ibaPQU-S
Power Quality Measurement Unit according to
IEC61000-4-30 Ed. 3 Class A
Manual
Issue 1.5
Manual
Issue 1.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ibaPQU-S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBA ibaPQU-S

Summary of Contents for IBA ibaPQU-S

  • Page 1 Manual ibaPQU-S Power Quality Measurement Unit according to IEC61000-4-30 Ed. 3 Class A Manual Issue 1.5 Issue 1.0...
  • Page 2 However, the information in this publication is updated regularly. Required cor- rections are contained in the following regulations or can be downloaded on the Internet. The current version is available for download on our web site www.iba-ag.com. Copyright notice ®...

  • Page 3: Table Of Contents

    Manual Table of Contents About this manual ................... 7 Target group ....................8 Notations ....................... 8 Used symbols ....................9 Introduction ....................10 Modular concept ...................11 Measurements according to EN50160............12 Scope of delivery................... 12 Safety instructions ..................13 Intended use ....................13 Special safety instructions ................
  • Page 4 PQU-S – “Analog” tab ................. 43 10.2.2 PQU-S – “Digital” tab .................. 43 10.2.3 PQU-S – “Diagnostics” tab ................44 10.2.4 ibaPQU-S – “General” tab ................45 10.2.5 ibaPQU-S – “Digital” tab ................46 10.2.6 ibaPQU-S – “Status” tab ................47 10.2.7 Diagnostics - “General”...
  • Page 5 Mounting panel 19“..................104 12.3.2 12.3.3 Module carrier ................... 109 12.4 Terminal blocks ..................110 12.5 I/O modules iba modular system ..............111 12.6 FO cards/cables ..................112 12.7 iba software ....................112 Appendix ...................... 113 13.1 Calculating characteristic values ..............113 13.1.1...
  • Page 6 Manual ibaPQU-S Index ......................125 Certificate ....................126 Support and contact ................... 127 Issue 1.5...

  • Page 7: About This Manual

    Manual About this manual This manual describes the design, use and operation of the ibaPQU-S. For information on the design, use and operation of the I/O modules, please refer to the dedicated man- uals. Note The documentation for the iba-modular system is part of the data medium “iba Soft- ware &...

  • Page 8: Target Group

    Manual ibaPQU-S Target group This manual addresses in particular the qualified professionals who are familiar with han- dling electrical and electronic modules as well as communication and measurement tech- nology. A person is regarded to as professional if he/she is capable of assessing safety and recognizing possible consequences and risks on the basis of his/her specialist train- ing, knowledge and experience and knowledge of the standard regulations.

  • Page 9: Used Symbols

    Manual Used symbols If safety instructions or other notes are used in this manual, they mean: The non-observance of this safety information may result in an imminent risk of death or severe injury:  By an electric shock!  Due to the improper handling of software products which are coupled to input and output procedures with control function! If you do not observe the safety instructions regarding the process and the system or machine to be controlled, there is a risk of death or severe injury!

  • Page 10: Introduction

    IEC 61000-4-30 Ed. 3 Class A. Charac- teristic values include: ...

  • Page 11: Modular Concept

    Manual Modular concept The modular concept of the ibaPQU-S system is designed on the basis of a backplane. You can plug on this backplane not only the CPU, but also up to 4 input/output modules. ibaPQU-S is used as a central unit with integrated measurement and calculation algo- rithms and additionally features 8 digital inputs.

  • Page 12: Measurements According To En50160

    The scope of delivery comprises:  ibaPQU-S device  Covering caps for FO cables, USB and Ethernet  16-pin connector with spring terminals (digital input channels)  2-pin connector with spring terminals (voltage supply)  Data medium “iba Software & Manuals” Issue 1.5...

  • Page 13: Safety Instructions

    Excess voltage may destroy the device! ATTENTION! Never insert or remove modules and the CPU at the backplane under live conditions! Switch off ibaPQU-S or disconnect the power supply before inserting or removing modules. Important note Do not open the device! Opening the device will void the warranty!

  • Page 14: System Requirements

     ibaFOB-2io-D / ibaFOB-2io-Dexp  ibaFOB-2i-D / ibaFOB-2i-Dexp with ibaFOB-4o-D add-on module  ibaFOB-4i-D / ibaFOB-4i-Dexp with ibaFOB-4o-D add-on module  ibaFOB-io-ExpressCard (for notebooks)  FO cable, bidirectional Software  ibaPDA beginning with version 6.34.4 Firmware ibaPQU-S beginning with version 02.11.014 Issue 1.5...

