Black Box SP077A Manual

In-Line Surge Protector, PoE, Mode B (RJ-45 8-Wire)
Get convenient in-line surge protection for access
points on your wireless Ethernet network.
Put avalanche diode and thyristor protection
where you need it.

Specifications

Application: PoE (Mode B)
Ground Wire: Yes
Maximum Shunt Capacitance: <25 pF (Ethernet lines only)
Peak Pulse Current: Pins 1, 2, 3, and 6: 132 amps;
Pins 4, 5, 7, and 8: 103 amps
Pins Protected: All
Protection Type: Avalanche diode and thyristor technology
Response Time: <5 ns
Standard Clamping Voltage: Pins 1, 2, 3, and 6: 7.5 volts;
Pins 4, 5, 7, and 8: 30 volts
Connectors: (2) RJ-45 F
