROGRAM 1-48 1 - 48 steps.
  • Page 22 MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION Allows to set GAMMA CORR. QUAD 2.0 quadratic current output for LED (Default). Allows to set gamma curve 2.2 . Allows to set S-curve S-CURVE to emulates light intensity characteristics of the tungsten halogen lamps.
  • Page 23 TRANSMITTER devices. LINK ALCHEMY 3 can be used as Wireless DMX transmitter/receiver. The product with Wireless DMX TX-RX interface on board is available on request. Operation as Receiver (default) Enable Wireless DMX control under WIRELESS -> STATUS menu.
  • Page 24 MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION Unit model, motors SYSTEM INFO SOFTWARE ALCHEMY 3 firmware release date, 15 NOV 2019 Motors board and LED Driver board firmware MOTOR: V.10 release. LED: V.1.00 LED: LED temperature TEMPERATURES LED: 041°C monitoring.
  • Page 25 MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION To restore factory DEFAULT settings. To reset head motors MANUAL RESET HEAD MOTORS only. CONTR. To reset Pan and Tilt PAN TILT only. To reset all motors. ALL MOTORS To restore parameters RESTORE DEF.

  • Page 26: Error Messages

    15- ERROR MESSAGES ERROR SHOWN ON DISPLAY APPEARS WHEN -Pan motor fault -Pan encoder fault -Pan motor driver on Pan&Tilt PCB fault -Wiring connection between Pan encoder and Pan&Tilt PCB fault PAN LOCKED -Pan locked -Pan motor fault -Pan encoder fault -Pan motor driver on Pan&Tilt PCB fault -Wiring connection between Pan encoder and Pan&Tilt PCB fault...

  • Page 27: Periodic Cleaning

    Fuse replacement Locate the fuse, which protects the lamp and electronics, in the base of ALCHEMY 3. Using a multimeter, test the condition of the fuse, replacing it with one of equivalent type (T 5A 250V) if necessary.

  • Page 28: Dmx Protocol

    18- DMX PROTOCOL 1. “CCT” mode (20 DMX channels) (Default) 1 PAN msb 2 PAN lsb 3 TILT msb 4 TILT lsb 5 SPEED MOVEMENT 6 SHUTTER 7 DIMMER msb 8 DIMMER lsb 9 CCT (1.800K – 10.000K) 10 GREEN SATURATION 11 GEL LIBRARY 1 12 GELS X-FADE 13 GEL LIBRARY 2...
  • Page 29 DMX CHANNEL 6 Parameter: SHUTTER DMX value Function 000-009 Black Out 010-019 Open 020-029 Black Out 030-119 Strobe (from 3,27s to 30ms) 120-149 Pulse up (from 42,6s to 120ms) 150-179 Pulse down (from 42,6s to 120ms) 180-189 Random strobe 190-199 Open 200-209 Effect wheel in Black Out while rotating...
  • Page 30 DMX CHANNEL 11 Parameter: GEL LIBRARY 1 DMX value Function 000-009 No function 010-011 M001: L 002 Rose Pink 012-013 M002: L 007 Pale Yellow 014-015 M003: L 015 Deep Straw 016-017 M004: L 019 fire 018-019 M005: L 020 medium amber 020-021 M006: L 021 Gold Amber 022-023...
  • Page 31 DMX CHANNEL 11 Parameter: GEL LIBRARY 1 DMX value Function 114-115 M053: L 182 Light Red M054: L 194 Surprise Pink 116-117 118-119 M055: L 195 zenith blue 120-121 M056: L 200 Double C.T. Blue 122-123 M057: L 201 Full C.T. Blue 124-125 M058: L 202 Half C.T Blue 126-127...
  • Page 32 DMX CHANNEL 13 Parameter: GEL LIBRARY 2 DMX value Function 000-009 No function 010-011 M001: L 002 Rose Pink 012-013 M002: L 007 Pale Yellow 014-015 M003: L 015 Deep Straw 016-017 M004: L 019 fire 018-019 M005: L 020 medium amber 020-021 M006: L 021 Gold Amber 022-023...
  • Page 33 DMX CHANNEL 13 Parameter: GEL LIBRARY 2 DMX value Function 114-115 M053: L 182 Light Red M054: L 194 Surprise Pink 116-117 118-119 M055: L 195 zenith blue 120-121 M056: L 200 Double C.T. Blue 122-123 M057: L 201 Full C.T. Blue 124-125 M058: L 202 Half C.T Blue 126-127...
