JESSIE STORAGE BOOKSHELF
Assembly Instructions - Please keep for future reference
Important – Please read these instructions before assembly
If you need help or have damaged or missing parts, email:
customerservices@habitat.co.uk
0344 499 4686
or call:
JESS-SB-SS20-A
Dimensions
Width -66cm
Depth -31.6cm
Height -189cm
Tools required
1
2
1
Advertisement
Related Manuals for Habitat JESSIE JESS-SB-SS20-A
Summary of Contents for Habitat JESSIE JESS-SB-SS20-A
- Page 1 Assembly Instructions - Please keep for future reference JESS-SB-SS20-A Dimensions Width -66cm Depth -31.6cm Height -189cm Tools required Important – Please read these instructions before assembly If you need help or have damaged or missing parts, email: customerservices@habitat.co.uk 0344 499 4686 or call:...
- Page 2 Check you have all the components and Assemble the item as close to its final tools listed on the front cover and position (in the same room) as possible. pages 3. Remove all fittings from the plastic bags and separate them into their groups. Dust regularly with a clean dry cloth.
- Page 3 Components and Fittings If you need help or have damaged or missing parts, email: customerservices@habitat.co.uk or call: 0344 499 4686 Please check you have all the panels listed below...
- Page 4 Step1: Front Front Step2:...
- Page 5 Step3: Step4: Step5:...
- Page 6 Step6: Step7:...
- Page 7 Step8: Step9:...
- Page 8 Step10: Step11: Take care when standing product upright...
- Page 9 Step12: Step13: Please Note! Adjusting Push-To-Open Door Mechanism If door does not open when pushed in it could be because the push-to-open mechanism needs adjustment. Simply turn the magnetic end of the mechanism to screw it out further so that it makes better contact with the metal strike plate.
- Page 10 Step14: Adjusting the hinge Step15: WARNING! In order to prevent overturning this product must be used with the wall attachment device provided. Serious or fatal crushing injuries can occur from furniture tipping over. To help prevent topple over :- -Use the wall attachment devices provided -Never allow children to climb or hang on drawers -Do not overload the drawer beyond maximum recommended loading.
- Page 11 Step16: Step17: Step18: Fixing wall bracket to your wall Please Note You must source and supply suitable fixings for your wall type. If in doubt consult a qualified trades person. Always ensure that the wall to be drilled into is free from hidden electrical wires, water and gas pipes.
-
Page 12: A Guide To - Wall Mounting & Fixings
1: General rule: Always use a larger screw and wall plug if you are not sure. different wall types, Habitat cannot provide you with the 2: Ensure you use the recommended drill bit to match the wall exact fixings you will need to plug and hole size.
