- Page 2 Follow Us On Social Media Thank you for purchasing this Element RC product. This assembly manual contains instructions and tips for building and maintaining your new Enduro chassis. Please take a moment to read through this manual to help familiarize yourself with these steps.
- Page 3 33.657120, -117.701139 HARDWARE 1:1 SCALE VIEW HARDWARE USED WITH OPTIONAL REPLACEMENT PART NUMBERS FLAT HEAD SCREWS (FHCS) SOCKET HEAD SCREWS (SHCS) SHIMS AND WASHERS 2x5mm (31511) 2.5x10mm (31350) 3x7mmx1mm (42260) 2x8mm (7187) 2.5x14mm (41077) 2.5x6mm (41079) 3x7mmx2mm (42260) 3x6mm (31541) 2.5x10mm (41087) 3x8mm (25201) 3x7x3mm (42260)
- Page 4 33.657120, -117.701139 TABLE OF CONTENTS 4/17/2023 COVER DRIVESHAFTS BUILD INTRODUCTION SHOCKS BUILD 1:1 HARDWARE “FOLD OUT” BUMPERS BUILD TABLE OF CONTENTS WHEELS/TIRES BUILD Stealth XF BUILD BODY BUILD Chassis BUILD OPTIONAL GEARBOX BUILD REAR AXLES BUILD TRAIL TIPS LINKS BUILD BACK COVER USING THIS MANUAL This symbol indicates a special note or...
- Page 5 YOUR BUILD BEGINS HERE. GATE 01 STEALTH XF BUILD: 42316 42315 Stealth XF Stealth XF Drive Gear, 52T Case 42319 42025 Top Shaft Idler Shaft Pin 2x9mm 42321 91560 5x10x4mm 5x10x4mm Bushing Bearing 42320 Stealth XF 42025 42315 Idler Shaft Stealth XF 31350 Case...
- Page 6 GATE 04 STEALTH XF BUILD: Motor 42321 91560 25201 5x10x4mm 5x10x4mm 3x8mm Bushing Bearing FHCS 42317 Stealth XF Running Gear Shaft 25225 3x3mm 31531 1336 Set Screw 3x6mm Pinion Gear BHCS 42316 NOTE: Make sure the gear mesh 41090 42317 between the running gear and Stealth XF 3x10mm...
- Page 7 33.657120, -117.701139 GATE 03 CHASSIS BUILD: 31532 3x8mm BHCS 42346 Steering Plate 42346 Steering Rack 42345 Diff Case, 42344 Links, 48mm 42216 Ballstud 42345 Diff Case, Bottom 89210 3x20mm FHCS GATE 04 CHASSIS BUILD: 89202 42348 3x12mm Shim, BHCS 42216 Ballstud 31510 2x4mm...
- Page 8 GATE 05 CHASSIS BUILD: 25202 41090 3x10mm 3x10mm FHCS LP SHCS Servo 42344 42345 Link, Servo 44mm Plate 42215 Servo Horn 42348 Shim, 42216 31532 Ballstud 3x8mm BHCS GATE 06 CHASSIS BUILD: 42216 Ballstud, 42348 Shouldered 91560 42321 Shim, 5x10x4mm 5x10x4mm Bearing Bushing...
- Page 9 33.657120, -117.701139 GATE 08 CHASSIS BUILD: 42020 42021 42314 42021 31532 Gearbox Side Drive Shaft, Drive Shaft, Female Pin, 3x8mm Male, CVA (33mm, 42mm) 2x11mm BHCS 42020 Axle Side 42020 42021 Pin Retainer, Drive Shaft 42021 Long Barrel Drive Shaft, 42314 42314 Female, CVA...
- Page 10 GATE 11 CHASSIS BUILD: 42301 NOTE: Install Left and 71050 25202 Fuel Cell, Right side Rock Sliders Hook and 3x10mm Loop Straps FHCS 42302 Battery Box, Shorty Pack 42325 SE Rock 42302 Slider Battery Brace 89202 25211 3x12mm 3x10mm BHCS BHCS GATE 12 CHASSIS BUILD:...
- Page 11 33.657120, -117.701139 GATE 14 CHASSIS BUILD: 42304 Shock Mount (Left, Rear) 25203 3x12mm FHCS 42304 Shock Mount (Left, Front) GATE 01 REAR AXLE BUILD: 42335 Ring Gear, 4673 42335 42336 2.5x4mm Pinion Gear, FT Ring/Pinion BHCS Option 42307 Axle Housing, Rear 42308 Axle Housing...
- Page 12 GATE 01 LINKS BUILD: 25188 42041 3x20mm, Pivot Ball, BHCS NOTE: Build and install two rear upper links 41078 42344 3x28mm BHCS Link, 146mm NOTE: Check the rod end 25215 angles before installation M3 Locknut, Black 146.00mm GATE 02 LINKS BUILD: 4689 3x16mm NOTE: Check the rod end...
- Page 13 33.657120, -117.701139 GATE 01 SHOCK BUILD: 31865 42311 O-Ring, Small, Shock Cap Shock Piston 42312 2661 Shock Body, E-Clip 10x32mm 5407 Shock Eyelet (mm) O-Ring, Rear 42311 Front 42083 Shock O-Ring Shock Shaft, Pro Tip: 42348 Spacer 3x30mm Use #1105 Green Enduro Slime on O-Rings Rod Ends...
- Page 14 GATE 04 SHOCK BUILD: 42041 42041 Pivot Ball, Pivot Ball, Upper Shock Upper Shock 89203 3x16mm BHCS 91478 4689 89203 3x30mm 3x16mm 3x16mm BHCS Set Screw 42308 BHCS 5mm Shim 25215 42041 42041 Pivot Ball Pivot Ball Locknut GATE 01 BUMPER BUILD: 42353 Front...
- Page 15 33.657120, -117.701139 GATE 01 WHEEL/TIRE BUILD 42328 *Optional NOTE: Install #41088 screws in 42328 Hex Adapters Hex Adapter, a crossing pattern Inner Wheel, Black Black 42103 Aluminum 42349 42104 Brass Pinseeker Tire 42329 Tire, Insert 42328 Ring, Black 42332 2.6x10mm SHCS, Silver 42328 Outer Wheel, Black...
- Page 16 GATE 01 STEALTH XF: BUILD CONFIGURATION: OVERDRIVE: Overdrive is a scenario where the front and rear wheels do not rotate at the same speed. The Stealth XF gearbox is designed to allow the front wheels to spin faster than the rear wheels. Overdrive is advantageouse when climbing up rock faces because the front tires will want to pull the vehicle up the rock.
- Page 17 33.657120, -117.701139 TRAIL TIPS AND CHECKLIST PREPARING TO HIT THE TRAIL: When preparing to hit the trail, it’s a good idea to have a checklist to make sure you have everything and don’t end up having to head back early. We’ve compiled a checklist of the things we think you’ll need on the trail. We’ve also left some space for you to add your specifi...