  • Page 15: Mounting, Connecting, Dismounting

    Manual Mounting, connecting, dismounting Caution! Only work on the device when it is de-energized! Mounting 1. Mount the backplane on an appropriate construction. 2. Connect the ground terminal. 3. Plug the device into the left slot. Make sure that the guiding bolts on the rear side of the device are inserted into the corresponding holes on the backplane.

  • Page 16: Connecting

    Manual ibaPQU-S Connecting 1. Connect the measuring lines connected to the measuring objects to the I/O module inputs. Connection principles are described in chapter 8. 2. Use an ibaNet FO patch cable (duplex) to connect the device to the ibaPDA com- puter: ...

  • Page 17: Device Description

    Manual Device description Views Operating status indicators L1...L4 On/off switch S11 Connector power supply 24 V X14 Indicators digital inputs L10...L17 Connector digital inputs X5 Fixing screws Indicators L5...L8 Network interface X22 (no function) Rotary switches S1, S2 System function push button S10 (no function) Connection FO output (TX) X10 Connection FO input (RX) X11 X23 for service purposes only...

  • Page 18: Display Elements

    Malfunction, internal applications do not run Hardware error Important note When the LED L4 indicates an error, please contact the iba support. LEDs L5…L8 7.2.2 The LEDs L5 through L8 show status and progress when installing an update, see chap- ter 9 “Updates”.

  • Page 19: Indicators Digital Inputs L10

    Unlike other iba devices supporting the 32Mbit Flex protocol, it is only allowed to oper- ate two ibaPQU-S systems in cascade configuration at one free 32Mbit Flex link of an ibaFOB card due to the high sampling rate of 10 - 40 kHz and the high data volume in the network channel of the Flex protocol.

  • Page 20: Communication Interfaces

    Communication interfaces 7.4.1 Fiber optic connections X10 and X11 The FO cables transmit the process data between the device and the connected iba systems. The 32Mbit Flex transfer protocol also allows configuration data to be trans- ferred via FO cable.

  • Page 21: Debounce Filter

    Manual 7.5.2 Debounce filter There are four debounce filters for each digital input. They can be chosen and configured independently of each other for each signal. The following filters are available:  “Off” (without filter)  “Stretch rising edge”  “Stretch falling edge” ...
  • Page 22 Manual ibaPQU-S “Stretch falling edge” The first falling edge sets the output signal (green) to logical 0 and it remains logical 0 for the set debounce time. Subsequently, the channel is transparent again and waits for the next falling edge.
  • Page 23 Manual Issue 1.5...

  • Page 24: Voltage Supply

    Manual ibaPQU-S Voltage supply 7.6.1 Voltage supply X14 The external voltage supply is connected with a 2-pin connector. Caution! Only connect the device to an external voltage supply 24 V DC (±10 % unregulated)! Pay attention to the correct polarity! 7.6.2...

  • Page 25: Measurement Principles And Measured Quantities

    Manual Measurement principles and measured quantities To determine the power quality parameters, ibaPQU-S measures raw values such as currents and voltages in synch with the grid. The characteristic values relevant for power quality are calculated internally. Grid types The device is suitable for 1-phase grids, 3-phase grids without neutral conductor and 3-phase grids with neutral conductor (N) or protective earth (PE).

  • Page 26: Signals And Calculated Characteristic Values

    Manual ibaPQU-S Signals and calculated characteristic values The following table shows the required measured values depending on the grid type. Based on the measurements, all characteristic values are calculated which are needed to assess the power quality. Measured values 1-phase...
  • Page 27 Manual Characteristic Available Grid type Calculation Calculation time values (conductor) interval Half 10 s 3+N Phase Grid riod Reactive energy with sign Fundamental reactive energy Power factor Cos φ Positive sequence component Negative sequence component Zero sequence component Supply voltage unbalance (negative sequence component)

  • Page 28: System Integration

    Therefore, the signals are re-sampled internally by ibaPQU-S using the sampling rate set in ibaPDA. As a re- sult, individual values may not be available or repeated. ibaPDA sampling...

  • Page 29: Signal Filtering

    A digital anti-aliasing filter with a cut-off frequency of approx. 3 kHz is implemented. This filter is also used for the raw values recorded with ibaPDA. ibaPQU-S activates this anti-aliasing filter with the signals used for characteristic value calculation or as synchronization signal. The configuration of these signals in ibaPDA is ignored in this process.
  • Page 30 Manual ibaPQU-S In this context, the range of the set signal (in the network definition) is irrelevant; the algorithm described above will always be used. For signals captured as raw signals, the range settings in ibaPDA take effect. Issue 1.5...

