Sony WEGA KE-32TS2 Dimension Manual

KE-32TS2
RM-923Y REMOTE CONTROL
Stand is
removeable
VIDEO 1 IN
R AUDIO L
VIDEO 2 IN
NOTE:
WHERE THERE ARE CLOSE TOLERANCES
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF
MEASUREMENTS.
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
MODEL:
DESCRIPTION:
DESCRIPTION:
DIMENSIONS DIMENSIONS
(WHD):
(WHD):
WEIGHT:
WEIGHT:
TOP VIEW

FRONT VIEW

33 3/4"
29 1/16"
REMOTE
SENSOR
SPEAKERS
18 5/8"
BACK VIEW
15 3/8"
VENTILLATION
VENTILLATION
EXHAUST
VENTILLATION
VIDEO 1 VIDEO IN 3 AUDIO OUT
L AUDIO R VIDEO
VIDEO S-VIDEO R AUDIO L DVI/HDTV R AUDIO L
CONTROL S
Y/G Pb/B Pr/R HD VD
SUB
OUT
VIDEO 2 VIDEO IN 4
JACK PACK
VIDEO IN 3
L AUDIO R VIDEO
VIDEO S-VIDEO
R AUDIO L
DVI/HDTV
Y/G Pb/B
VIDEO IN 4
SONY WILL NOT BE RESPONSIBLE FOR
32" Flat Panel
TV
33 3/4 " X 24 3/4" X 5 1/4"
57 lbs 3 oz.
9 7/8"
CONTROLS
1/8"
16 9/16"
SPEAKERS
6 1/4"
9 3/16"
6 11/16"
8 7/8"
IN
OUT
AUDIO OUT
R AUDIO L
CONTROL S
Pr/R HD VD
SUB
IN
OUT
OUT
INVOLVED IN CABINET BUILDING
BE USED TO MAKE THE ACTUAL
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
SIDE VIEW
5 1/4"
24 3/4"
22 3/8"
24 3/4"
VHF/UHF
AC IN
WE
INACCURACIES
120V AC
60Hz
300W
1.7w Stby