  • Page 34 DMX CHANNEL 14 Parameter: GEL FILTER DESATURATION DMX value Function 000-255 Gel filters desaturation 0 = 100% color 255 = 0% color DMX CHANNEL 15 Parameter: FROST/COLOUR WHEEL DMX value Function 000-009 No Function 010-050 Reserved 051-090 Heavy frost 091-130 Deep blue filter switch ON (BLUE channel forced at full) 131-170 Deep red...
  • Page 35 DMX CHANNEL 19 Parameter: FIXTURE CONTROL Function 000-009 0 - No effect 010-024 1 – SMOOTH DIMMING OFF 025-026 2 - SMOOTH DIMMING 1 027-028 3 - SMOOTH DIMMING 2 029-030 4 - SMOOTH DIMMING 3 031-032 5 - SMOOTH DIMMING 4 (Default) 033-034 6 - SMOOTH DIMMING 5 035-036...
  • Page 36 DMX CHANNEL 19 Parameter: FIXTURE CONTROL Function 52 - reserved 53 - reserved 54 - reserved 55 - reserved 56 - reserved 57 - reserved 58 - reserved 59 - reserved 60 - reserved 61 - reserved 62 - reserved 135-136 63 - reserved 137-138...
  • Page 37 DMX CHANNEL 19 Parameter: FIXTURE CONTROL Function 235-236 107 – OPERATING MODE SILENT (Default) 237-238 108 - OPERATING MODE STANDARD 239-240 109 – reserved 241-242 110 – FAN MODE CONSTANT (Default) 243-244 111 – FAN MODE AUTO 245-246 112 – reserved 247-248 113 –...
  • Page 38 2. “ADVANCED” mode (28 DMX channels) 1 PAN msb 2 PAN lsb 3 TILT msb 4 TILT lsb 5 SPEED MOVEMENT 6 SHUTTER 7 DIMMER msb 8 DIMMER lsb 9 CCT (1.800K – 10.000K) 10 GREEN SATURATION 11 GEL LIBRARY 1 12 GELS X-FADE 13 GEL LIBRARY 2 14 GEL FILTER DESATURATION...
  • Page 39 DMX CHANNEL 6 Parameter: SHUTTER DMX value Function 000-009 Black Out 010-019 Open 020-029 Black Out 030-119 Strobe (from 3,27s to 30ms) 120-149 Pulse up (from 42,6s to 120ms) 150-179 Pulse down (from 42,6s to 120ms) 180-189 Random strobe 190-199 Open 200-209 Effect wheel in Black Out while rotating...
  • Page 40 DMX CHANNEL 11 Parameter: GEL LIBRARY 1 DMX value Function 000-009 No function 010-011 M001: L 002 Rose Pink 012-013 M002: L 007 Pale Yellow 014-015 M003: L 015 Deep Straw 016-017 M004: L 019 fire 018-019 M005: L 020 medium amber 020-021 M006: L 021 Gold Amber 022-023...
  • Page 41 DMX CHANNEL 11 Parameter: GEL LIBRARY 1 DMX value Function 114-115 M053: L 182 Light Red M054: L 194 Surprise Pink 116-117 118-119 M055: L 195 zenith blue 120-121 M056: L 200 Double C.T. Blue 122-123 M057: L 201 Full C.T. Blue 124-125 M058: L 202 Half C.T Blue 126-127...
  • Page 42 DMX CHANNEL 13 Parameter: GEL LIBRARY 2 DMX value Function 000-009 No function 010-011 M001: L 002 Rose Pink 012-013 M002: L 007 Pale Yellow 014-015 M003: L 015 Deep Straw 016-017 M004: L 019 fire 018-019 M005: L 020 medium amber 020-021 M006: L 021 Gold Amber 022-023...
  • Page 43 DMX CHANNEL 13 Parameter: GEL LIBRARY 2 DMX value Function 114-115 M053: L 182 Light Red M054: L 194 Surprise Pink 116-117 118-119 M055: L 195 zenith blue 120-121 M056: L 200 Double C.T. Blue 122-123 M057: L 201 Full C.T. Blue 124-125 M058: L 202 Half C.T Blue 126-127...
  • Page 44 DMX CHANNEL 15 Parameter: CCT/GEL FADE TO RGBACL DMX value Function 000-255 Crossfade from CCT/GEL to RGBACL 0 = 100% CCT/GEL, 0% RGBACL 255 = 0% CCT/GEL, 100% RGBACL DMX CHANNEL 16 Parameter: RED DMX value Function 000-255 Proportional color from min to max DMX CHANNEL 17 Parameter: GREEN DMX value Function...