  • Page 31: Updates

    When the software version of a module does not match the “overall release version” of the central unit, ibaPQU-S does an automatic upgrade or downgrade of the module. After that the module is ready for use.
  • Page 32 CPU), this module is ignored and not displayed in ibaPDA. In this case, a new update file has to be installed for the “overall release version“. If you want to get the current update file, please contact the iba support. Issue 1.5...

  • Page 33: Configuration With Ibapda

    1. Select the “General” tab and the “Settings” node and set the acquisition timebase on the left to 1 ms. 2. Look for the corresponding link of the ibaFOB-D card to which ibaPQU-S is con- nected in the I/O Manager. Right-click the link to open a submenu. Select “Autode- tect”.
  • Page 34 Manual ibaPQU-S Now, the device is shown in the module tree. Drag the device to the address that is set on the device with the S1 rotary switch (Link 1 – 15 under the device), while keeping the right mouse button pressed: Position 1 –...
  • Page 35 The option “Show line-to-line” allows the voltages U12, U23 and U31 to be provided also in a star system. If the signals are not assigned, ibaPQU-S calculates these values. If the signals are measured, the raw values serve as the basis for the other calculations.
  • Page 36 Manual ibaPQU-S 11. Under “Measured values” select whether voltages only, currents only or voltages and currents are measured. 12. To perform measurements according to a defined standard, click the link “Click to configure standards...” and select the desired standard. By selecting the standard, all characteristic values required for measurement and calculation according to the standard are determined automatically.
  • Page 37 Manual 14. Each submodule has its own time base; the default value should not be changed. The signal names in the submodules are already preset. They include the corre- sponding characteristic value, the measuring input and the measurement interval al- lowing it to be identified unambiguously in subsequent evaluations.
  • Page 38 Manual ibaPQU-S  Basic, values for each input: - RMS value, peak value, rectified value, frequency (measurement interval 200 ms and half period) - phase, form factor, crest factor (peak factor) (measurement interval 200 ms)  Phasor, values for each input:...
  • Page 39 Manual  Flicker severity, values per phase: inst  Unbalance (asymmetry): values for voltages: - zero sequence unbalance - negative sequence unbalance - positive, negative, zero sequence component - phase angle of the positive sequence component, negative sequence compo- nent and zero sequence component values for currents: - positive, negative, zero sequence component - phase angle of the positive sequence component, negative sequence compo-...

  • Page 40: Overview Of The Modules In Ibapda

    Manual ibaPQU-S 10.1.1 Overview of the modules in ibaPDA Module Characteristic values Measurement interval Half period EN50160: Power Frequency (reference signal, all voltage frequency inputs) EN50160: Slow RMS value supply voltage (all voltage inputs) variation EN50160: Fundamental frequency, THD up to 40th...

  • Page 41: Basic Modules In I/O Manager

    Data acquisition is enabled for this module.  Name You can enter a module name.  Timebase Specifies the acquisition time base in ms used for ibaPQU-S and the connected modules in order to sample the raw signals. Smallest time base: 0.025 ms. Issue 1.5...
  • Page 42 If “True” is selected, the module name is prefixed to the signal names of this module. Connection  IP address IP address or host name of the ibaPQU-S device (read only).  Auto enable/disable If this option is enabled and ibaPDA cannot establish a connection to this device when starting the measurement, it will disable this module and start the measurement without the module.

  • Page 43: Pqu-S - "Analog" Tab

    Grid modules and the analog status signals of ibaPQU-S with their current values. PQU-S – “Digital” tab 10.2.3 The “Digital” tab is only displayed when acquisition with digital input modules has been started. The list shows the configured digital signals, the digital status display of ibaPQU-S and the current values. Issue 1.5...

  • Page 44: Pqu-S - "Diagnostics" Tab

     Write firmware This button allows running firmware updates. Select the update file “pqu_v[xx.yy.zzz].iba” in the browser and start the update by clicking <Ok>. Important note This process may take several minutes and must not be interrupted.

  • Page 45: Ibapqu-S - "General" Tab

    The following message is displayed and the device reinitializes automatically with the deleted I/O settings: Subsequently, run the “Autodetect” function again as described in chapter 10.1 “First steps”. ibaPQU-S – “General” tab 10.2.5 Basic settings  Module type, Locked, Enabled, Name, Timebase, Use name as prefix see chapter 10.2.1 PQU-S –...

  • Page 46: Ibapqu-S - "Digital" Tab

    Logical module number for the unambiguous referencing of signals, e.g. in expressions and ibaAnalyzer. Is assigned by ibaPDA in ascending order, but can be changed by the user. ibaPQU-S – “Digital” tab 10.2.6  Name Here you can enter a signal name and additionally two comments when clicking the icon in the Name field.

