Specifi cations - EA273WM
Monitor Specifi cations
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DisplayPort:
DisplayPort Connector:
DVI:
VGA:
15pin Mini D-sub:
HDMI:
HDMI Connector:
Display Colours
Synchronization Range
Viewing Angle
Image Formation Time
Resolutions Supported
Active Display Area
Landscape: Horiz.:
USB Hub
AUDIO
AUDIO Input:
STEREO Mini Jack:
DisplayPort Connector:
HDMI Connector:
Headphone Output: STEREO Mini Jack:
Speakers
Practical Audio Output:
ControlSync
(available up to 5 sub monitors)
Power Supply
Current Rating
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current fl at panel technologies when displaying non-native resolutions full screen. In fl at panel technologies, each dot on the screen is actually one
pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE:
Technical specifi cations are subject to change without notice.
MultiSync EA273WM
Diagonal:
68.57 cm/27.0 inches
68.57 cm/27.0 inches
1920 x 1080
Digital RGB
DVI-D 24pin:
Digital RGB
Analog RGB
Sync
Digital YUV
Digital RGB
16,777,216
Horizontal:
31.5 kHz to 83.0 kHz (Analog)
31.5 kHz to 83.0 kHz (Digital)
Vertical:
56 Hz to 75 Hz
Left/Right:
±80° (CR > 10)
Up/Down:
±80° (CR > 10)
5 ms (Typ.)
1
720 x 400*
: VGA text
1
640 x 480*
@ 60 Hz to 75 Hz
800 x 600*
1
@ 56 Hz to 75 Hz
832 x 624*
1
@ 75 Hz
1024 x 768*
1
1152 x 870*
1
1280 x 1024*
1400 x 1050*
1
1440 x 900*
1920 x 1080 @ 60 Hz........................................... NEC DISPLAY SOLUTIONS cites recommended.
597.6 mm/23.5 inches
Vert.:
336.2 mm/13.2 inches
Portrait: Horiz.:
336.2 mm/13.2 inches
Vert.:
597.6 mm/23.5 inches
I/F:
USB Specifi cation Revision 2.0
Port:
Upstream 1
Downstream 4
Load Current:
Maximum 0.5A per port
Analog Audio
Digital Audio
Digital Audio
1.0 W + 1.0 W
IN:
Stereo Micro jack 2.5 φ
OUT:
Stereo Micro jack 2.5 φ
AC 100-240 V ~ 50/60 Hz
0.95 - 0.50 A (with USB and Audio)
Landscape:
631.4 mm (W) x 415.0 - 545.0 mm (H) x 230.0 mm (D)
24.9 inches (W) x 16.3 - 21.5 inches (H) x 9.1 inches (D)
Portrait:
371.8 mm (W) x 647.2 - 674.8 mm (H) x 230.0 mm (D)
14.6 inches (W) x 25.5 - 26.6 inches (H) x 9.1 inches (D)
130 mm / 5.1 inches (Landscape orientation)
27.6 mm / 1.1 inches (Portrait orientation)
7.2 kg (15.9 lbs)/Without stand: 4.3 kg (9.5 lbs)
5°C to 35°C/41°F to 95°F
Humidity:
30% to 80%
Altitude:
0 to 6,562 Feet/0 to 2,000 m
-10°C to 60°C/14°F to 140°F
Humidity:
10% to 85%
Altitude:
0 to 40,000 Feet/0 to 12,192 m
@ 60 Hz to 75 Hz
@ 75 Hz
1
@ 60 Hz to 75 Hz
1
@ 60 Hz
@ 60 Hz
English-18
Notes
Active matrix; thin fi lm transistor (TFT) liquid crystal
display (LCD); 0.311 mm dot pitch; 300 cd/m
luminance; 1000:1 contrast ratio (typical), (25000:1
Contrast ratio, Dynamic).
DisplayPort Complies with Standard V1.1a,
applicable to HDCP
DVI (HDCP)
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
HDMI
Depends on display card used.
Automatically
Automatically
Automatically
Some systems may not support all modes listed.
Stereo L/R 500mV rms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Impedance 32 Ohm
2