  • Page 45 DMX CHANNEL 23 Parameter: BEAM SHAPER DMX value Function 000-009 No Function 010-255 Beam shaper inserted DMX CHANNEL 24 Parameter: BEAM SHAPER INDEX/ROTATION DMX value Function 000-009 No Function 010-127 Proportional index 0°-360° 128-180 CW rotation from fast to slow 181-202 Stop 203-255...
  • Page 46 DMX CHANNEL 27 Parameter: FIXTURE CONTROL Function 000-009 0 - No effect 010-024 1 – SMOOTH DIMMING OFF 025-026 2 - SMOOTH DIMMING 1 027-028 3 - SMOOTH DIMMING 2 029-030 4 - SMOOTH DIMMING 3 031-032 5 - SMOOTH DIMMING 4 (Default) 033-034 6 - SMOOTH DIMMING 5 035-036...
  • Page 47 DMX CHANNEL 27 Parameter: FIXTURE CONTROL Function 52 - reserved 53 - reserved 54 - reserved 55 - reserved 56 - reserved 57 - reserved 58 - reserved 59 - reserved 60 - reserved 61 - reserved 62 - reserved 135-136 63 - reserved 137-138...
  • Page 48 DMX CHANNEL 27 Parameter: FIXTURE CONTROL Function 235-236 107 – OPERATING MODE SILENT (Default) 237-238 108 - OPERATING MODE STANDARD 239-240 109 – reserved 241-242 110 – FAN MODE CONSTANT (Default) 243-244 111 – FAN MODE AUTO 245-246 112 – reserved 247-248 113 –...
  • Page 49 3. “BASIC” mode (23 DMX channels) 1 PAN msb 2 PAN lsb 3 TILT msb 4 TILT lsb 5 SPEED MOVEMENT 6 SHUTTER 7 DIMMER msb 8 DIMMER lsb 9 CCT (1.800K – 10.000K) (priority on GEL LIBRARY and RGBACL channels) 10 GEL LIBRARY (priority on RGBACL channels) 11 RED 12 GREEN...
  • Page 50 DMX CHANNEL 6 Parameter: SHUTTER DMX value Function 000-009 Black Out 010-019 Open 020-029 Black Out 030-119 Strobe (from 3,27s to 30ms) 120-149 Pulse up (from 42,6s to 120ms) 150-179 Pulse down (from 42,6s to 120ms) 180-189 Random strobe 190-199 Open 200-209 Effect wheel in Black Out while rotating...
  • Page 51 DMX CHANNEL 10 Parameter: GEL LIBRARY (priority on RGBACL channels) DMX value Function 000-009 No function 010-011 M001: L 002 Rose Pink 012-013 M002: L 007 Pale Yellow 014-015 M003: L 015 Deep Straw 016-017 M004: L 019 fire 018-019 M005: L 020 medium amber 020-021 M006: L 021 Gold Amber...
  • Page 52 DMX CHANNEL 10 Parameter: GEL LIBRARY (priority on RGBACL channels) DMX value Function 114-115 M053: L 182 Light Red M054: L 194 Surprise Pink 116-117 118-119 M055: L 195 zenith blue 120-121 M056: L 200 Double C.T. Blue 122-123 M057: L 201 Full C.T. Blue 124-125 M058: L 202 Half C.T Blue 126-127...
  • Page 53 DMX CHANNEL 11 Parameter: RED DMX value Function 000-255 Proportional color from min to max DMX CHANNEL 12 Parameter: GREEN DMX value Function 000-255 Proportional color from min to max DMX CHANNEL 13 Parameter: BLUE DMX value Function 000-255 Proportional color from min to max DMX CHANNEL 14 Parameter: AMBER DMX value Function...
  • Page 54 DMX CHANNEL 19 Parameter: BEAM SHAPER INDEX/ROTATION DMX value Function 000-009 No Function 010-127 Proportional index 0°-360° 128-180 CW rotation from fast to slow 181-202 Stop 203-255 CCW rotation from slow to fast DMX CHANNEL 20 Parameter: Reserved DMX value Function 000-255 Reserved...
