Summary of Contents for Reid KD716
- Page 1 KD716 Display Manual...
-
Page 2: Table Of Contents
Content PRODUCT MODEL SPECIFICATIONS APPEARANCE AND SIZE FUNCTION SUMMARY AND DISTRIBUTION FUNCTION LAYOUT DISPLAY BUTTON DEFINITION GENERAL OPERATIONS SWITCHING THE SYSTEM ON/OFF DISPLAY INTERFACE 6KM/H PUSH ASSISTANCE PAS LEVEL BATTERY CAPACITY INDICATOR MOTOR POWER INDICATOR ERROR CODE INDICATOR RESTORE DEFAULT SETTINGS GENERAL SETTINGS TRIP DISTANCE CLEARANCE BACKLIGHT BRIGHTNESS... -
Page 3: Product Model
Product model E-bike Intelligent LCD display Model: KD716/KD716-V, both models have the same functionality and software. In this manual, we will only use one interface. Specifications 36V/48V Power Supply Rated working current: 25mA The maximum working current: 30mA Off-state leakage current: <1μA Supply controller working current: 50mA Operating temperature: -20℃~ 60℃... -
Page 4: Function Layout
Display button definition The KD716-V/KD716 display matches the K41-N button, which has 4 buttons: including power on/off, i button, plus button/headlight button, minus button/boost button; in the following instructions, the on/off button is used The word "ON/OFF" is replaced; the i button is replaced with the word "i"; the plus/headlight button is replaced with "+";... -
Page 5: 6Km/H Push Assistance
6km/h Push assistance Press and hold the "-" button after 2 seconds, the e-bike will enter the state of electric power-assisted propulsion. The e-bike travels at a constant speed of 6 km/h. At the same time, the screen displays " ". -
Page 6: Motor Power Indicator
battery undervoltage flashing Battery capacity indicator Motor Power Indicator The power of the motor can be read via the interface. Motor Power Indication interface Error Code Indication The components of the E-bike system are continuously and automatically monitored. When an error is detected, the respective error code is indicated in text indication area. -
Page 7: Restore Default Settings
Restore default setting DEF means to restore the default parameters. In the normal display interface, press and hold the "-" and "i" buttons at the same time for more than 2 seconds to enter the interface of restoring the default parameters. Short press the UP/DOWN button to switch Y/N, and Y means to restore the default Parameters, N means that the default parameters do not need to be restored. -
Page 8: General Settings
General Setting Press and hold the " " button to start working. In the power-on state, when the e-bike is stationary, press and hold the "+" and "-" buttons for more than 2 seconds at the same time, and the display enters the normal setting state. All the Settings are operated in the case of parking the E-bike. -
Page 9: Advanced Parameter Settings
Advanced Parameter Setting Press and hold the "+" and "-" buttons for more than 2 seconds and lift them up to enter the normal setting state. Then press and hold the "-" and "i" buttons for more than 2 seconds at the same time to enter the wheel diameter setting interface and speed limited setting interface. -
Page 10: Personalised Parameter Settings
Personalized Parameter Setting In order to meet the customer's personalized use requirements, the personalized setting items The content includes battery capacity setting, power assist parameter setting, current limit value setting, PAS sensor setting, speed sensor setting, throttle function setting, system setting and power-on password setting from left to right and from top to bottom. -
Page 11: Assist Parameter Setting (Optional)
Assist parameter setting (optional) PAS level selection A mode is provided in the selection of the assist level: 0-5, short press the "i" button to confirm and enter the assist ratio value setting interface in the corresponding mode. PAS level selection interface Assist ratio value setting By setting the power ratio value, the speed of each... -
Page 12: Pas Sensor Setting (Optional)
PAS sensor setting (optional) PAS sensor direction setting PAS stands for power assist sensor, and run-F/b is displayed on the screen. run-F stands for forward, run-b stands for reverse; press the "+" or "-" button to switch, short press the "i" button to confirm and enter the power sensor sensitivity setting. -
Page 13: Speed Sensor Setting(Optional)
Speed sensor setting(optional) SPS stands for speed sensor, which can be set according to the number of magnetic heads installed on the wheel of the e-bike, and the setting range is 1-15; short press the "+" or "-" button to modify, long press the "i" button to confirm and return to the display setting Item selection interface. -
Page 14: System Settings (Optional)
System setting (optional) Power delay time setting DLY stands for power delay time, press the "+" or "-" button to select the power delay time 3/6/12s; short press the "i" button to confirm and enter the maximum speed limit setting interface. The display defaults to 3s. Power delay time setting Power-on password setting... -
Page 15: Quality Assurance And Warranty Scope
Quality Assurance and Warranty Scope Warranty The warranty will be valid only for products used in normal usage and conditions. The warranty is valid for 24 months after the shipment or delivery to the customer. Others The following items do not belong to our warranty scope. The display is demolished. -
Page 16: Operation Cautions
Operation Cautions Be careful of safe use.Don’t attempt to release the connector when battery is on power. Try to avoid hitting. Do not modify system parameters to avoid parameters disorder. Make the display repaired when error code appears. E rror code definition Attached list 1 ：... - Page 17 KD716 Display Manual...
