Summary of Contents for Power-Lite MS-6M-360
- Page 1 Certainty at The Speed of Light INSTALLATION MANUAL INFRARED MOTION SENSOR MS-6M-360...
- Page 2 Introduction Connection Installation MS-6M-360 infrared motion sensor Warning. Danger of death through electric shock! The sensor has great detection sensitivity via integrated circuitry. It utilizes the infrared energy from Must be installed by professional electrician. humans as the control-signal source.
- Page 3 Testing the Sensor Wiring Diagram • Adjust the hold time using the time control on the side of the sensor to 10 seconds. Rear Cable Entry • Switch on the power; the sensor and its connected lamp will have no signal to start with. After Warm-up 30sec, the sensor will work.