  • Page 47: Ibapqu-S - "Status" Tab

    Manual ibaPQU-S – “Status” tab 10.2.7 In the Status tab, you can enable status signals: Signal Meaning UDP data loss […] Data packet lost (per measurement interval) Data correct […] All data transmitted correctly (for different measurement intervals) PLL unlocked […]...

  • Page 48: Diagnostics - "General" Tab

    Manual ibaPQU-S Diagnostics - “General” tab 10.2.8 In the “Diagnostics” module, diagnosis signals are available. The module has to be added manually by right-clicking the “PQU-S” module and selecting “Diagnostics” from the context menu. Basic settings  Module Type, Locked, Enabled, Name, Module No., Use name as prefix see chapter 10.2.1.
  • Page 49 Manual Signal Meaning Hardware state X[…] Module on slot X[…] is OK Hardware available X[…] Module on slot X[…] was detected and initialized properly Embedded application state Embedded application is currentlty available Embedded application started Embedded application has been started. When the embedded application is finished properly, the signal will change to FALSE.

  • Page 50: Submodules To Calculate Characteristic Values

    Manual ibaPQU-S 10.3 Submodules to calculate characteristic values 10.3.1 Grid module “General” tab Basic settings  See PQU-S module, “General” tab, chapter 10.2.1 Configuration  Inputs Select the grid type from the drop-down menu. Depending on the grid type, the input measurement signals required for the grid type are displayed in the rows below.
  • Page 51 Manual  Measured values In the drop-down menu, select which raw signals are available. Based on the selection, the inputs for voltages or currents are displayed or hidden.  Show line-to-line This option is only available in a star system. It activates the additional inputs for U12, U23 and U31.
  • Page 52 Manual ibaPQU-S  Units The set units influence the calculated output values. If large input signals are combined in a calculation, e.g. kV and kA, this function produces understandable output values. Standard generation  Enable currents If Enable currents = TRUE, all current values are calculated additionally.
  • Page 53 Manual The values preset are taken from the standard IEC 61000-4-30 Ed. 3 class A. Using the threshold values you can set the detection limit from which the corresponding event can be recognized. The hysteresis sets the point of time when the event can be considered as terminated.

  • Page 54: En50160 Submodule: Power Frequency

    Manual ibaPQU-S The “EN50160” tab lists all signals calculated in the EN50160-compliant submodules. The message “Fully compliant” against a green background confirms compliance with the standard. If individual signals are disabled, the display changes to “Partially compli- ant” on a white background.
  • Page 55 Manual Configuration The “Configuration” section shows the characteristic value that is determined by this module as well as the measurement interval. Here: Power frequency acc. to EN50160, 10 s You can enable or disable all signals of this module in a drop-down menu. “Analog”...

  • Page 56: Submodule En50160: Supply Voltage Variation

    Manual ibaPQU-S 10.3.3 Submodule EN50160: Supply voltage variation “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2. Configuration  The “Configuration” section shows the characteristic values determined by this module as well as the measurement interval. Here: Supply voltage variation acc. to EN50160, 10 min.

  • Page 57: En50160 Submodule: Flicker Severity

    Ohm. “Analog” tab  Name The names are assigned by default. To allow an unambiguous identification, they contain the input channel, the characteristic value and the measurement interval.  Function Calculation function used by ibaPQU-S. Issue 1.5...

  • Page 58: En50160 Submodule: Supply Voltage Unbalance

    Manual ibaPQU-S  Input The signal used for calculation.  Unit Display of the relevant unit.  Active Here you can enable or disable the signal. 10.3.5 EN50160 submodule: Supply voltage unbalance “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 Configuration ...

  • Page 59: En50160 Submodule: Harmonic Voltage

     Name The names are assigned by default. To allow an unambiguous identification, they contain the input channel, the characteristic value and the measurement interval.  Function Calculation function used by ibaPQU-S.  Input The signals used for calculation.  Unit Display of the relevant unit.
  • Page 60 Manual ibaPQU-S Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 Configuration  The “Configuration” section shows the characteristic values determined by this module as well as the measurement interval. Here: Harmonic voltage acc. to EN50160, 10 min.

  • Page 61: En50160 Submodule: Mains Signalling Voltage

    Manual 10.3.7 EN50160 submodule: Mains signalling voltage “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 Configuration  The “Configuration” section shows the characteristic values determined by this module as well as the measurement interval. Here: Mains signalling voltage acc. to EN50160, 3 s.
  • Page 62 Manual ibaPQU-S “Analog” tab The EN50160 submodule: Mains signalling voltage calculates the harmonics 1-50 and the interharmonics 1-50 for each input channel plus the fundamental frequency and the DC component, in 3 second measurement intervals. In the signal display, the signals are grouped by input.

