Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S . D.T.S.
INDEX: 1- SYMBOLS ......................... 4 2- GENERAL WARNING ....................4 3- GENERAL WARRANTY CONDITIONS ..............4 4- TECHNICAL FEATURES ..................5 5- ACCESSORIES ......................6 6- IMPORTANT SAFETY INFORMATION ..............7 6.1 Fire prevention...................... 7 6.2 Prevention of electric shock .................. 7 6.3 Safety ........................
1- SYMBOLS Graphic symbols used on this manual: THIS SYMBOL INDICATES A HOT SURFACE THIS SYMBOL INDICATES ELECTRIC SHOCK RISK THIS SYMBOL INDICATES GENERAL RISK THIS SYMBOL INDICATES THE MAXIMUM OPERATING AMBIENT TEMPERATURE THIS SYMBOL MEANS “DO NOT STARE AT THE OPERATING LIGHT SOURCE” THIS SYMBOL INDICATES PHOTOBIOLOGICAL SAFETY THIS SYMBOL INDICATES THE EUROPEAN...
Linear color temperature (2700K – 8000K) Control DMX 512 / RDM or Manual control 12 DMX channels (Default) 4-digit 7-segment LED display + 4 soft keys Internal operating system updatable via DTS Dongle Firmware Uploader Power supply Full-range 100-240Vac 50-60 Hz Consumption: 200W Max Connections Power supply: PowerCON TRUE1 In&Out panel connectors...
The use of a thermal magnetic circuit breaker is recommended for each SCENA LED 200 MZ FC unit. Use only AC supplies 100-240V 50-60 Hz. SCENA LED 200 MZ FC should never be located in position exposed to rain or in areas of extreme humidity.
7- INSTALLATION The unit is suitable for dry locations only. SCENA LED 200 MZ FC can be installed on a truss or on the ceiling. It is recommend the use of appropriate clamps to fix the unit to the mounting surface.
9- DMX SIGNAL CONNECTION: The unit operates using a digital DMX 512 signal. Connection between the controller and the unit or between units must be carried out using a two pair screened ø 0.5 mm. Ensure that the conductors do not touch each other. Do not connect the cable ground to the DMX connector chassis.
9.1 DMX addresses SCENA LED 200 MZ FC can be controlled with 12 DMX channels (Default). In order to use the unit in 12 DMX channels mode, set the following addresses on the mixer: Projector 1 A001 If you want to select the next projector, just add “12”...
10- RDM FUNCTIONS By using a RDM controller it is possible to set DMX address, DMX mode and other parameters. SCENA LED 200 MZ FC accepts the following RDM commands: DEVICE_INFO To read the following parameters: RDM protocol version ...
Using these options, it is possible to change the fixture’s setting. Changing the DTS settings can vary the functions of the unit so that it does not respond to the DMX 512 used to control it. Carefully follow the instructions below before carrying out any variations or selections.
Page 14
MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION Display normal orientation for floor mounting position (Default) Display inverted orientation for suspended mounting position Display always ON (Default) Display goes OFF after 10 seconds ...
Page 15
MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION In DMX Recorder mode it is possible to create and store the scenes of the CHPR menu by using an external DMX controller. The unit must be set to 12 DMX ...
13- REC MODE DMX Recorder mode For the programming of ChPr by using a DMX controller, besides the 12 channels necessary to control the unit a further 3 DMX channels are needed. So that in RECORDER mode (via DMX) the unit will need 15 channels to be correctly programmed.
15- ERROR MESSAGES ERROR SHOWED ON DISPLAY APPEARS WHEN LED thermal sensor damaged (open or in short circuit). Unit immediately goes in black-out. LED temperature detected over 70°C. Unit immediately goes in black-out. Micro controller thermal sensor damaged (open or in short circuit).
16- DMX PROTOCOL 12 CHANNELS MODE (Default) GREEN BLUE WHITE SHUTTER DIMMER DIMMER FINE MACRO COLOR FUNCTIONS ZOOM RESET Name DMX levels 0..255 Proportional color from min to max GREEN 0..255 Proportional color from min to max BLUE 0..255 Proportional color from min to max WHITE 0..255 Proportional color from min to max...
Page 19
Name DMX levels MACRO COLOR 0..09 No function 1: GEL FILTER NO.19 "FIRE" (R255 G15 B0 W0 =) 10..20 (R255 G62 B0 W0 =) 2: GEL FILTER NO.20 "MEDIUM AMBER" (R231 G80 B0 W0 =) 21..25 (R243 G143 B0 W0 =) 3: GEL FILTER NO.25 "SUNSET RED"...
Page 20
Name DMX levels FUNCTIONS (staying 0..9 No function on desired option for 10..24 SMOOTH OFF 5 seconds) 25..26 SMOOTH 1 (25 ms) 27..28 SMOOTH 2 (50 ms) 29..30 SMOOTH 3 (75 ms) 31..32 SMOOTH 4 (100 ms) (DEFAULT) 33..34 SMOOTH 5 (125 ms) 35..36 SMOOTH 6 (150 ms) 37..38...
Page 21
Name DMX levels FUNCTIONS (staying 253..255 SET DEFAULTS VALUES FOR FUNCTIONS: on desired option for SMOOTH = 4 (100 ms) 5 seconds) GAMMA CORRECTION () = QUADRATIC OUTPUT FREQUENCY = 610 Hz BOOST = ON DISPLAY STAND-BY = OFF NO DMX ACTION = KEEP LAST DMX FAN MODE = SILENT ZOOM MODE = SILENT ZOOM...
Page 22
7 CHANNELS MODE GREEN BLUE WHITE SHUTTER DIMMER ZOOM Name DMX levels 0..255 Proportional color from min to max GREEN 0..255 Proportional color from min to max BLUE 0..255 Proportional color from min to max WHITE 0..255 Proportional color from min to max SHUTTER 0..9 Black-out...
Page 23
“FINE” MODE (11 CHANNELS) RED FINE GREEN GREEN FINE BLUE BLUE FINE WHITE WHITE FINE DIMMER DIMMER FINE ZOOM Name DMX levels 0..255 Proportional color from min to max RED FINE 0..255 Proportional color from min to max GREEN 0..255 Proportional color from min to max GREEN FINE 0..255...
