Unpack the machine and check the components
Toner Cartridge and Drum
Unit Assemblies*
(Black, Cyan, Magenta, and
* Installed in the machine
1
Remove the packing materials and re-install the toner cartridge and drum unit assemblies
Remove all the blue packing tape.
Remove the orange parts from each
cartridge.
2
Load paper in the paper tray
3
Connect the power cord and turn the machine on
Back
Quick Setup Guide
HL-L3215CW / HL-L3220CW / HL-L3220CWE / HL-L3220CDW / HL-L3240CDW /
HL-L3280CDW / HL-L8230CDW / HL-L8240CDW
UK
Read the Product Safety Guide first, then read this Quick Setup Guide for the correct installation procedure.
Not all models are available in all countries.
Video setup instructions:
support.brother.com/videos
Waste Toner Box*
Yellow)
AC Power Cord
x4
BK
C
M
Y
Location of the power button varies depending on the model.
NOTE:
• The components included in the box may differ depending on your
country.
• The available connection interfaces vary depending on the model.
You must purchase the correct interface cable if you require one.
• USB cable
Belt Unit*
• Network cable (HL-L3240CDW / HL-L3280CDW / HL-L8240CDW)
• The illustrations in this Quick Setup Guide show the HL-L3240CDW.
• Brother aims to reduce waste and save both raw materials and the
Quick Setup Guide
energy required to produce them. Read more about our environmental
work at www.brotherearth.com.
Product Safety Guide
Push firmly.
Adjust the paper
guides.
NOTE:
Before connecting the power cord, locate the
Serial Number label on the back or side of the
machine. Record this number for Registration
and Warranty support.
Front
The latest manuals are available at the Brother support website:
support.brother.com/manuals
We recommend using a USB 2.0 cable (Type A/B) that is no more
than 2 metres long.
Use a straight-through Category 5 (or greater) twisted-pair cable.
Do not exceed this mark.
