BIOS User Guide
Hi-Fi H170S3H / Hi-Fi B150S3H
BIOS Update ������������������������������������������������������������������������������������� 2
UEFI BIOS Setup �������������������������������������������������������������������������������� 6
1� Main Menu ����������������������������������������������������������������������������������� 7
2� Advanced Menu ���������������������������������������������������������������������������� 8
3� Chipset Menu �������������������������������������������������������������������������������18
4� Boot Menu �����������������������������������������������������������������������������������22
5� Security Menu ������������������������������������������������������������������������������25
6� O�N�E Menu����������������������������������������������������������������������������������28
7� Exit Menu�������������������������������������������������������������������������������������35

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hi-Fi B150S3H and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar Hi-Fi B150S3H

  • Page 1: Table Of Contents

    BIOS User Guide Hi-Fi H170S3H / Hi-Fi B150S3H BIOS Update ������������������������������������������������������������������������������������� 2 UEFI BIOS Setup �������������������������������������������������������������������������������� 6 1� Main Menu ����������������������������������������������������������������������������������� 7 2� Advanced Menu ���������������������������������������������������������������������������� 8 3� Chipset Menu �������������������������������������������������������������������������������18 4� Boot Menu �����������������������������������������������������������������������������������22 5� Security Menu ������������������������������������������������������������������������������25 6� O�N�E Menu����������������������������������������������������������������������������������28...
  • Page 2: Bios Update

    The BIOS can be updated using either of the following utilities: •  BIOSTAR BIOS Flasher: Using this utility, the BIOS can be updated from a file on a hard disk, a USB drive (a flash drive or a USB hard drive), or a CD-ROM.
  • Page 3 Hi-Fi H170S3H / Hi-Fi B150S3H 7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the <Y> key to restart system. 8. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.
  • Page 4 Then, the BIOS Update is completed. BIOS Update Utility (through a BIOS file) 1. Installing BIOS Update Utility from the DVD Driver. 2. Download the proper BIOS from http://www.biostar.com.tw/ 3. Launch BIOS Update Utility and click the “Update BIOS” button on the main screen.
  • Page 5 Hi-Fi H170S3H / Hi-Fi B150S3H 6. After the BIOS Update process is finished, click on “OK” to reboot the system. 7. While the system boots up and the full screen logo shows up, press <DEL> key to enter BIOS setup.
  • Page 6: Uefi Bios Setup

    UEFI BIOS Setup Introduction The purpose of this manual is to describe the settings in the AMI UEFI BIOS Setup program on this motherboard. The Setup program allows users to modify the basic system configuration and save these settings to NVRAM. UEFI BIOS determines what a computer can do without accessing programs from a disk.
  • Page 7: 1� Main Menu

    Hi-Fi H170S3H / Hi-Fi B150S3H 1� Main Menu Once you enter AMI UEFI BIOS Setup Utility, the Main Menu will appear on the screen providing an overview of the basic system information. BIOS Information It shows system information including UEFI BIOS version, Project Code, Model Name, Build Date and etc.
  • Page 8: 2� Advanced Menu