  • Page 63: En50160 Submodule: Voltage Events

    Manual 10.3.8 EN50160 submodule: Voltage events “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 Configuration  The “Configuration” section shows the characteristic values determined by this module as well as the measurement interval. Here: Voltage events acc. to EN50160, half period.

  • Page 64: Basic Submodule

    Manual ibaPQU-S The EN50160 submodule: Voltage events calculates the RMS value for each input chan- nel.  Name The names of the voltage events are assigned by default. You can additionally assign two comments by clicking the icon in the signal name field.
  • Page 65 Manual Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 “Analog” tab The Basic submodule captures the following characteristic values:  Power frequency in 200 ms and half period measurement intervals, respectively  For each input: RMS value, peak value, rectified value and frequency in 200 ms and half period measurement intervals ...

  • Page 66: 10.3.10 Phasor Submodule

    Manual ibaPQU-S 10.3.10 Phasor submodule “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 “Analog” tab The Phasor submodule captures the following characteristic values for each input:  RMS value, phase angle, frequency, measurement interval 200 ms In the signal display, the signals are grouped by input.
  • Page 67 Manual Display in the phasor diagram (phasor view) The voltage and current characteristics of the 3 phases can be visualized in a phasor diagram. Click the button in the ibaPDA toolbar to display the phasor diagram. Hold the mouse button down and drag the Phasor or Basic module from the signal tree on the left onto the display.

  • Page 68: 10.3.11 Power Submodule

    Manual ibaPQU-S 10.3.11 Power submodule “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 Configuration  Enable distortion power Set this option to “True” if you want to activate the calculation of the distortion power. “Analog” tab...
  • Page 69 Manual Depending on the AC/DC setting and the configured grid inputs, the Analog tab con- tains different characteristic values. AC/DC = DC Only active power, peak value and active energy are calculated. AC/DC = AC The following values are calculated for each phase: ...

  • Page 70: 10.3.12 Spectrum Submodule

    Manual ibaPQU-S 10.3.12 Spectrum submodule “General” tab Important note The total number of Harmonic voltage and Spectrum submodules per ibaPQU must not exceed nine (9) to avoid overloading the system. Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2...
  • Page 71 Manual Configuration  Input Select the input signal.  Update interval If the spectrum is required in another update time than 200 ms, you can set here as a default which time interval should be used.  Harmonics values Select whether to measure relative or absolute harmonics/interharmonics. ...
  • Page 72 Manual ibaPQU-S  Normalization: Hn/H1: All harmonics are normalized to the value of the fundamental frequency, i.e. divided by this value. This corresponds to the relative values in ibaPDA, how- ever without the factor 100 for percent. Hn/RMS: All harmonics are normalized to the RMS value, i.e. divided by the RMS...

  • Page 73: 10.3.13 Unbalance Submodule

    Manual  Active Here you can enable or disable the signal. 10.3.13 Unbalance submodule “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 “Analog” tab The “Analog” tab is only available for star grid with N/PE and a grid without N/PE. If the submodule is configured for a different grid, it is disabled when starting the meas- urement and a warning is displayed.
  • Page 74 Manual ibaPQU-S Signal Meaning Zero sequence unbalance Ratio of zero sequence component to positive sequence component in percent Negative sequence unbalance Ratio of negative sequence component to positive sequence component in percent Positive sequence component Percentage of symmetrical voltage vectors...

  • Page 75: 10.3.14 Flicker Severity Submodule

    Manual 10.3.14 Flicker severity submodule “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 Configuration  Lamp model To calculate the flicker, the lamp model to be used, 230V or 120V, has to be specified.  Flicker input ...
  • Page 76 Manual ibaPQU-S  Only currents For the calculation only currents are being used. For this purpose, you need to indicate for each conductor its impedance in Ohm.  Voltages and currents The flicker for voltages and currents is calculated. For the current flicker calcula- tion you need to indicate the impedance of the single conductors.

  • Page 77: 10.3.15 Aggregation Submodule

    Manual 10.3.15 Aggregation submodule The Aggregation submodule is a freely configurable module in which the measurement interval and the characteristic values can be selected individually. The submodule name is assigned automatically by ibaPDA and is in accordance with the set measurement interval.
  • Page 78 Manual ibaPQU-S  The following default intervals are available: 200 ms, 3 s, 10 s, 10 min or 2 h If you choose a default interval, the Unit and Amount fields will show the matching values and cannot be edited.
  • Page 79 Manual “Analog” tab The display in the “Analog” tab depends on the settings in the “General” tab. In the following example, we selected “Auto” mode and the submodules “Basic” and “Power”. The characteristic values defined in the submodules are listed in the “Analog” tab.
  • Page 80 Manual ibaPQU-S  Name You can select any name. You can additionally assign two comments by clicking the icon in the signal name field.  Function Select the characteristic value to be calculated from the drop-down menu: Phase, Peak value, …...
  • Page 81 Here you can enable or disable the signal. Special considerations for grids with user-defined nominal frequencies In addition to grids with 50 Hz and 60 Hz nominal frequency, ibaPQU-S also allows taking measurements in grids with a user-defined frequency. If a user-defined power frequency is set (in the PQU-S module), this will influence the length of the 200 ms measurement interval and the naming in the Aggregation submodule.