  • Page 55 DMX CHANNEL 22 Parameter: FIXTURE CONTROL Function 000-009 0 - No effect 010-024 1 – SMOOTH DIMMING OFF 025-026 2 - SMOOTH DIMMING 1 027-028 3 - SMOOTH DIMMING 2 029-030 4 - SMOOTH DIMMING 3 031-032 5 - SMOOTH DIMMING 4 (Default) 033-034 6 - SMOOTH DIMMING 5 035-036...
  • Page 56 DMX CHANNEL 22 Parameter: FIXTURE CONTROL Function 52 - reserved 53 - reserved 54 - reserved 55 - reserved 56 - reserved 57 - reserved 58 - reserved 59 - reserved 60 - reserved 61 - reserved 62 - reserved 135-136 63 - reserved 137-138...
  • Page 57 DMX CHANNEL 22 Parameter: FIXTURE CONTROL Function 235-236 107 – OPERATING MODE SILENT (Default) 237-238 108 - OPERATING MODE STANDARD 239-240 109 – reserved 241-242 110 – FAN MODE CONSTANT (Default) 243-244 111 – FAN MODE AUTO 245-246 112 – reserved 247-248 113 –...
  • Page 58 4. “EXPO” mode (13 DMX channels) 1 PAN msb 2 PAN lsb 3 TILT msb 4 TILT lsb 5 SHUTTER 6 DIMMER 7 CCT (1.800K – 10.000K) (priority on GEL LIBRARY) 8 GEL LIBRARY 9 FROST/COLOUR WHEEL 10 BEAM SHAPER + BEAM SHP INDEX/ROTATION 11 ZOOM 12 FIXTURE CONTROL 13 RESET...
  • Page 59 DMX CHANNEL 6 Parameter: DIMMER msb DMX CHANNEL Parameter: CCT (priority on GEL LIBRARY) DMX value Function 000-009 No function 010-255 Correlated colour temperature from 1800K to 10000K. Relevant CCT values: 1800K = 010 2700K = 070 3000K = 083 3200K = 092 4000K = 119 5000K = 148...
  • Page 60 DMX CHANNEL 8 Parameter: GEL LIBRARY DMX value Function 000-009 No function 010-011 M001: L 002 Rose Pink 012-013 M002: L 007 Pale Yellow 014-015 M003: L 015 Deep Straw 016-017 M004: L 019 fire 018-019 M005: L 020 medium amber 020-021 M006: L 021 Gold Amber 022-023...
  • Page 61 DMX CHANNEL 8 Parameter: GEL LIBRARY DMX value Function 114-115 M053: L 182 Light Red M054: L 194 Surprise Pink 116-117 118-119 M055: L 195 zenith blue 120-121 M056: L 200 Double C.T. Blue 122-123 M057: L 201 Full C.T. Blue 124-125 M058: L 202 Half C.T Blue 126-127...
  • Page 62 DMX CHANNEL 9 Parameter: FROST/COLOUR WHEEL DMX value Function 000-009 No Function 010-050 Reserved 051-090 Heavy frost 091-130 Deep blue filter switch ON (BLUE channel forced at full) 131-170 Deep red filter switch ON (RED channel forced at full) 171-210 Deep blue filter manual control 211-255 Deep red...
  • Page 63 DMX CHANNEL 12 Parameter: FIXTURE CONTROL Function 000-009 0 - No effect 010-024 1 – SMOOTH DIMMING OFF 025-026 2 - SMOOTH DIMMING 1 027-028 3 - SMOOTH DIMMING 2 029-030 4 - SMOOTH DIMMING 3 031-032 5 - SMOOTH DIMMING 4 (Default) 033-034 6 - SMOOTH DIMMING 5 035-036...
  • Page 64 DMX CHANNEL 12 Parameter: FIXTURE CONTROL Function 52 - reserved 53 - reserved 54 - reserved 55 - reserved 56 - reserved 57 - reserved 58 - reserved 59 - reserved 60 - reserved 61 - reserved 62 - reserved 135-136 63 - reserved 137-138...
  • Page 65 DMX CHANNEL 12 Parameter: FIXTURE CONTROL Function 235-236 107 – OPERATING MODE SILENT (Default) 237-238 108 - OPERATING MODE STANDARD 239-240 109 – reserved 241-242 110 – FAN MODE CONSTANT (Default) 243-244 111 – FAN MODE AUTO 245-246 112 – reserved 247-248 113 –...