    2� Advanced Menu The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power Management, and other system devices. Note   » Beware of that setting inappropriate values in items of this menu may cause system to malfunction. Trusted Computing TPM Device Selection This item selects TPM device: PTT or TPM.
  • Page 9 Hi-Fi H170S3H / Hi-Fi B150S3H Security Device Support This item enables or disables BIOS support for security device. O.S. will not show security device. TCG EFI protocol and INT1A interface will not be available. Options: Enable (Default) / Disable Pending operation This item schedule an operation for the security device.
  • Page 10 Enable ACPI Auto Configuration This item enables or disables BIOS ACPI auto configuration function. Options: Disabled (Default) / Enabled Enable Hibernation This item enables or disables system ability to hibernate (0S/S4 sleep state). This option may be not effective with some OS. Options: Enabled (Default) / Disabled ACPI Sleep State This item selects the highest ACPI sleep state the system will enter when the SUSPEND button is...
  • Page 11 Hi-Fi H170S3H / Hi-Fi B150S3H SMART FAN Control CPU Smart Fan1 This item allows you to control the CPU/System Smart Fan function. Options: Disabled (Default) / Auto Note   » The following items appear only when you set the Smart Fan function to [Auto].
  • Page 12 Super IO Configuration Serial Port 1 Configuration Serial Port This item enables or disables Serial Port (COM). Options: Enabled (Default) / Disabled Change Settings This item selects an optimal setting for Super IO device. Options: Auto (Default) / IO=3F8h; IRQ=4 / IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12 / IO=3E8h;...
  • Page 13 Hi-Fi H170S3H / Hi-Fi B150S3H H/W Monitor Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. Options: Disabled (Default) / 70°C/158°F / 75°C/167°F / 80°C/176°F / 85°C/185°F / 90°C/194°F CPU Configuration This item shows CPU Information...
  • Page 14 Active Processor Cores This item sets number of cores to enable in each processor package. Options: All (Default) / 1 / 2 / 3 Overclocking lock This item sets Overclocking lock. Options: Disabled (Default) / Enabled Intel Virtualization Technology Virtualization Technology can virtually separate your system resource into several parts, thus enhance the performance when running virtual machines or multi interface systems.
  • Page 15 Hi-Fi H170S3H / Hi-Fi B150S3H SATA Controller(s) This item enables/disables Serial ATA Device. Options: Enabled (Default) / Disabled SATA Mode Selection This item determines how SATA controller(s) operate. Options: AHCI (Default) / RAID SMART Self Test This item runs SMART Self Test on all HDDs during POST.
  • Page 16 NVMe Configuration The item shows NVMe controller and driver information. USB Configuration Legacy USB Support The item allows you to enable Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Options: Enabled (Default) / Disabled / Auto XHCI Hand-off This is a workaround for OSes without XHCI hand-off support.
  • Page 17 Hi-Fi H170S3H / Hi-Fi B150S3H USB Mass Storage Driver Support The item allows you to enable or disable USB Mass Storage Driver Support. Options: Enabled (Default) / Disabled Port 60/64 Emulation The item allows you to enable or disable I/O port 60h/64h emulation support. This should be enabled for the complete USB keyboard legacy support for non-USB aware OSes.
  • Page 18: 3� Chipset Menu

    3� Chipset Menu This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. Note  ...
  • Page 19 Hi-Fi H170S3H / Hi-Fi B150S3H PCI Express Configuration PEX1_1/PEX1_2 Options: Auto(Default) / Gen1 / Gen2 / Gen3 HD Audio Control Detection of the HD-Audio device. Disabled = HDA will be unconditionally disabled. Enabled = HDA will be enabled. Options: Auto (Default) / Disabled / Enabled EuP Control When EuP is enabled, the system will meet EuP requirement.
  • Page 20 VT-d This item enables or disables VT-d capability. Options: Enabled (Default) / Disabled Max TOLUD Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. Options: Dynamic (Default) / 1 GB / 1.25 GB / 1.5 GB / 1.75 GB / 2 GB / 2.25 GB / 2.5 GB / 2.75 GB / 3 GB / 3.25 GB / 3.5GB Internal Graphics This item keeps IGD enabled based on the setup options.
  • Page 21 Hi-Fi H170S3H / Hi-Fi B150S3H Onboard Device Onboard LAN1 This item enables/disables Onbaord LAN1. Options: Enabled (Default) / Disabled Onboard LAN1 Option ROM This item enables/disables Onboard LAN1 Option ROM. Options: Disabled (Default) / Enabled 3. Chipset Menu | 21...
  • Page 22: 4� Boot Menu