  • Page 82: 10.3.16 Commutation Notches Submodule

    Manual ibaPQU-S 10.3.16 Commutation notches submodule “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 “Analog” tab  Signals: Depth of notch per phase in percent Issue 1.5...

  • Page 83: 10.3.17 Events Submodule

    Manual 10.3.17 Events submodule “General” tab Basic settings  See Power frequency submodule, “General” tab, chapter 10.3.2 You will find the configuration of the event limits in chapter 10.3.1 “Grid module”. “Analog” tab Signal Meaning Start How many seconds ago did the event start Duration Duration of the event Min/Max...
  • Page 84 Manual ibaPQU-S Delta Umax / Delta Uss Delta Umax: RMS value that was furthest from the floating average. Delta Uss: Difference between Uss and the start of the event and Uss and the end of the event. Uss: Floating average of the half period RMS value over 1 second “Digital”...

  • Page 85: Technical Data

    Manual Technical data 11.1 Main data Brief description Description ibaPQU-S Description Central unit for (iba modular system) Power Quality Monitoring applications Order number 10.150000 Processor unit Processor 1.6 GHz Atom processor, dual core CPU Flash memory Solid-state drive Clock Unbuffered / external buffering possible...

  • Page 86: Interfaces

    32Mbit Flex (bidirectional) Connector type 2 ST connectors for RX and TX; iba recommends the use of FO with multimode fibers of type 50/125 μm or 62.5/125 μm; For information on cable length, see chap. 11.7. Transmitting interface (TX) Output power 50/125 µm FO cable...

  • Page 87: Digital Inputs

    Manual 11.3 Digital inputs Digital inputs Number Version Galvanically isolated, protected against reverse polarity, single ended Input signal 24 V DC Max. input voltage ±60 V permanent Signal level log. 0 > -6 V; < +6 V Signal level log. 1 <...

  • Page 88: Grid Characteristics

    Manual ibaPQU-S 11.4 Grid characteristics Grid types 1-phase grid, 3-phase grid without N/PE, 3-phase grid with N/PE Grid frequency 10-80 Hz Characteristic values Calculation time Grid type Half period 10/12 150/180 10 s 10 min     ...

  • Page 89: Dimensions

    Manual 11.5 Dimensions ibaPQU-S (Dimensions in mm) Dimensions of ibaPQU-S with cables (dimensions in mm) Issue 1.5...
  • Page 90 Manual ibaPQU-S Distance between two ibaPQU-S systems (Dimensions in mm) Issue 1.5...
  • Page 91 Manual ibaPQU-S and backplane (Dimensions in mm) Issue 1.5...
  • Page 92 Manual ibaPQU-S Dimensions of ibaPADU-S-B1S with modules (dimensions in mm) Issue 1.5...

  • Page 93: Connection Diagram

    Manual 11.6 Connection diagram 11.6.1 Pin assignment voltage supply X14 Connection + 24 V 11.6.2 Pin assignment digital inputs X5 Connection Digital input 00 + Digital input 00 - Digital input 01 + Digital input 01 - Digital input 02 + Digital input 02 - Digital input 03 + Digital input 03 -...

  • Page 94: Example For Fo Budget Calculation

    Manual ibaPQU-S 11.7 Example for FO budget calculation As an example, an FO connection from an ibaFOB-io-Dexp card (FO transmitter) to an ibaBM-PN device (FO receiver) is used. The example refers to a point-to-point connection with an FO cable of type 62.5/125 µm.
  • Page 95 Manual Equation for calculating the FO budget (A Budget �� = |(�� − �� ������������ ���������������� ������������ = sensitivity of FO receiving interface Receiver = output power of FO transmitting interface Sender Equation for calculating the fiber optic cable length (l ��...