  • Page 66 5. “CMY EMULATION” mode (23 DMX channels) • Source color temperature always 7000K. • CMY / CTO channels variations will affect Gel Library 1 and 2 channels. 1 PAN msb 2 PAN lsb 3 TILT msb 4 TILT lsb 5 SPEED MOVEMENT 6 SHUTTER 7 DIMMER msb 8 DIMMER lsb...
  • Page 67 DMX CHANNEL 6 Parameter: SHUTTER DMX value Function 000-009 Black Out 010-019 Open 020-029 Black Out 030-119 Strobe (from 3,27s to 30ms) 120-149 Pulse up (from 42,6s to 120ms) 150-179 Pulse down (from 42,6s to 120ms) 180-189 Random strobe 190-199 Open 200-209 Effect wheel in Black Out while rotating...
  • Page 68 DMX CHANNEL 10 Parameter: GEL LIBRARY 1 DMX value Function 000-009 No function 010-011 M001: L 002 Rose Pink 012-013 M002: L 007 Pale Yellow 014-015 M003: L 015 Deep Straw 016-017 M004: L 019 fire 018-019 M005: L 020 medium amber 020-021 M006: L 021 Gold Amber 022-023...
  • Page 69 DMX CHANNEL 10 Parameter: GEL LIBRARY 1 DMX value Function 114-115 M053: L 182 Light Red M054: L 194 Surprise Pink 116-117 118-119 M055: L 195 zenith blue 120-121 M056: L 200 Double C.T. Blue 122-123 M057: L 201 Full C.T. Blue 124-125 M058: L 202 Half C.T Blue 126-127...
  • Page 70 DMX CHANNEL 12 Parameter: GEL LIBRARY 2 DMX value Function 000-009 No function 010-011 M001: L 002 Rose Pink 012-013 M002: L 007 Pale Yellow 014-015 M003: L 015 Deep Straw 016-017 M004: L 019 fire 018-019 M005: L 020 medium amber 020-021 M006: L 021 Gold Amber 022-023...
  • Page 71 DMX CHANNEL 12 Parameter: GEL LIBRARY 2 DMX value Function 114-115 M053: L 182 Light Red M054: L 194 Surprise Pink 116-117 118-119 M055: L 195 zenith blue 120-121 M056: L 200 Double C.T. Blue 122-123 M057: L 201 Full C.T. Blue 124-125 M058: L 202 Half C.T Blue 126-127...
  • Page 72 DMX CHANNEL 13 Parameter: CYAN DMX value Function 000-255 Proportional color from min to max DMX CHANNEL 14 Parameter: MAGENTA DMX value Function 000-255 Proportional color from min to max DMX CHANNEL 15 Parameter: YELLOW DMX value Function 000-255 Proportional color from min to max DMX CHANNEL 16 Parameter: CTO DMX value Function...
  • Page 73 DMX CHANNEL 22 Parameter: FIXTURE CONTROL Function 000-009 0 - No effect 010-024 1 – SMOOTH DIMMING OFF 025-026 2 - SMOOTH DIMMING 1 027-028 3 - SMOOTH DIMMING 2 029-030 4 - SMOOTH DIMMING 3 031-032 5 - SMOOTH DIMMING 4 (Default) 033-034 6 - SMOOTH DIMMING 5 035-036...
  • Page 74 DMX CHANNEL 22 Parameter: FIXTURE CONTROL Function 52 - reserved 53 - reserved 54 - reserved 55 - reserved 56 - reserved 57 - reserved 58 - reserved 59 - reserved 60 - reserved 61 - reserved 62 - reserved 135-136 63 - reserved 137-138...
  • Page 75 DMX CHANNEL 22 Parameter: FIXTURE CONTROL Function 235-236 107 – OPERATING MODE SILENT (Default) 237-238 108 - OPERATING MODE STANDARD 239-240 109 – reserved 241-242 110 – FAN MODE CONSTANT (Default) 243-244 111 – FAN MODE AUTO 245-246 112 – reserved 247-248 113 –...

  • Page 76: Frost/Colour Wheel

    19- FROST/COLOUR WHEEL...
  • Page 77 NOTES...
  • Page 78 NOTES...
  • Page 79 NOTES...
  • Page 80 ISO 9001:2015 DTS quality system is certified 9001:2015 standard 0517I354 D.T.S. Illuminazione s.r.l. ● Via Fagnano Selve 12- 47843 Misano Adriatico (RN) Italy ● Tel.: +39 0541 611131 Fax +39 0541 611111 info@dts-lighting.it www.dts-lighting.it Product and specifications subjects to change without notice.