    4� Boot Menu This menu allows you to setup the system boot options. Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. Options: 1 (Default) Bootup NumLock State This item selects the keyboard NumLock state. Options: On (Default) / Off Full Screen Logo Display This item allows you to enable/disable Full Screen Logo Show function.
  • Page 23 Hi-Fi H170S3H / Hi-Fi B150S3H SATA Support Options: All Sata Devices (Default) / Last Boot HDD Only VGA Support If Auto, only install Legacy OpRom with Legacy OS and logo would NOT be shown during post. EFI driver will still installed with EFI.
  • Page 24 Other PCI device For PCI devices other than Network, Mass storage or video defines which OpROM to launch. Options: Legacy (Default) / UEFI / Do not launch New Boot Option Policy It controls the placement of newly detected UEFI boot options. Options: Default (Default) / Place First / Place Last Boot Option Priorities The items specify the boot device priority sequence from the available devices.
  • Page 25: 5� Security Menu

    Hi-Fi H170S3H / Hi-Fi B150S3H 5� Security Menu Administrator Password This item sets Administrator Password. User Password This item sets User Password. Secure Boot Menu 5. Security Menu | 25...
  • Page 26 Secure Boot Secure Boot can be enabled if 1. System running in user mode with enrolled Platform Key(PK) 2.CSM function is disabled. Options: Disabled (Default) / Enabled Secure Boot Mode Secure Boot mode selector. ‘Custom’ mode enables users to change Image Execution policy and manage Secure Boot Keys.
  • Page 27 Hi-Fi H170S3H / Hi-Fi B150S3H Forbidden Signature Delete Key – Allows you to delete the DBX file from your system. Set new Key – Allows you set new DBK file. Append Key – Allows you append Var to DBX. Authorized Timestamps Set new Key –...
  • Page 28: 6� O�N�E Menu

    6� O�N�E Menu This submenu allows you to change voltage and clock of various devices. Note   » We suggest you use the default setting. Changing the voltage and clock improperly may damage the device.   » The options and default settings might be different by RAM or CPU models.  ...
  • Page 29 Hi-Fi H170S3H / Hi-Fi B150S3H Memory Profile Select DIMM timing profile. The blow values start with the current running values and don’t auto populate. Options: Auto (Default) / Manual Note   » The following items appear only when you set the Memory Profiles function to [Manual] Memory Reference Clock This sets the memory reference clock in Automatic, 133MHZ or 100MHZ.
  • Page 30 tRAS This item allows you to select Row Active Time, 0: AUTO, max: 64 Options: Auto (Default) tCWL This item allows you to select Minimum CAS Write Latency Range, 0: AUTO, max: 20 Options: Auto (Default) tFAW This item allows you to select Four Active Window Delay, 0: AUTO, max: 63 Options: Auto (Default) tREFI This item allows you to select Maximum tREFI time,, 0: AUTO, max: 65535...
  • Page 31 Hi-Fi H170S3H / Hi-Fi B150S3H Voltage Configuration CPU Vcore Over Voltage This item sets CPU Vcore Over Voltage. Options: Auto (Default) / Override / Adaptive Note   » The following items appear only when you set the CPU Vcore Over Voltage to [Override] CPU Vcore Adjust Voltage Options: 1.300V (Default), Range: 1.000V-1.800V...
  • Page 32 CPU GT Offset Voltage Options: Auto (Default), Range: 0.0V-0.635V DRAM Voltage This item sets DRAM Over Voltage. Options: Auto (Default) / 1.35V / 1.42V CPU Power Management Intel(R) SpeedStep(tm) This item enables/disables Enhanced Intel SpeedStep Technology. Options: Enabled (Default) / Disabled Turbo Mode This item enables/disables CPU Turbo Mode.
  • Page 33 Hi-Fi H170S3H / Hi-Fi B150S3H CPU C states This item enables or disables CPU C states. Options: Auto (Default) / Enabled / Disabled Enhanced C-states This item enables or disables C1E. When enabled, CPU will switch to minimum speed when all cores enter C-State.
  • Page 34 Memory Insight DIMM Profile These items display memory information. 34 | 6. O.N.E Menu...
  • Page 35: 7� Exit Menu

    Hi-Fi H170S3H / Hi-Fi B150S3H 7� Exit Menu This menu allows you to load the optimal default settings, and save or discard the changes to the BIOS items. Discard Changes and Exit Abandon all changes made during the current session and exit setup.