  • Page 96: Accessories

    Manual ibaPQU-S Accessories 12.1 Backplane panels 12.1.1 ibaPADU-S-B4S Backplane panel for mounting 1 central unit and up to 4 I/O modules. 12.1.1.1 Scope of delivery  Backplane panel  Assembly kit Issue 1.5...
  • Page 97 Manual Assembly kit 12.1.1.2 Dimensions Dimensions in mm Dimensions ibaPADU-S-B4S with mounting angles (dimensions in mm) Issue 1.5...
  • Page 98 12.1.1.4 Technical data Short description Product name ibaPADU-S-B4S Description Backplane panel for 1 central unit and up to 4 I/O modules from the iba modular system Order number 10.124000 Interface central unit Number Connection type Female header, pole number 3 x 32...

  • Page 99: Ibapadu-S-B1S

    Manual 12.1.2 ibaPADU-S-B1S Backplane panel for mounting 1 central unit and 1 I/O module. 12.1.2.1 Scope of delivery  Backplane panel  Assembly kit Issue 1.5...
  • Page 100 See chapter 12.1.1.3 12.1.2.4 Technical data Short description Product name ibaPADU-S-B1S Description Backplane panel for 1 central unit and 1 I/O module from the iba modular system; with mounting angles Order number 10.124002 Interface central unit Number Connection type Female header, pole number 3 x 32...

  • Page 101: Mounting System For Central Unit

    Manual Mounting Housing 4 through holes M6 Assembly kit Grounding 1 thread M6, rear side Assembly kit enclosed Design Dimensions (width x height x depth) 99 mm x 247 mm x 21 mm Weight / incl. packaging 0.32 kg / 0.43 kg 12.2 Mounting system for central unit 12.2.1...
  • Page 102 The grounding must be done via the DIN rail. 12.2.1.4 Technical data Short description Product name ibaPADU-S-B Description Mounting panel for 1 central unit from the iba modular system; with DIN rail clip Order number 10.124001 Mounting Panel on DIN rail according to EN 50022 (TS 35, DIN Rail 35)

  • Page 103: Mounting Systems For Ibapadu-S-B4S

    12.3 Mounting systems for ibaPADU-S-B4S 12.3.1 Mounting angles Mounting angles for mounting an iba modular system in a cabinet, 2 pieces, matching for ibaPADU-S-B4S (10.124000). 1 set (2 pieces) is needed for one ibaPADU-S-B4S backplane panel. 12.3.1.1 Scope of delivery ...

  • Page 104: Mounting Panel 19

    Manual ibaPQU-S Mounting panel 19“ 12.3.2 Mounting panel (483 mm/19“) for up to 2 ibaPADU-S-B4S backplane panels. 12.3.2.1 Scope of delivery  Mounting panel  Assembly kit Issue 1.5...
  • Page 105 Manual 12.3.2.2 Mounting backplane panel Up to 2 ibaPADU-S-B4S backplane panels can be mounted on the 19" mounting panel. The mounting of one backplane panel is possible either in the center or on the right or left side. Mounting centered Mounting on the right Issue 1.5...
  • Page 106 Manual ibaPQU-S 12.3.2.3 Dimensions Dimensions in mm Issue 1.5...
  • Page 107 Manual 12.3.2.4 Grounding Variation 1: One backplane panel and grounding of the mounting panel are on the same side. After the backplane panel is mounted on the 19" mounting panel, the backplane panel must be grounded via the mounting panel. Screw the grounding cable on the back of the mounting panel to the backplane panel.
  • Page 108 Manual ibaPQU-S Variation 2: One backplane panel and grounding of the mounting panel are not on the same side. The backplane panel is mounted on the right or left side of the mounting panel, the grounding of the mounting panel is connected on the respective other side. Ground the backplane panel at the next threaded bolt of the mounting panel.

  • Page 109: Module Carrier

    Manual 12.3.2.5 Technical data Short description Mounting panel 19“ for iba modular system Product name Mounting panel (483 mm/19“) for up to 2 ibaPADU-S- Description B4S backplane panels Order number 10.124005 Mounting Panel 4 through holes Assembly kit enclosed Grounding...

  • Page 110: Terminal Blocks

    W x h x d: 230 mm x 435 mm x 200 mm 12.3.3.3 Technical data Short description Product name Module carrier for iba modular system Description Module carrier for mounting 1 backplane panel ibaPADU-S-B4S; incl. power supply 24 V DC / 5 A (10.800007) Order number 10.124007...

  • Page 111: I/O Modules Iba Modular System

    Manual 12.5 I/O modules iba modular system Product Order No. Note ibaMS3xAI-1A 10.124600 3 analog inputs, 1 A AC ibaMS3xAI-5A 10.124610 3 analog inputs, 5 A AC ibaMS3xAI-1A/100A 10.124620 3 analog inputs, 1 A AC/100 A DC ibaMS4xAI-380VAC 10.124521 4 analog inputs, 380 V AC ibaMS8xAI-110VAC 10.124500...

  • Page 112: Fo Cards/Cables

    For measuring with the notebook ibaFOB-io-USB 11.117010 For measuring with the notebook iba also offers suitable fiber optic cables in different designs and lengths. Here is an example of a common cable in duplex and 5 m length. Product Order no.

  • Page 113: Appendix

    Manual Appendix 13.1 Calculating characteristic values The characteristic values are calculated as follows: 13.1.1 RMS (Root Mean Square) 13.1.2 Rectified value 13.1.3 Peak value 13.1.4 Form factor 13.1.5 Crest factor 13.1.6 Frequency 13.1.7 Harmonics, interharmonics, phase angle Calculation with FFT algorithm 13.1.8 THD (Total Harmonic Distorsion) Issue 1.5...

  • Page 114: Flicker

    Manual ibaPQU-S 13.1.9 Flicker  Short term Flicker algorithm  Long term 13.1.10 Power / Energy  Two conductors / per phase Active power Apparent power Total reactive power Fundamental reactive power Distortion reactive power Power factor Cos φ Issue 1.5...
  • Page 115 Manual  Three conductors Active power Apparent power Total reactive power Fundamental reactive power Distortion reactive power Power factor Cos φ Per phase: Total grid: no calculation possible Issue 1.5...
  • Page 116 Manual ibaPQU-S  Four conductors Active power Apparent power Total reactive power Fundamental reactive power Distortion reactive power Per phase: Total grid: Power factor Cos φ Per phase: Total grid: no calculation possible Neutral conductor current (if physically not available)

  • Page 117: 13.1.11 Voltage Balance / Unbalance

    Manual 13.1.11 Voltage balance / Unbalance Example graph from ibaPDA (high asymmetry!) In a symmetrical grid the arrows of the respective phase are located directly over each other. Name Meaning RMS value of the phase Percentage of the positive sequence component Percentage of the negative sequence component Percentage of the zero sequence component Positive sequence component...

  • Page 118: 13.1.12 Interference Factor

    Manual ibaPQU-S The voltages specified here are complex numbers and consist of an amount and an angle. Negative sequence unbalance Zero sequence unbalance 13.1.12 Interference factor  TIF/THFF : Nominal power system frequency (50 Hz or 60 Hz) Factor : Weighting factor for harmonic Various methods are available for normalization of Issue 1.5...

  • Page 119: 13.1.13 Commutation Notches

    Manual 13.1.13 Commutation notches Commutation notch = voltage drop = peak value of the fundamental wave of the nominal voltage Issue 1.5...

  • Page 120: 13.1.14 Events

    Manual ibaPQU-S 13.1.14 Events  Voltage dip Signal Meaning Dip event (digital) Active, if the half period RMS value of at least one phase is lower than the limit. Current time – start_time, in seconds, while the Dip event Start event is running.
  • Page 121 Manual  Mains signalling Signal Meaning Mains signalling event (digital) Active, if the RMS value of the mains signalling voltage on at least one phase is higher than the limit set. Current_time – start_time, in seconds, while the Mains signalling event Start event is running.

  • Page 122: Connection Examples

    The examples mentioned here refer to a grid with 230 V and 50 Hz. Furthermore, the consumers to be measured are directly connected to the ibaPQU-S system. If the values voltage and current to be measured are higher, appropriate instrument transformers need to be used.

  • Page 123: Delta Connection

    Manual 13.2.3 Delta connection Delta connection direct connection 13.2.4 Connection with instrument transformers It is important that the instrument transformers are Open Loop transformers. This means that a sinus signal on the primary side also needs to exist on the secondary side. The instrument transformers also need to offer a broadband frequency transmission in order to capture harmonics or interharmonics up to the 50th harmonic.
  • Page 124 Manual ibaPQU-S Example of 1-phase measuring with a Rogowski coil or a current clamp Issue 1.5...
  • Page 125 Manual Index IP address via FO backplane Measurements Calculated characteristic values 24, 78 Current measurement Nominal frequency Debounce filter configure in ibaPDA Phasor diagram 66, 69 Digital signals Pin assignment configure in ibaPDA digital inputs DIN EN 50160 11, 34 Power supply Display digital inputs...
  • Page 126 Manual ibaPQU-S Certificate Issue 1.5...
  • Page 127 Mailing address iba AG Postbox 1828 D-90708 Fuerth Germany Delivery address iba AG Gebhardtstrasse 10 DE-90762 Fuerth Germany Regional and Worldwide For contact data of your regional iba office or representative please refer to our web site www.iba-ag.com. Issue 1.5...

Table of Contents
